Gold Sweep Desk Free

//@version=6
// Gold Sweep Desk 1.1.0 · MIT · © 2026 ProEA Lab · built for r/pinescript
// Gold liquidity as a desk: the prior-day, Asia and London highs and lows, their sweeps, the flip and the plan, in words.
// Every clock is New York time; bars while spot gold is closed are skipped, so spot and 24/7 feeds agree.
// Decisions happen on closed bars. The record is this chart's history after an estimated cost, not a forecast.
// Rules: docs/engine-contract.md in the release · https://proea.app/en/free/gold-sweep-desk
// License: MIT. Share it freely; keep this header.
indicator("Gold Sweep Desk", "GoldSweep", overlay = true, behind_chart = false, max_lines_count = 500, max_labels_count = 500, max_boxes_count = 500, max_bars_back = 2000)
const string GS_VERSION = "1.1.0"
const bool GS_IS_STRATEGY = false

// ═══ ENGINE · core.pinefrag ═════════════════════════════════════════════════════════════════════════════════════
// The engine decides; the renderer (visuals.pinefrag) only reads. Every engine name starts with "gs" and a
// capital letter; tests/display.test.mjs refuses any renderer line that assigns one. The rules are written in
// docs/engine-contract.md; tests/reference/engine.mjs is the independent reference.
//
//   ① SWEEP  a bar in an entry window trades through a fresh pool (prior day, Asia or London high/low) and a close
//            comes back inside it within a few bars.
//   ② FLIP   a close goes through the nearest opposing fair value gap: the gap inverts.
//   ③ PLAN   entry at that close (or at a later close back inside the gap); stop beyond the sweep's extreme; target
//            in R; flat at the time exit. Stop first when a bar reaches both.
// Every clock is New York time by the bar's open. Bars while spot gold is closed (Friday 17:00 → Sunday 18:00 and
// the daily 17:00–18:00 break) are skipped entirely, so a 24/7 feed and a spot feed give the same bar stream.
// Decisions happen on closed bars only. A plan's geometry is frozen at entry.

string gsG1 = "01 · Pools and windows"
bool gsPoolPd = input.bool(true, "Prior day high / low", group = gsG1, tooltip = "The previous trading day's high and low. Gold's day runs 18:00 → 17:00 New York.")
bool gsPoolAsia = input.bool(true, "Asia high / low · 20:00–24:00", group = gsG1, tooltip = "The range of the bars opening 20:00–24:00 New York; a pool from the first bar after midnight.")
bool gsPoolLon = input.bool(true, "London high / low · 02:00–05:00", group = gsG1, tooltip = "The range of the bars opening 02:00–05:00 New York; a pool from the first bar after 05:00.")
string gsWindows = input.string("London + New York", "Entry windows", options = ["London + New York", "Continuous 01:00–11:00"], group = gsG1, tooltip = "A setup can only start on a bar that opens inside a window (New York time). The pools are used up by any bar that trades through them, window or not.")
bool gsWinLon = input.bool(true, "  London 02:00–05:00", group = gsG1)
bool gsWinNy = input.bool(true, "  New York 07:00–11:00", group = gsG1)

string gsG2 = "02 · Sweep and flip"
float gsDepth = input.float(0.05, "Sweep depth · ATR beyond the level", minval = 0, maxval = 5, step = 0.05, group = gsG2, tooltip = "The raid must reach at least this far beyond the outermost pool it takes, in ATR(14).")
int gsReclaim = input.int(3, "Close back inside within · bars", minval = 0, maxval = 20, group = gsG2, tooltip = "The close back inside the swept level may come on the raid bar or on this many bars after it. Otherwise price was accepted beyond the level (HELD).")
string gsFailOn = input.string("A close back beyond the level", "A sweep fails on", options = ["A close back beyond the level", "Any new extreme"], group = gsG2, tooltip = "While the flip is awaited: a close back beyond the swept level ends the setup, and a new wick only moves the extreme (and the stop) further; or any new extreme ends it.")
string gsConfirm = input.string("FVG flip", "Confirmation", options = ["FVG flip", "Close back only"], group = gsG2, tooltip = "FVG flip: a close through the nearest opposing fair value gap. Close back only: the sweep's own close is the trigger.")
int gsLookback = input.int(30, "Gap born within · bars before the sweep", minval = 3, maxval = 200, group = gsG2)
int gsFlipBars = input.int(12, "Flip within · bars after the sweep", minval = 0, maxval = 100, group = gsG2)
float gsMinLeg = input.float(1.0, "Leg from the extreme · at least ATR", minval = 0, maxval = 10, step = 0.1, group = gsG2, tooltip = "The flip close must be at least this far from the sweep's extreme.")

string gsG3 = "03 · Plan"
string gsEntryMode = input.string("Flip close", "Entry", options = ["Flip close", "Retest close"], group = gsG3, tooltip = "Flip close: the flip's close is the entry. Retest close: after the flip, the first close back inside the gap within the retest bars.")
int gsRetestBars = input.int(12, "  Retest within · bars", minval = 1, maxval = 100, group = gsG3)
float gsBuffer = input.float(0.1, "Stop buffer · ATR beyond the extreme", minval = 0, maxval = 3, step = 0.05, group = gsG3)
float gsMaxStop = input.float(6.0, "Skip if the stop is wider than · ATR", minval = 0.5, maxval = 50, step = 0.5, group = gsG3)
float gsTargetR = input.float(2.0, "Target · R", minval = 0.5, maxval = 20, step = 0.5, group = gsG3, tooltip = "A design choice, not a tested setting. 1R is the distance from the entry to the stop; the 1R milestone is recorded on the way.")
string gsExitAt = input.string("16:45", "Flat at · HH:MM New York", group = gsG3, tooltip = "An open plan closes at the close of the bar that ends at or after this time; no entry on or after it. Gold's daily break starts at 17:00.")
string gsSide = input.string("Both", "Direction", options = ["Both", "Long only", "Short only"], group = gsG3)

string gsG4 = "04 · Costs and record"
float gsCost = input.float(0.40, "Estimated round-trip cost · price", minval = 0, step = 0.05, group = gsG4, tooltip = "Spread plus slippage for entry and exit together, in the chart's price (0.40 = 40 cents an ounce on spot gold). Every R on the desk is after this estimate. Set your own broker's.")
int gsPctMin = input.int(20, "Show percentages from N closed plans", minval = 5, maxval = 500, group = gsG4, tooltip = "Below this many closed plans the desk shows counts only: a percentage of a few plans says little.")

// ── clock: New York, by the bar's open
string gsTz = "America/New_York"
float gsTick = syminfo.mintick
bool gsClosed = barstate.isconfirmed
f_gsClock(string hm) =>
    array<string> parts = str.split(hm, ":")
    int out = -1
    if array.size(parts) == 2
        float h = str.tonumber(array.get(parts, 0))
        float m = str.tonumber(array.get(parts, 1))
        if not na(h) and not na(m)
            out := int(h) * 60 + int(m)
    out
// A trading day starts at 18:00: its id is the New York date six hours later.
f_gsDayId(int t) =>
    int t6 = t + 6 * 3600000
    year(t6, "America/New_York") * 10000 + month(t6, "America/New_York") * 100 + dayofmonth(t6, "America/New_York")
int gsExitMin = f_gsClock(gsExitAt) < 0 ? 16 * 60 + 45 : f_gsClock(gsExitAt)
int gsDow = dayofweek(time, gsTz)
int gsHm = hour(time, gsTz) * 60 + minute(time, gsTz)
int gsDayNow = f_gsDayId(time)
int gsCloseHm = hour(time_close, gsTz) * 60 + minute(time_close, gsTz)
int gsCloseDay = f_gsDayId(time_close)
// dayofweek: 1 = Sunday … 7 = Saturday.
bool gsGoldShut = gsDow == dayofweek.saturday or (gsDow == dayofweek.sunday and gsHm < 1080) or (gsDow == dayofweek.friday and gsHm >= 1020) or (gsHm >= 1020 and gsHm < 1080)
bool gsInAsia = gsHm >= 1200
bool gsInLon = gsHm >= 120 and gsHm < 300
string gsWinNow = gsWindows == "Continuous 01:00–11:00" ? (gsHm >= 60 and gsHm < 660 ? (gsHm < 420 ? "London" : "New York") : "") : (gsWinLon and gsHm >= 120 and gsHm < 300) ? "London" : (gsWinNy and gsHm >= 420 and gsHm < 660) ? "New York" : ""
bool gsAvailable = chart.is_standard and timeframe.isintraday and timeframe.in_seconds() <= 3600
string gsUnavailable = gsAvailable ? "" : not chart.is_standard ? "standard candles needed" : "an intraday chart of 1 hour or less is needed"

// ── state
type GSPool
    string name
    int side
    float price
    bool fresh = true
    int bornBar = na
    int takenBar = na
    int day = 0

type GSGap
    int dir
    int born
    int bornBar
    float bottom
    float top
    bool killed = false

// The setup in progress: 0 idle · 1 raid · 2 swept · 3 flipped (waiting for the retest).
type GSSetup
    int state = 0
    int dir = 0
    string window = ""
    float ref = na
    string pool = ""
    string pools = ""
    int poolsN = 0
    float extreme = na
    float depthAtr = na
    int raidN = na
    int raidBar = na
    int sweepN = na
    int sweepBar = na
    float gapB = na
    float gapT = na
    int gapBar = na
    float gapAtr = na
    int flipN = na
    int flipBar = na
    float legAtr = na
    float atrFlip = na
    float stop = na

// The plan (dir 0 = none). Its geometry is frozen at entry; a copy goes to gsDone when it ends.
type GSPlan
    int dir = 0
    int day = 0
    string window = ""
    string pool = ""
    int poolsN = 0
    float depthAtr = na
    float legAtr = na
    float gapAtr = na
    float riskAtr = na
    int raidBar = na
    int sweepBar = na
    int flipBar = na
    int gapBar = na
    int entryN = na
    int entryBar = na
    int entryTime = na
    string how = ""
    float extreme = na
    float gapB = na
    float gapT = na
    float entry = na
    float stop = na
    float risk = na
    float tp1 = na
    float target = na
    bool tp1Hit = false
    int tp1Bar = na
    int exitBar = na
    int exitTime = na
    float exitPrice = na
    string ending = ""
    float grossR = na
    float netR = na

type GSStat
    int plans = 0
    int wins = 0
    float sumR = 0.0
    int nTarget = 0
    int nStop = 0
    int nTime = 0
    int nTp1 = 0
    int raids = 0
    int sweeps = 0
    int flips = 0
    int held = 0
    int noGap = 0
    int failed = 0
    int noFlip = 0
    int noEntry = 0

// What happened on this bar.
type GSEv
    int raid = 0
    int sweep = 0
    int flip = 0
    int entry = 0
    bool exit = false
    string why = ""
    float r = na
    int exitDir = 0
    bool tp1 = false
    string stopped = ""
    string pool = ""

var GSSetup gsS = GSSetup.new()
var GSPlan gsP = GSPlan.new()
var GSStat gsSt = GSStat.new()
var array<GSPool> gsPools = array.new<GSPool>()
var array<GSPool> gsPoolLog = array.new<GSPool>()
var array<GSGap> gsGaps = array.new<GSGap>()
var array<GSPlan> gsDone = array.new<GSPlan>()
var array<int> gsEvBar = array.new<int>()
var array<string> gsEvWhat = array.new<string>()
var array<float> gsEvPx = array.new<float>()
GSEv gsEv = GSEv.new()
var float gsAtr = na
var float gsTrSum = 0.0
var int gsTrN = 0
var float gsPrevC = na
var int gsN = -1
var int gsDay = 0
var float gsDayH = na
var float gsDayL = na
var float gsAsiaH = na
var float gsAsiaL = na
var bool gsAsiaDone = false
var float gsLonH = na
var float gsLonL = na
var bool gsLonDone = false
var int gsRestN = -1
var float gsH1 = na
var float gsL1 = na
var int gsD1 = 0
var float gsH2 = na
var float gsL2 = na
var int gsD2 = 0
// The day's story for the desk, in words (a field, so the helpers below can extend it).
type GSText
    string log = ""
var GSText gsTx = GSText.new()

f_gsRText(float v) =>
    (v < 0 ? "−" : "+") + str.tostring(math.abs(v), "0.0") + "R"
f_gsHhmm() =>
    str.tostring(hour(time, "America/New_York"), "00") + ":" + str.tostring(minute(time, "America/New_York"), "00")
f_gsLogAdd(string what) =>
    gsTx.log := gsTx.log + (gsTx.log == "" ? "" : " · ") + f_gsHhmm() + what
f_gsNote(string what) =>
    array.push(gsEvBar, bar_index)
    array.push(gsEvWhat, what)
    array.push(gsEvPx, close)
    if array.size(gsEvBar) > 200
        array.shift(gsEvBar)
        array.shift(gsEvWhat)
        array.shift(gsEvPx)
f_gsPoolNew(string name, int side, float price, int day) =>
    GSPool p = GSPool.new(name, side, price, true, bar_index, na, day)
    array.push(gsPools, p)
    array.push(gsPoolLog, p)
    if array.size(gsPoolLog) > 120
        array.shift(gsPoolLog)
f_gsReset(string why) =>
    // A setup ends without a plan: remembered for the desk and the alerts.
    gsEv.stopped := why
    gsS.state := 0
    gsS.dir := 0
    if why == "HELD"
        gsSt.held += 1
    else if why == "NO GAP"
        gsSt.noGap += 1
    else if why == "SWEEP FAILED"
        gsSt.failed += 1
    else if why == "NO FLIP" or why == "NO RETEST"
        gsSt.noFlip += 1
    else
        gsSt.noEntry += 1
    f_gsNote(why)
    f_gsLogAdd(" " + str.lower(why))

// Entry at this close, or a refusal. Returns true when a plan starts.
f_gsEnter(float px, string how) =>
    int d = gsS.dir
    float risk = (px - gsS.stop) * d
    bool ok = false
    if not (risk > 0)
        f_gsReset("NO ENTRY · stop not beyond entry")
    else if risk > gsMaxStop * gsS.atrFlip
        f_gsReset("NO ENTRY · stop too wide")
    else if not (gsCloseDay == gsDayNow and gsCloseHm < gsExitMin)
        f_gsReset("NO ENTRY · too late in the day")
    else
        ok := true
        gsP.dir := d
        gsP.day := gsDayNow
        gsP.window := gsS.window
        gsP.pool := gsS.pool
        gsP.poolsN := gsS.poolsN
        gsP.depthAtr := gsS.depthAtr
        gsP.legAtr := gsS.legAtr
        gsP.gapAtr := gsS.gapAtr
        gsP.riskAtr := risk / gsS.atrFlip
        gsP.raidBar := gsS.raidBar
        gsP.sweepBar := gsS.sweepBar
        gsP.flipBar := gsS.flipBar
        gsP.gapBar := gsS.gapBar
        gsP.entryN := gsN
        gsP.entryBar := bar_index
        gsP.entryTime := time
        gsP.how := how
        gsP.extreme := gsS.extreme
        gsP.gapB := gsS.gapB
        gsP.gapT := gsS.gapT
        gsP.entry := px
        gsP.stop := gsS.stop
        gsP.risk := risk
        gsP.tp1 := px + d * risk
        gsP.target := px + d * gsTargetR * risk
        gsP.tp1Hit := false
        gsP.tp1Bar := na
        gsP.exitBar := na
        gsP.exitTime := na
        gsP.exitPrice := na
        gsP.ending := ""
        gsP.grossR := na
        gsP.netR := na
        gsS.state := 4
        gsEv.entry := d
        f_gsNote(d == 1 ? "ENTRY LONG" : "ENTRY SHORT")
        f_gsLogAdd((d == 1 ? " ▲ long " : " ▼ short ") + str.tostring(px, format.mintick))
    ok

// The flip on this bar, if the close goes through the gap far enough from the extreme.
f_gsFlip() =>
    int d = gsS.dir
    bool through = d == -1 ? close < gsS.gapB : close > gsS.gapT
    float leg = (gsS.extreme - close) * -d
    bool done = false
    if through and leg >= gsMinLeg * gsAtr
        done := true
        gsS.flipN := gsN
        gsS.flipBar := bar_index
        gsS.legAtr := leg / gsAtr
        gsS.atrFlip := gsAtr
        gsS.stop := d == -1 ? math.ceil((gsS.extreme + gsBuffer * gsAtr) / gsTick - 1e-9) * gsTick : math.floor((gsS.extreme - gsBuffer * gsAtr) / gsTick + 1e-9) * gsTick
        gsEv.flip := d
        gsSt.flips += 1
        f_gsNote("FLIP")
        f_gsLogAdd(" flip")
        if gsEntryMode == "Flip close"
            f_gsEnter(close, "flip close")
        else
            gsS.state := 3
    done

// The sweep on this bar: pick the gap to invert (or trigger at once with "Close back only").
f_gsSweep() =>
    gsS.sweepN := gsN
    gsS.sweepBar := bar_index
    gsEv.sweep := gsS.dir
    gsEv.pool := gsS.pool
    gsSt.sweeps += 1
    f_gsNote("SWEEP " + gsS.pool)
    f_gsLogAdd(" swept " + gsS.pool)
    if gsConfirm == "Close back only"
        gsS.legAtr := (gsS.extreme - close) * -gsS.dir / gsAtr
        gsS.atrFlip := gsAtr
        gsS.flipN := gsN
        gsS.flipBar := bar_index
        gsS.stop := gsS.dir == -1 ? math.ceil((gsS.extreme + gsBuffer * gsAtr) / gsTick - 1e-9) * gsTick : math.floor((gsS.extreme - gsBuffer * gsAtr) / gsTick + 1e-9) * gsTick
        f_gsEnter(close, "reclaim close")
    else
        int want = -gsS.dir
        GSGap best = na
        for g in gsGaps
            if g.dir == want and not g.killed and g.born >= gsN - gsLookback and g.born < gsN
                if na(best)
                    best := g
                else if want == 1 ? g.bottom > best.bottom : g.top < best.top
                    best := g
        if na(best)
            f_gsReset("NO GAP")
        else
            gsS.gapB := best.bottom
            gsS.gapT := best.top
            gsS.gapBar := best.bornBar
            gsS.gapAtr := (best.top - best.bottom) / gsAtr
            gsS.state := 2
            f_gsFlip()
    // The branches above return different types; the function returns the setup state.
    gsS.state

f_gsEnd(float px, string why) =>
    float gross = (px - gsP.entry) * gsP.dir / gsP.risk
    float net = gross - gsCost / gsP.risk
    gsP.exitBar := bar_index
    gsP.exitTime := time
    gsP.exitPrice := px
    gsP.ending := why
    gsP.grossR := gross
    gsP.netR := net

if gsClosed and gsAvailable and not gsGoldShut
    gsN += 1
    // (A) ATR over session bars, this bar included.
    float tr = na(gsPrevC) ? high - low : math.max(high - low, math.abs(high - gsPrevC), math.abs(low - gsPrevC))
    if gsTrN < 14
        gsTrSum += tr
        gsTrN += 1
        if gsTrN == 14
            gsAtr := gsTrSum / 14
    else
        gsAtr := (tr + 13 * gsAtr) / 14
    gsPrevC := close

    // (B) A new trading day: yesterday's range becomes the prior-day pools; the session pools start again.
    if gsDayNow != gsDay
        for p in gsPools
            if p.fresh
                p.takenBar := bar_index - 1
        array.clear(gsPools)
        if gsDay != 0 and gsPoolPd and not na(gsDayH)
            f_gsPoolNew("PDH", 1, gsDayH, gsDayNow)
            f_gsPoolNew("PDL", -1, gsDayL, gsDayNow)
        gsDay := gsDayNow
        gsDayH := na
        gsDayL := na
        gsAsiaH := na
        gsAsiaL := na
        gsAsiaDone := false
        gsLonH := na
        gsLonL := na
        gsLonDone := false
        gsTx.log := ""
    if not gsAsiaDone and not na(gsAsiaH) and not gsInAsia
        gsAsiaDone := true
        if gsPoolAsia
            f_gsPoolNew("Asia high", 1, gsAsiaH, gsDayNow)
            f_gsPoolNew("Asia low", -1, gsAsiaL, gsDayNow)
    if not gsLonDone and not na(gsLonH) and not gsInLon
        gsLonDone := true
        if gsPoolLon
            f_gsPoolNew("London high", 1, gsLonH, gsDayNow)
            f_gsPoolNew("London low", -1, gsLonL, gsDayNow)

    // (C) The open plan: a later day, stop first, target, then the time exit.
    if gsP.dir != 0 and gsN > gsP.entryN
        int d = gsP.dir
        bool stopHit = d == 1 ? low <= gsP.stop : high >= gsP.stop
        bool targetHit = d == 1 ? high >= gsP.target : low <= gsP.target
        bool lateDay = gsDayNow != gsP.day
        if lateDay
            f_gsEnd(open, "TIME")
        else if stopHit
            f_gsEnd((d == 1 ? open <= gsP.stop : open >= gsP.stop) ? open : gsP.stop, "STOP")
        else if targetHit
            f_gsEnd(gsP.target, "TARGET")
        else if gsCloseDay == gsP.day and gsCloseHm >= gsExitMin
            f_gsEnd(close, "TIME")
        if not gsP.tp1Hit and not stopHit and not lateDay and (d == 1 ? high >= gsP.tp1 : low <= gsP.tp1)
            gsP.tp1Hit := true
            gsP.tp1Bar := bar_index
            gsEv.tp1 := true
        if gsP.ending != ""
            gsEv.exit := true
            gsEv.why := gsP.ending
            gsEv.r := gsP.netR
            gsEv.exitDir := gsP.dir
            gsSt.plans += 1
            gsSt.wins += gsP.netR > 0 ? 1 : 0
            gsSt.sumR += gsP.netR
            gsSt.nTarget += gsP.ending == "TARGET" ? 1 : 0
            gsSt.nStop += gsP.ending == "STOP" ? 1 : 0
            gsSt.nTime += gsP.ending == "TIME" ? 1 : 0
            gsSt.nTp1 += gsP.tp1Hit ? 1 : 0
            f_gsNote(gsP.ending)
            f_gsLogAdd(" " + str.lower(gsP.ending) + " " + f_gsRText(gsP.netR))
            array.push(gsDone, gsP.copy())
            if array.size(gsDone) > 300
                array.shift(gsDone)
            gsP.dir := 0
            gsRestN := gsN
            gsS.state := 0
            gsS.dir := 0

    // (D) Pools this bar trades through are used up, whatever else happens.
    int penHN = 0
    int penLN = 0
    float penHMax = na
    float penLMin = na
    string penHName = ""
    string penLName = ""
    string penHAll = ""
    string penLAll = ""
    for p in gsPools
        if p.fresh and p.side == 1 and high > p.price
            p.fresh := false
            p.takenBar := bar_index
            penHN += 1
            penHAll += (penHAll == "" ? "" : " + ") + p.name
            if na(penHMax) or p.price > penHMax
                penHMax := p.price
                penHName := p.name
        else if p.fresh and p.side == -1 and low < p.price
            p.fresh := false
            p.takenBar := bar_index
            penLN += 1
            penLAll += (penLAll == "" ? "" : " + ") + p.name
            if na(penLMin) or p.price < penLMin
                penLMin := p.price
                penLName := p.name

    // (E) The setup: RAID → SWEPT → (FLIPPED →) plan.
    if gsP.dir == 0
        if gsS.state == 1
            int d = gsS.dir
            gsS.extreme := d == -1 ? math.max(gsS.extreme, high) : math.min(gsS.extreme, low)
            int moreN = d == -1 ? penHN : penLN
            if moreN > 0
                gsS.poolsN += moreN
                gsS.pools += " + " + (d == -1 ? penHAll : penLAll)
                float outer = d == -1 ? penHMax : penLMin
                if d == -1 ? outer > gsS.ref : outer < gsS.ref
                    gsS.ref := outer
                    gsS.pool := d == -1 ? penHName : penLName
            if d == -1 ? close < gsS.ref : close > gsS.ref
                f_gsSweep()
            else if gsN - gsS.raidN >= gsReclaim
                f_gsReset("HELD")
        else if gsS.state == 2
            int d = gsS.dir
            bool beyond = d == -1 ? high > gsS.extreme : low < gsS.extreme
            bool onClose = gsFailOn == "A close back beyond the level"
            if onClose and beyond
                gsS.extreme := d == -1 ? high : low
            if onClose ? (d == -1 ? close > gsS.ref : close < gsS.ref) : beyond
                f_gsReset("SWEEP FAILED")
            else if not f_gsFlip() and gsN - gsS.sweepN >= gsFlipBars
                f_gsReset("NO FLIP")
        else if gsS.state == 3
            int d = gsS.dir
            if d == -1 ? high >= gsS.stop : low <= gsS.stop
                f_gsReset("NO ENTRY · stop traded before the retest")
            else if close >= gsS.gapB and close <= gsS.gapT
                f_gsEnter(close, "retest close")
            else if gsN - gsS.flipN >= gsRetestBars
                f_gsReset("NO RETEST")
        else if gsS.state == 0 and gsN != gsRestN and not na(gsAtr) and gsTrN >= 14
            bool up = penHN > 0 and gsSide != "Long only"
            bool dn = penLN > 0 and gsSide != "Short only"
            if gsWinNow != "" and up != dn
                int d = up ? -1 : 1
                float outer = up ? penHMax : penLMin
                float depth = d == -1 ? high - outer : outer - low
                if depth >= gsDepth * gsAtr
                    gsS := GSSetup.new(1, d, gsWinNow, outer, up ? penHName : penLName, up ? penHAll : penLAll, up ? penHN : penLN, d == -1 ? high : low, depth / gsAtr, gsN, bar_index)
                    gsEv.raid := d
                    gsEv.pool := gsS.pool
                    gsSt.raids += 1
                    f_gsNote("RAID " + gsS.pool)
                    f_gsLogAdd(" raid " + gsS.pool)
                    if d == -1 ? close < gsS.ref : close > gsS.ref
                        f_gsSweep()

    // (F) Gaps: a close through a gap kills it; a gap completes on this bar (three bars of the same trading day).
    for g in gsGaps
        if not g.killed and g.born < gsN and (g.dir == 1 ? close < g.bottom : close > g.top)
            g.killed := true
    if gsN >= 2 and gsD2 == gsDayNow
        if low > gsH2
            array.push(gsGaps, GSGap.new(1, gsN, bar_index, gsH2, low, false))
        if high < gsL2
            array.push(gsGaps, GSGap.new(-1, gsN, bar_index, high, gsL2, false))
    while array.size(gsGaps) > 0 and array.first(gsGaps).born < gsN - 2 * gsLookback
        array.shift(gsGaps)
    gsH2 := gsH1
    gsL2 := gsL1
    gsD2 := gsD1
    gsH1 := high
    gsL1 := low
    gsD1 := gsDayNow

    // (G) Today's range and the session ranges include this bar.
    gsDayH := na(gsDayH) ? high : math.max(gsDayH, high)
    gsDayL := na(gsDayL) ? low : math.min(gsDayL, low)
    if gsInAsia and not gsAsiaDone
        gsAsiaH := na(gsAsiaH) ? high : math.max(gsAsiaH, high)
        gsAsiaL := na(gsAsiaL) ? low : math.min(gsAsiaL, low)
    if gsInLon and not gsLonDone
        gsLonH := na(gsLonH) ? high : math.max(gsLonH, high)
        gsLonL := na(gsLonL) ? low : math.min(gsLonL, low)

// ═══ ALERTS · alerts.pinefrag (indicator only) ══════════════════════════════════════════════════════════════════
// Engine events are decided on closed bars, so every message goes out once per bar close. For the messages, create
// one TradingView alert on this indicator with "Any alert() function call"; the named conditions below also work
// one by one. JSON keys: src, version, symbol, tf, event, side, pool, entry, sl, tp1, target, reason, r, time; a
// missing number is null.

string gsG5 = "05 · Alerts"
string gsAlertFmt = input.string("Text", "Alert format", options = ["Text", "JSON"], group = gsG5, tooltip = "Create the alert with 'Any alert() function call'. Text sends one readable line; JSON sends one object per event for webhooks and bots.")
bool gsAlertSetup = input.bool(true, "Also alert the sweep and the flip (before an entry)", group = gsG5)

f_gsNum(float v, string fmt) =>
    na(v) ? "null" : str.tostring(v, fmt)
f_gsPx(float v) =>
    na(v) ? "—" : str.tostring(v, format.mintick)
f_gsMsg(string ev, int side, string pool, float entry, float sl, float tp1, float target, string reason, float r) =>
    string sideTxt = side == 1 ? "LONG" : side == -1 ? "SHORT" : "NONE"
    string js = "{\"src\":\"GoldSweepDesk\",\"version\":\"" + GS_VERSION + "\",\"symbol\":\"" + syminfo.ticker + "\",\"tf\":\"" + timeframe.period + "\",\"event\":\"" + ev + "\",\"side\":\"" + sideTxt + "\",\"pool\":\"" + pool + "\",\"entry\":" + f_gsNum(entry, format.mintick) + ",\"sl\":" + f_gsNum(sl, format.mintick) + ",\"tp1\":" + f_gsNum(tp1, format.mintick) + ",\"target\":" + f_gsNum(target, format.mintick) + ",\"reason\":\"" + reason + "\",\"r\":" + f_gsNum(r, "0.00") + ",\"time\":" + str.tostring(time_close) + "}"
    string tx = "Gold Sweep Desk · " + syminfo.ticker + " " + timeframe.period + " · " + ev + (side != 0 and ev != sideTxt ? " " + sideTxt : "") + (pool != "" ? " · " + pool : "") + (na(entry) ? "" : " · entry " + f_gsPx(entry) + " · stop " + f_gsPx(sl) + " · 1R " + f_gsPx(tp1) + " · target " + f_gsPx(target)) + (reason != "" ? " · " + reason : "") + (na(r) ? "" : " · " + (r < 0 ? "−" : "+") + str.tostring(math.abs(r), "0.00") + "R after the estimated cost")
    gsAlertFmt == "JSON" ? js : tx

// In the order they happen on a bar: the 1R milestone, an exit, then a new setup, a sweep, a flip and an entry.
if gsClosed
    if gsEv.tp1 and gsP.dir != 0
        alert(f_gsMsg("ONE_R", gsP.dir, gsP.pool, gsP.entry, gsP.stop, gsP.tp1, gsP.target, "1R reached", na), alert.freq_once_per_bar_close)
    if gsEv.exit and array.size(gsDone) > 0
        GSPlan x = array.last(gsDone)
        alert(f_gsMsg("EXIT", x.dir, x.pool, x.entry, x.stop, x.tp1, x.target, x.ending, x.netR), alert.freq_once_per_bar_close)
    if gsAlertSetup and gsEv.sweep != 0
        alert(f_gsMsg("SWEEP", gsEv.sweep, gsEv.pool, na, na, na, na, "swept, waiting for the flip", na), alert.freq_once_per_bar_close)
    if gsAlertSetup and gsEv.flip != 0 and gsEv.entry == 0
        alert(f_gsMsg("FLIP", gsEv.flip, gsS.pool, na, gsS.stop, na, na, gsEntryMode == "Retest close" ? "waiting for the retest close" : gsEv.stopped, na), alert.freq_once_per_bar_close)
    if gsEv.entry != 0
        alert(f_gsMsg(gsEv.entry == 1 ? "LONG" : "SHORT", gsP.dir, gsP.pool, gsP.entry, gsP.stop, gsP.tp1, gsP.target, gsP.how, na), alert.freq_once_per_bar_close)

alertcondition(gsEv.sweep != 0, "Sweep", "Gold Sweep Desk: a pool was swept; waiting for the flip")
alertcondition(gsEv.entry == 1, "Long", "Gold Sweep Desk: long, a swept low flipped")
alertcondition(gsEv.entry == -1, "Short", "Gold Sweep Desk: short, a swept high flipped")
alertcondition(gsEv.tp1, "1R reached", "Gold Sweep Desk: the plan reached 1R")
alertcondition(gsEv.exit and gsEv.why == "TARGET", "Target", "Gold Sweep Desk: the target was reached")
alertcondition(gsEv.exit and gsEv.why == "STOP", "Stopped", "Gold Sweep Desk: the stop ended the plan")
alertcondition(gsEv.exit and gsEv.why == "TIME", "Flat at the time exit", "Gold Sweep Desk: the time exit closed the plan")

// ═══ DISPLAY · visuals.pinefrag ═════════════════════════════════════════════════════════════════════════════════
// Reads engine state and draws it. It never assigns an engine variable, requests data, trades or alerts
// (tests/display.test.mjs enforces this), so a display change cannot change a plan or a result.
// Desk standard: state line · reason · ribbon · steps (✓ / ✗ / —, ● required) · plan in price and R · today ·
// record (counts first, % only from the threshold) · footer. Co-Pilot: NOW · WHY · PLAN · LIMITS.
// Layers: the desk and the live drawings follow every tick; the history is redrawn once per closed bar.

string gsvG = "06 · View"
string gsvTheme = input.string("Standard", "Theme", options = ["Standard", "Colorblind-safe"], group = gsvG)
string gsvDeskPos = input.string("Top right", "Desk position", options = ["Top right", "Top left", "Bottom right", "Bottom left", "Off"], group = gsvG)
string gsvRows = input.string("Compact", "Desk rows", options = ["Compact", "Full"], group = gsvG, tooltip = "Full adds every pool of the day, the last plan and the average result.")
string gsvPilot = input.string("Brief", "Co-Pilot", options = ["Standard", "Brief", "Off"], group = gsvG, tooltip = "The desk in plain words. Brief shows NOW and PLAN; Standard adds WHY and LIMITS.")
string gsvPilotPos = input.string("Bottom left", "Co-Pilot position", options = ["Bottom left", "Bottom right", "Top left", "Top right"], group = gsvG)
string gsvTextSize = input.string("Normal", "Text size", options = ["Small", "Normal", "Large"], group = gsvG)
int gsvDays = input.int(2, "Days drawn", minval = 1, maxval = 30, group = gsvG, tooltip = "Pools, sessions and plans of this many trading days (today included), within the last 1,500 bars.")
bool gsvPools = input.bool(true, "Liquidity pools", group = gsvG)
bool gsvSessions = input.bool(true, "Asia and London boxes", group = gsvG)
bool gsvZones = input.bool(true, "Risk / reward zones", group = gsvG)
bool gsvMisses = input.bool(true, "Mark setups that ended without a plan (◌)", group = gsvG)
bool gsvTint = input.bool(false, "Tint candles while a plan is open", group = gsvG)

// Colour carries meaning: teal = long / target, coral = short / stop, gold = liquidity and a setup in progress.
bool gsvCb = gsvTheme == "Colorblind-safe"
color gsvUp = gsvCb ? #56B4E9 : #26A69A
color gsvDown = gsvCb ? #E69F00 : #EF5350
color gsvGold = gsvCb ? #F0E442 : #F2B33D
color gsvAsia = #7E8CE0
color gsvInk = #E6E9F0
color gsvMuted = #8A93A6
color gsvGrey = #6B7280
color gsvPanel = color.new(#10151F, 6)
string gsvSz = gsvTextSize == "Small" ? size.tiny : gsvTextSize == "Large" ? size.normal : size.small
string gsvSzState = gsvTextSize == "Small" ? size.small : gsvTextSize == "Large" ? size.large : size.normal

f_gsvCorner(string p) =>
    p == "Top left" ? position.top_left : p == "Bottom right" ? position.bottom_right : p == "Bottom left" ? position.bottom_left : position.top_right
f_gsvPx(float v) =>
    na(v) ? "—" : str.tostring(v, format.mintick)
f_gsvR(float v) =>
    na(v) ? "—" : math.abs(v) < 0.05 ? "0.0R" : (v < 0 ? "−" : "+") + str.tostring(math.abs(v), "0.0") + "R"
f_gsvHm(int mins) =>
    str.tostring(int(mins / 60) % 24, "00") + ":" + str.tostring(mins % 60, "00")
f_gsvAt(int t) =>
    str.tostring(hour(t, "America/New_York"), "00") + ":" + str.tostring(minute(t, "America/New_York"), "00")
f_gsvLeft(int mins) =>
    mins <= 0 ? "closing" : (mins >= 60 ? str.tostring(int(mins / 60)) + " h " : "") + str.tostring(mins % 60) + " m left"
f_gsvMark(int s) =>
    s == 1 ? "✓ met" : s == 0 ? "✗ not met" : s == -1 ? "— no data" : s == -3 ? "— waiting" : "— off"
f_gsvTone(int s) =>
    s == 1 ? gsvUp : s == 0 ? gsvDown : gsvMuted
f_gsvEnding(string why) =>
    why == "TARGET" ? "TARGET" : why == "STOP" ? "STOP" : why == "TIME" ? "FLAT AT THE TIME EXIT" : why
f_gsvEndMark(string why, float r) =>
    why == "TARGET" ? "✓" : why == "STOP" ? "✗" : r > 0.05 ? "✓" : r < -0.05 ? "✗" : "◌"
f_gsvWrap(string txt, int columns) =>
    array<string> words = str.split(txt, " ")
    string output = ""
    int width = 0
    for word in words
        if width > 0 and width + str.length(word) + 1 > columns
            output += "\n"
            width := 0
        output += (width > 0 ? " " : "") + word
        width += str.length(word) + 1
    output
f_gsvSide(int d) =>
    d == 1 ? "long" : "short"

// ── windows, in New York minutes
bool gsvCont = gsWindows == "Continuous 01:00–11:00"
int gsvWinEnd = gsvCont ? 660 : gsWinNow == "London" ? 300 : 660
string gsvWinTxt = gsvCont ? "01:00–11:00" : gsWinNow == "London" ? "London 02:00–05:00" : "New York 07:00–11:00"
// The next window start after this minute of the day: later today, tomorrow, or Monday (no windows at the weekend).
f_gsvNextWin(int hm) =>
    int dow = dayofweek(time, "America/New_York")
    bool later = gsvCont ? hm >= 60 : not ((gsWinLon and hm < 120) or (gsWinNy and hm < 420))
    string day = dow == dayofweek.saturday or dow == dayofweek.sunday or (dow == dayofweek.friday and later) ? "Monday " : later ? "tomorrow " : ""
    string win = gsvCont ? "01:00" : (not later and gsWinLon and hm < 120) or (later and gsWinLon) ? "London 02:00" : gsWinNy ? "New York 07:00" : ""
    win == "" ? "none (both windows off)" : day + win

// ── what the desk shows (display variables; the engine's objects are only read)
string gsvState = ""
string gsvReason = ""
string gsvNow = ""
string gsvPlan = ""
color gsvTone = gsvMuted
string gsvRib = ""
int gsvDir = 0
string gsvNearUp = ""
string gsvNearDn = ""
int gsvFresh = 0
int gsvPoolsToday = 0
if barstate.islastconfirmedhistory or barstate.isrealtime
    // Nearest fresh pools above and below the close.
    float upPx = na
    float dnPx = na
    for p in gsPools
        gsvPoolsToday += 1
        if p.fresh
            gsvFresh += 1
            if p.price >= close and (na(upPx) or p.price < upPx)
                upPx := p.price
                gsvNearUp := p.name + " " + f_gsvPx(p.price) + " (+" + str.tostring(p.price - close, format.mintick) + ")"
            if p.price < close and (na(dnPx) or p.price > dnPx)
                dnPx := p.price
                gsvNearDn := p.name + " " + f_gsvPx(p.price) + " (−" + str.tostring(close - p.price, format.mintick) + ")"
    gsvDir := gsP.dir != 0 ? gsP.dir : gsS.state != 0 ? gsS.dir : 0
    string r1 = gsvFresh > 0 ? "✓" : "·"
    string r2 = "·"
    string r3 = "·"
    string r4 = "·"
    string r5 = "·"
    if not gsAvailable
        gsvState := "— UNAVAILABLE · " + timeframe.period + " chart"
        gsvReason := gsUnavailable == "standard candles needed" ? "Heikin Ashi, Renko and other synthetic candles move the closes. Use standard candles." : "Use an intraday chart of 1 hour or less (5 or 15 minutes on gold)."
        gsvNow := "This chart cannot run the rule. " + gsvReason
    else if gsTrN < 14
        gsvState := "○ WARMING UP"
        gsvReason := "The ATR needs 14 session bars."
        gsvNow := gsvReason
    else if gsP.dir != 0
        float openR = (close - gsP.entry) * gsP.dir / gsP.risk
        gsvState := "● IN TRADE · " + (gsP.dir == 1 ? "LONG" : "SHORT") + " · " + f_gsvR(openR) + (gsP.tp1Hit ? " · 1R reached" : "")
        gsvTone := gsP.dir == 1 ? gsvUp : gsvDown
        gsvReason := "Stop " + f_gsvPx(gsP.stop) + " · 1R " + f_gsvPx(gsP.tp1) + (gsP.tp1Hit ? " ✓" : "") + " · target " + f_gsvPx(gsP.target) + " · flat at " + gsExitAt
        gsvNow := "In a " + f_gsvSide(gsP.dir) + " from " + f_gsvPx(gsP.entry) + " after the " + gsP.pool + " sweep (" + gsP.how + "), " + str.tostring(bar_index - gsP.entryBar) + " bars ago, " + f_gsvR(openR) + " at this close before costs."
        gsvPlan := "Stop first on every closed bar: the stop " + f_gsvPx(gsP.stop) + " is beyond the sweep's extreme " + f_gsvPx(gsP.extreme) + ", where the idea is wrong. The target " + f_gsvPx(gsP.target) + " ends it; otherwise it is flat at " + gsExitAt + " New York."
        r2 := "✓"
        r3 := "✓"
        r4 := "✓"
        r5 := "▶"
    else if gsGoldShut
        gsvState := "◌ GOLD IS CLOSED"
        gsvReason := "Spot gold trades Sunday 18:00 → Friday 17:00 New York, with a break 17:00–18:00. These bars are skipped."
        gsvNow := gsvReason
    else if gsS.state == 1
        int left = math.max(0, gsReclaim - (gsN - gsS.raidN))
        gsvState := "● RAID · " + gsS.pool + " · " + (gsS.dir == -1 ? "above" : "below")
        gsvTone := gsvGold
        gsvReason := "A close back " + (gsS.dir == -1 ? "below " : "above ") + f_gsvPx(gsS.ref) + " makes it a sweep (" + str.tostring(left) + (left == 1 ? " bar" : " bars") + " left); otherwise price was accepted beyond the level."
        gsvNow := "Price is raiding the " + gsS.pool + " (" + f_gsvPx(gsS.ref) + ") in the " + gsS.window + " window, extreme " + f_gsvPx(gsS.extreme) + ". " + gsvReason
        r2 := "▶"
    else if gsS.state == 2
        int left = math.max(0, gsFlipBars - (gsN - gsS.sweepN))
        float lvl = gsS.dir == -1 ? math.min(gsS.gapB, gsS.extreme - gsMinLeg * gsAtr) : math.max(gsS.gapT, gsS.extreme + gsMinLeg * gsAtr)
        gsvState := "● SWEPT · " + gsS.pool + " · waiting for the flip"
        gsvTone := gsvGold
        gsvReason := "A close " + (gsS.dir == -1 ? "below " : "above ") + f_gsvPx(lvl) + " flips the gap " + f_gsvPx(gsS.gapB) + "–" + f_gsvPx(gsS.gapT) + " (" + str.tostring(left) + (left == 1 ? " bar" : " bars") + " left). " + (gsFailOn == "Any new extreme" ? "A new extreme ends it." : "A close back " + (gsS.dir == -1 ? "above " : "below ") + f_gsvPx(gsS.ref) + " ends it.")
        gsvNow := "The " + gsS.pool + " was swept (extreme " + f_gsvPx(gsS.extreme) + "). The desk now waits for a close through the nearest opposing gap, the flip that confirms the reversal."
        r2 := "✓"
        r3 := "▶"
    else if gsS.state == 3
        int left = math.max(0, gsRetestBars - (gsN - gsS.flipN))
        gsvState := "● FLIPPED · waiting for the retest"
        gsvTone := gsvGold
        gsvReason := "A close back inside " + f_gsvPx(gsS.gapB) + "–" + f_gsvPx(gsS.gapT) + " enters " + f_gsvSide(gsS.dir) + " (" + str.tostring(left) + (left == 1 ? " bar" : " bars") + " left); a touch of the stop " + f_gsvPx(gsS.stop) + " cancels."
        gsvNow := "The gap flipped after the " + gsS.pool + " sweep. Retest mode waits for a close back inside the flipped gap."
        r2 := "✓"
        r3 := "✓"
        r4 := "▶"
    else if gsWinNow != ""
        int left = gsvWinEnd - gsHm
        gsvState := "○ WATCHING · " + gsWinNow + " window · " + str.tostring(gsvFresh) + (gsvFresh == 1 ? " fresh pool" : " fresh pools")
        gsvTone := gsvGold
        gsvReason := gsvFresh == 0 ? "Every pool of today is used up. The next ones: Asia and London ranges, then tomorrow's prior-day levels." : "A raid of a fresh pool, then a close back inside it, starts a setup (" + f_gsvLeft(left) + ")."
        gsvNow := "Watching the " + gsWinNow + " window. " + (gsvNearUp != "" ? "Above: " + gsvNearUp + ". " : "") + (gsvNearDn != "" ? "Below: " + gsvNearDn + ". " : "") + (gsvFresh == 0 ? "No fresh pool is left today." : "")
    else
        gsvState := "◌ OUTSIDE THE WINDOWS · next " + f_gsvNextWin(gsHm)
        gsvReason := "Setups start only in " + (gsvCont ? "the 01:00–11:00 window" : (gsWinLon ? "London 02:00–05:00" : "") + (gsWinLon and gsWinNy ? " and " : "") + (gsWinNy ? "New York 07:00–11:00" : "")) + " (New York time). Pools still get used up now."
        gsvNow := "Outside the entry windows. " + (gsvNearUp != "" ? "Above: " + gsvNearUp + ". " : "") + (gsvNearDn != "" ? "Below: " + gsvNearDn + "." : "")
    gsvRib := "01 POOLS " + r1 + "  02 SWEEP " + r2 + "  03 FLIP " + r3 + "  04 PLAN " + r4 + "  05 RESULT " + r5
    if gsvPlan == ""
        gsvPlan := "Rule: sweep of the prior day, Asia or London high/low in " + (gsvCont ? "01:00–11:00" : "the London or New York window") + " → a close through the nearest opposing gap" + (gsEntryMode == "Retest close" ? " → a close back inside it" : "") + " → entry at that close, stop beyond the sweep's extreme, target " + str.tostring(gsTargetR, "0.0#") + "R, flat at " + gsExitAt + "."

// ── desk and Co-Pilot
var table gsvDesk = table.new(f_gsvCorner(gsvDeskPos), 2, 40, frame_width = 0, border_width = 0)
string gsvPilotCorner = gsvPilotPos != gsvDeskPos ? gsvPilotPos : gsvDeskPos == "Bottom left" ? "Bottom right" : "Bottom left"
var table gsvPilotT = table.new(f_gsvCorner(gsvPilotCorner), 1, 7, frame_width = 0, border_width = 0)
int gsvPOff = gsvPilotCorner == "Top left" ? 1 : 0
int gsvOff = gsvDeskPos == "Top left" ? 1 : 0
f_gsvRow(int r, string a, string b, color ca, color cb) =>
    table.cell(gsvDesk, 0, r + gsvOff, a, text_color = ca, bgcolor = gsvPanel, text_size = gsvSz, text_halign = text.align_left)
    table.cell(gsvDesk, 1, r + gsvOff, b, text_color = cb, bgcolor = gsvPanel, text_size = gsvSz, text_halign = text.align_left)
f_gsvWide(int r, string txt, color c, bool bold, string tip) =>
    table.cell(gsvDesk, 0, r + gsvOff, txt, text_color = c, bgcolor = gsvPanel, text_size = bold ? gsvSzState : gsvSz, text_halign = text.align_left, text_formatting = bold ? text.format_bold : text.format_none, tooltip = tip)
    table.merge_cells(gsvDesk, 0, r + gsvOff, 1, r + gsvOff)
// The rule is built for 5–15 minute candles: from 30 minutes a candle is a large part of a window and the 2R target has
// little room before 16:45; TradingView loads only a few days of 1–4 minute candles, too few for this chart's record.
int gsvTfSec = timeframe.in_seconds()
string gsvTfMins = str.tostring(gsvTfSec / 60, "#")
string gsvTfNote = gsvTfSec >= 1800 ? "TIMEFRAME · built for 5–15 minutes: on " + gsvTfMins + "-minute candles a plan has little room for its target before 16:45" : gsvTfSec < 300 ? "TIMEFRAME · built for 5–15 minutes: TradingView loads only a few days of " + gsvTfMins + "-minute candles, too few for a record" : ""
// One step row: the mark, a detail, and "● required" (every step of the sequence is required).
f_gsvStep(int r, string name, int s, string detail) =>
    f_gsvRow(r, name, f_gsvMark(s) + (detail == "" ? "" : " · " + detail) + "  ● required", gsvInk, f_gsvTone(s))

f_gsvDrawDesk() =>
    table.clear(gsvDesk, 0, 0, 1, 39)
    if gsvDeskPos != "Off"
        if gsvOff == 1
            table.cell(gsvDesk, 0, 0, "", height = 14, bgcolor = na)
            table.cell(gsvDesk, 1, 0, "", height = 14, bgcolor = na)
        bool full = gsvRows == "Full"
        bool inPlan = gsP.dir != 0
        int st = gsS.state
        // Step states: 1 met · 0 not met · -1 no data · -3 waiting.
        int sWin = inPlan or st > 0 ? 1 : gsWinNow != "" ? 1 : 0
        int sPool = inPlan or st > 0 ? 1 : gsvFresh > 0 ? 1 : 0
        int sSweep = inPlan or st >= 2 ? 1 : st == 1 ? -3 : -3
        int sGap = inPlan or st >= 2 ? 1 : -3
        int sFlip = inPlan or st == 3 ? 1 : -3
        int met = (sWin == 1 ? 1 : 0) + (sPool == 1 ? 1 : 0) + (sSweep == 1 ? 1 : 0) + (sGap == 1 ? 1 : 0) + (sFlip == 1 ? 1 : 0)
        f_gsvWide(0, "GOLD SWEEP DESK · " + syminfo.ticker + " · " + timeframe.period + (GS_IS_STRATEGY ? " · STRATEGY LAB" : ""), gsvMuted, false, "Gold Sweep Desk " + GS_VERSION + " · a paper reference decided on closed bars, New York time." + (GS_IS_STRATEGY ? " The Strategy Tester shows TradingView's fills of the same plans." : "") + " Fills at your broker can differ.")
        f_gsvWide(1, gsvState, gsvTone, true, "Pools → raid → sweep → flip → plan → result.")
        f_gsvWide(2, f_gsvWrap(gsvReason, 58), gsvInk, false, "")
        f_gsvWide(3, gsvRib, gsvMuted, false, "01 fresh pools · 02 a raid and a close back inside · 03 the gap flips · 04 the plan · 05 its result")
        f_gsvWide(4, "STEPS" + (gsvDir != 0 ? " · for a " + f_gsvSide(gsvDir) : "") + " · " + str.tostring(met) + " of 5 required met", gsvMuted, false, "")
        f_gsvStep(5, "Window", sWin, inPlan or st > 0 ? (inPlan ? gsP.window : gsS.window) : gsWinNow != "" ? gsvWinTxt + " · " + f_gsvLeft(gsvWinEnd - gsHm) : "closed · next " + f_gsvNextWin(gsHm))
        f_gsvStep(6, "Fresh pool", sPool, inPlan ? gsP.pool : st > 0 ? gsS.pool : str.tostring(gsvFresh) + " of " + str.tostring(gsvPoolsToday) + " today")
        f_gsvStep(7, "Sweep · close back inside", sSweep, inPlan ? gsP.pool + " · extreme " + f_gsvPx(gsP.extreme) : st >= 2 ? gsS.pool + " · extreme " + f_gsvPx(gsS.extreme) : st == 1 ? "raid under way" : "")
        f_gsvStep(8, "Opposing gap", sGap, inPlan ? f_gsvPx(gsP.gapB) + "–" + f_gsvPx(gsP.gapT) : st >= 2 ? f_gsvPx(gsS.gapB) + "–" + f_gsvPx(gsS.gapT) : "")
        f_gsvStep(9, "Flip close ≥ " + str.tostring(gsMinLeg, "0.0#") + " ATR from the extreme", sFlip, inPlan ? f_gsvAt(gsP.entryTime) : st == 3 ? "done" : "")
        int r = 10
        if gsvNearUp != "" or gsvNearDn != ""
            f_gsvRow(r, "Nearest fresh", (gsvNearUp != "" ? "▲ " + gsvNearUp : "") + (gsvNearUp != "" and gsvNearDn != "" ? "\n" : "") + (gsvNearDn != "" ? "▼ " + gsvNearDn : ""), gsvMuted, gsvGold)
            r += 1
        if full
            for p in gsPools
                if r < 24
                    f_gsvRow(r, "  " + p.name, f_gsvPx(p.price) + (p.fresh ? " · fresh" : " · taken"), gsvMuted, p.fresh ? gsvGold : gsvGrey)
                    r += 1
        if inPlan
            f_gsvWide(r, "PLAN · " + f_gsvSide(gsP.dir) + " · " + gsP.how + " · frozen at entry", gsvMuted, false, "Frozen at entry.")
            f_gsvRow(r + 1, "Entry", f_gsvPx(gsP.entry) + " · " + str.tostring(bar_index - gsP.entryBar) + " bars ago", gsvMuted, gsvGold)
            f_gsvRow(r + 2, "Stop · 1R", f_gsvPx(gsP.stop) + " · " + str.tostring(math.abs(close - gsP.stop), format.mintick) + " away", gsvMuted, gsvDown)
            f_gsvRow(r + 3, "1R", f_gsvPx(gsP.tp1) + (gsP.tp1Hit ? " ✓" : " · " + str.tostring(math.abs(gsP.tp1 - close), format.mintick) + " away"), gsvMuted, gsvUp)
            f_gsvRow(r + 4, "Target · " + str.tostring(gsTargetR, "0.0#") + "R", f_gsvPx(gsP.target) + " · " + str.tostring(math.abs(gsP.target - close), format.mintick) + " away", gsvMuted, gsvUp)
            r += 5
        else
            f_gsvWide(r, f_gsvWrap("PLAN · " + gsvPlan, 58), gsvMuted, false, "")
            r += 1
        if gsTx.log != ""
            f_gsvWide(r, f_gsvWrap("TODAY " + gsTx.log, 58), gsvInk, false, "New York times.")
            r += 1
        string counts = "THIS CHART " + str.tostring(gsSt.raids) + " raids · " + str.tostring(gsSt.sweeps) + " sweeps · " + str.tostring(gsSt.flips) + " flips · " + (gsSt.plans == 0 ? "no closed plan yet" : str.tostring(gsSt.plans) + " plans: target " + str.tostring(gsSt.nTarget) + " · stop " + str.tostring(gsSt.nStop) + " · time " + str.tostring(gsSt.nTime) + " · reached 1R " + str.tostring(gsSt.nTp1))
        f_gsvWide(r, f_gsvWrap(counts, 58), gsvInk, false, "Counts of this chart's history. History on this chart, not a forecast.")
        r += 1
        if full
            string avgTxt = gsSt.plans == 0 ? "Average: needs a closed plan" : "Average " + f_gsvR(gsSt.sumR / gsSt.plans) + " over " + str.tostring(gsSt.plans) + " plans after an estimated " + str.tostring(gsCost, "0.00") + " round trip" + (gsSt.plans >= gsPctMin ? " · " + str.tostring(math.round(100.0 * gsSt.wins / gsSt.plans)) + "% closed above 0R" : "")
            f_gsvWide(r, f_gsvWrap(avgTxt, 58), gsvMuted, false, "Net R after the estimated cost in 04. A percentage appears only from " + str.tostring(gsPctMin) + " closed plans.")
            string ended = "Ended before a plan: held " + str.tostring(gsSt.held) + " · no gap " + str.tostring(gsSt.noGap) + " · sweep failed " + str.tostring(gsSt.failed) + " · no flip " + str.tostring(gsSt.noFlip) + " · refused " + str.tostring(gsSt.noEntry)
            f_gsvWide(r + 1, f_gsvWrap(ended, 58), gsvMuted, false, "")
            r += 2
        if gsvTfNote != ""
            f_gsvWide(r, f_gsvWrap(gsvTfNote, 58), gsvGold, false, "The rule's windows and its 16:45 exit are set in minutes of the New York day.")
            r += 1
        f_gsvWide(r, "Rules, not odds · history, not a forecast · ProEA Lab", gsvMuted, false, "")

f_gsvDrawPilot() =>
    table.clear(gsvPilotT, 0, 0, 0, 6)
    if gsvPilot != "Off"
        string why = "Above an old high and below an old low sit other traders' stops. A raid through such a level that closes back inside took that liquidity without accepting the new price. The flip, a close through the nearest opposing gap, is the sign that the move has turned; the sweep's extreme is where the idea is wrong."
        string limits = "A rule, not a forecast. The pools are price levels, not an order book. Results are this chart's history after an estimated " + str.tostring(gsCost, "0.00") + " round trip; fills at your broker can differ."
        int o = gsvPOff
        if o == 1
            table.cell(gsvPilotT, 0, 0, "", height = 14, bgcolor = na)
        table.cell(gsvPilotT, 0, 0 + o, "CO-PILOT", text_color = gsvMuted, bgcolor = gsvPanel, text_size = size.tiny, text_halign = text.align_left)
        table.cell(gsvPilotT, 0, 1 + o, f_gsvWrap("NOW · " + gsvNow, 60), text_color = gsvInk, bgcolor = gsvPanel, text_size = gsvSz, text_halign = text.align_left)
        if gsvPilot == "Standard"
            table.cell(gsvPilotT, 0, 2 + o, f_gsvWrap("WHY · " + why, 60), text_color = gsvInk, bgcolor = gsvPanel, text_size = gsvSz, text_halign = text.align_left)
        table.cell(gsvPilotT, 0, 3 + o, f_gsvWrap("PLAN · " + gsvPlan, 60), text_color = gsvInk, bgcolor = gsvPanel, text_size = gsvSz, text_halign = text.align_left)
        if gsvPilot == "Standard"
            table.cell(gsvPilotT, 0, 4 + o, f_gsvWrap("LIMITS · " + limits, 60), text_color = gsvMuted, bgcolor = gsvPanel, text_size = gsvSz, text_halign = text.align_left)
        if gsvPilotCorner == "Bottom left" or gsvPilotCorner == "Bottom right"
            table.cell(gsvPilotT, 0, 6, "", height = 5, bgcolor = na)

// ── chart layers: bounded handles, never further back than the history buffer (max_bars_back = 2000)
var array<box> gsvHB = array.new<box>()
var array<line> gsvHL = array.new<line>()
var array<label> gsvHT = array.new<label>()
var array<box> gsvLB = array.new<box>()
var array<line> gsvLL = array.new<line>()
var array<label> gsvLT = array.new<label>()
f_gsvClear(array<box> bs, array<line> ls, array<label> ts) =>
    for b in bs
        box.delete(b)
    for l in ls
        line.delete(l)
    for x in ts
        label.delete(x)
    array.clear(bs)
    array.clear(ls)
    array.clear(ts)
int gsvTfMin = math.max(1, int(timeframe.in_seconds() / 60))

// Short names on the chart; the desk and the tooltips use the full ones.
f_gsvShort(string name) =>
    name == "Asia high" ? "ASIA H" : name == "Asia low" ? "ASIA L" : name == "London high" ? "LDN H" : name == "London low" ? "LDN L" : name
// A pool's tag sits where its line ends: the candle that took it, or just right of the last candle while fresh.
f_gsvTagX(GSPool p) =>
    na(p.takenBar) ? bar_index + 3 : math.max(p.takenBar, math.max(p.bornBar, bar_index - 1500))
// A tag is about eight candles wide: tags within 12 candles and 1 ATR of each other would print over each other,
// so the upper one moves above its line and the lower one below it (a middle one of three stays on its line).
f_gsvPlace(int pi, int oldestDay, array<int> tagDays) =>
    GSPool p = array.get(gsPoolLog, pi)
    int x = f_gsvTagX(p)
    float near = nz(gsAtr, 0)
    bool above = false
    bool below = false
    for [qi, q] in gsPoolLog
        if qi != pi and q.day >= oldestDay and q.bornBar >= bar_index - 1500 and array.includes(tagDays, q.day) and math.abs(f_gsvTagX(q) - x) <= 12 and math.abs(q.price - p.price) <= near
            if q.price > p.price or (q.price == p.price and qi > pi)
                above := true
            else
                below := true
    below and not above ? label.style_label_lower_left : above and not below ? label.style_label_upper_left : label.style_label_left
f_gsvDrawPool(GSPool p, bool today, string place) =>
    int x1 = math.max(p.bornBar, bar_index - 1500)
    int x2 = f_gsvTagX(p)
    bool live = today and p.fresh
    color c = live ? gsvGold : gsvGrey
    array.push(gsvHL, line.new(x1, p.price, x2, p.price, color = color.new(c, live ? 10 : today ? 35 : 60), style = live ? line.style_solid : line.style_dotted, width = live ? 2 : 1))
    if today
        array.push(gsvHT, label.new(x2, p.price, f_gsvShort(p.name) + (p.fresh ? " " + f_gsvPx(p.price) : " ✕"), style = place, color = color.new(#10151F, 20), textcolor = color.new(c, p.fresh ? 0 : 20), size = size.small, tooltip = p.name + " " + f_gsvPx(p.price) + (p.fresh ? " · fresh: no bar has traded through it yet" : " · taken")))

f_gsvDrawSession(GSPool hi, GSPool lo, int mins, color c, string name) =>
    int x2 = hi.bornBar - 1
    int x1 = math.max(x2 - int(mins / gsvTfMin) + 1, bar_index - 1500)
    if x2 > x1
        array.push(gsvHB, box.new(x1, hi.price, x2, lo.price, border_color = color.new(c, 70), bgcolor = color.new(c, 92), text = name, text_color = color.new(c, 30), text_size = size.small, text_halign = text.align_left, text_valign = text.align_top))

f_gsvDrawPlan(GSPlan pl, bool isOpen) =>
    int xa = math.max(pl.entryBar, bar_index - 1500)
    int xb = isOpen ? bar_index + 2 : math.max(pl.exitBar, xa)
    int xg = math.max(pl.gapBar - 2, bar_index - 1500)
    if not na(pl.gapB) and pl.gapBar >= bar_index - 1500
        array.push(gsvHB, box.new(xg, pl.gapT, math.max(pl.flipBar, xg), pl.gapB, border_color = color.new(gsvGold, 55), bgcolor = color.new(gsvGold, 85), text = "FLIP", text_color = color.new(gsvGold, 20), text_size = size.tiny, text_halign = text.align_right, text_valign = text.align_center))
    if pl.sweepBar >= bar_index - 1500
        array.push(gsvHT, label.new(pl.sweepBar, pl.extreme, "SWEPT " + pl.pool, style = pl.dir == -1 ? label.style_label_down : label.style_label_up, color = color.new(gsvGold, 20), textcolor = #0C131D, size = size.small, tooltip = "Raid of the " + pl.pool + " and a close back inside · extreme " + f_gsvPx(pl.extreme)))
    if gsvZones
        array.push(gsvHB, box.new(xa, math.max(pl.entry, pl.stop), xb, math.min(pl.entry, pl.stop), border_color = color.new(gsvDown, 100), bgcolor = color.new(gsvDown, isOpen ? 84 : 93)))
        array.push(gsvHB, box.new(xa, math.max(pl.entry, pl.target), xb, math.min(pl.entry, pl.target), border_color = color.new(gsvUp, 100), bgcolor = color.new(gsvUp, isOpen ? 84 : 93)))
    array.push(gsvHL, line.new(xa, pl.tp1, xb, pl.tp1, color = color.new(gsvUp, isOpen ? 35 : 65), style = line.style_dashed))
    array.push(gsvHL, line.new(xa, pl.entry, xb, pl.entry, color = color.new(gsvGold, isOpen ? 10 : 50)))
    if pl.entryBar >= bar_index - 1500
        array.push(gsvHT, label.new(pl.entryBar, pl.entry, (pl.dir == 1 ? "▲ LONG " : "▼ SHORT ") + f_gsvPx(pl.entry), style = pl.dir == 1 ? label.style_label_up : label.style_label_down, color = color.new(pl.dir == 1 ? gsvUp : gsvDown, 15), textcolor = #0C131D, size = size.small, tooltip = pl.how + " after the " + pl.pool + " sweep · stop " + f_gsvPx(pl.stop) + " · 1R " + f_gsvPx(pl.tp1) + " · target " + f_gsvPx(pl.target)))
    if not isOpen and pl.exitBar >= bar_index - 1500
        bool above = pl.exitPrice >= pl.entry
        color c = pl.netR > 0.05 ? gsvUp : pl.netR < -0.05 ? gsvDown : gsvGrey
        array.push(gsvHT, label.new(pl.exitBar, pl.exitPrice, f_gsvEndMark(pl.ending, pl.netR) + " " + f_gsvEnding(pl.ending) + " " + f_gsvR(pl.netR), style = above ? label.style_label_down : label.style_label_up, color = color.new(c, 15), textcolor = #0C131D, size = size.small, tooltip = "Exit " + f_gsvPx(pl.exitPrice) + " · " + f_gsvR(pl.grossR) + " before costs, " + f_gsvR(pl.netR) + " after the estimated cost"))

f_gsvDrawHistory() =>
    f_gsvClear(gsvHB, gsvHL, gsvHT)
    // The trading days to draw: the latest gsvDays distinct day ids in the pool log.
    int oldestDay = gsDay
    int seen = 0
    int lastDay = -1
    int i = array.size(gsPoolLog) - 1
    while i >= 0 and seen < gsvDays
        GSPool p = array.get(gsPoolLog, i)
        if p.day != lastDay
            seen += 1
            lastDay := p.day
            oldestDay := p.day
        i -= 1
    // Pool names are written for today and for every drawn day that had a plan.
    array<int> tagDays = array.from(gsDay)
    for pl in gsDone
        if pl.day >= oldestDay
            array.push(tagDays, pl.day)
    GSPool asiaHi = na
    GSPool lonHi = na
    for [pi, p] in gsPoolLog
        if p.day >= oldestDay and p.bornBar >= bar_index - 1500
            if gsvPools
                bool tagged = array.includes(tagDays, p.day)
                f_gsvDrawPool(p, tagged, tagged ? f_gsvPlace(pi, oldestDay, tagDays) : label.style_label_left)
            if gsvSessions and p.name == "Asia high"
                asiaHi := p
            if gsvSessions and p.name == "Asia low" and not na(asiaHi)
                f_gsvDrawSession(asiaHi, p, 240, gsvAsia, "ASIA")
            if gsvSessions and p.name == "London high"
                lonHi := p
            if gsvSessions and p.name == "London low" and not na(lonHi)
                f_gsvDrawSession(lonHi, p, 180, gsvGold, "LONDON")
    int j = array.size(gsDone) - 1
    while j >= 0
        GSPlan pl = array.get(gsDone, j)
        if pl.day < oldestDay or bar_index - pl.entryBar >= 1500
            break
        f_gsvDrawPlan(pl, false)
        j -= 1
    if gsP.dir != 0 and bar_index - gsP.entryBar < 1500
        f_gsvDrawPlan(gsP, true)
    if gsvMisses
        int k = array.size(gsEvBar) - 1
        int marks = 0
        while k >= 0 and marks < 40
            int eb = array.get(gsEvBar, k)
            if bar_index - eb >= 1500
                break
            string w = array.get(gsEvWhat, k)
            if w == "HELD" or w == "NO GAP" or w == "SWEEP FAILED" or w == "NO FLIP" or w == "NO RETEST" or str.startswith(w, "NO ENTRY")
                array.push(gsvHT, label.new(eb, array.get(gsEvPx, k), "◌", style = label.style_label_center, color = color.new(#000000, 100), textcolor = color.new(gsvGrey, 10), size = size.tiny, tooltip = str.lower(w) + " · the setup ended without a plan"))
                marks += 1
            k -= 1

f_gsvDrawLive() =>
    f_gsvClear(gsvLB, gsvLL, gsvLT)
    if gsP.dir == 0 and gsS.state != 0
        int x1 = math.max(gsS.raidBar, bar_index - 1500)
        color c = gsS.dir == -1 ? gsvDown : gsvUp
        array.push(gsvLL, line.new(x1, gsS.extreme, bar_index + 3, gsS.extreme, color = color.new(c, 20), width = 2))
        array.push(gsvLT, label.new(bar_index + 3, gsS.extreme, (gsS.state == 1 ? "RAID " : "SWEPT ") + gsS.pool + " · extreme " + f_gsvPx(gsS.extreme), style = label.style_label_left, color = color.new(#10151F, 10), textcolor = c, size = size.small))
        if gsS.state >= 2 and not na(gsS.gapB)
            int xg = math.max(gsS.gapBar - 2, bar_index - 1500)
            array.push(gsvLB, box.new(xg, gsS.gapT, bar_index + 3, gsS.gapB, border_color = color.new(gsvGold, 20), border_style = line.style_dashed, bgcolor = color.new(gsvGold, 85), text = gsS.state == 2 ? "GAP TO FLIP" : "FLIPPED · RETEST", text_color = color.new(gsvGold, 10), text_size = size.tiny, text_halign = text.align_right, text_valign = text.align_center))
        if gsS.state == 3
            array.push(gsvLL, line.new(x1, gsS.stop, bar_index + 3, gsS.stop, color = color.new(gsvDown, 30), style = line.style_dashed))

// Draw on the last historical bar and on every realtime execution. A strategy never runs on the forming bar, so
// barstate.islast alone would leave the Strategy Lab blank while the market is open.
if barstate.islastconfirmedhistory or barstate.isrealtime
    if barstate.islastconfirmedhistory or barstate.isconfirmed
        f_gsvDrawHistory()
    f_gsvDrawLive()
    f_gsvDrawDesk()
    f_gsvDrawPilot()

barcolor(gsvTint and gsP.dir != 0 ? color.new(gsP.dir == 1 ? gsvUp : gsvDown, 15) : na, title = "Plan tint")

//@version=6
// Gold Sweep Desk 1.1.0 · MIT · © 2026 ProEA Lab · built for r/pinescript
// Gold liquidity as a desk: the prior-day, Asia and London highs and lows, their sweeps, the flip and the plan, in words.
// Every clock is New York time; bars while spot gold is closed are skipped, so spot and 24/7 feeds agree.
// Decisions happen on closed bars. The record is this chart's history after an estimated cost, not a forecast.
// Rules: docs/engine-contract.md in the release · https://proea.app/en/free/gold-sweep-desk
// License: MIT. Share it freely; keep this header.
strategy("Gold Sweep Desk · Strategy Lab", "GS Lab", overlay = true, behind_chart = false, max_lines_count = 500, max_labels_count = 500, max_boxes_count = 500, max_bars_back = 2000, initial_capital = 100000, currency = currency.USD, pyramiding = 0, margin_long = 100, margin_short = 100, commission_type = strategy.commission.cash_per_contract, commission_value = 0.20, slippage = 0, process_orders_on_close = true, calc_on_every_tick = false)
const string GS_VERSION = "1.1.0"
const bool GS_IS_STRATEGY = true

// ═══ ENGINE · core.pinefrag ═════════════════════════════════════════════════════════════════════════════════════
// The engine decides; the renderer (visuals.pinefrag) only reads. Every engine name starts with "gs" and a
// capital letter; tests/display.test.mjs refuses any renderer line that assigns one. The rules are written in
// docs/engine-contract.md; tests/reference/engine.mjs is the independent reference.
//
//   ① SWEEP  a bar in an entry window trades through a fresh pool (prior day, Asia or London high/low) and a close
//            comes back inside it within a few bars.
//   ② FLIP   a close goes through the nearest opposing fair value gap: the gap inverts.
//   ③ PLAN   entry at that close (or at a later close back inside the gap); stop beyond the sweep's extreme; target
//            in R; flat at the time exit. Stop first when a bar reaches both.
// Every clock is New York time by the bar's open. Bars while spot gold is closed (Friday 17:00 → Sunday 18:00 and
// the daily 17:00–18:00 break) are skipped entirely, so a 24/7 feed and a spot feed give the same bar stream.
// Decisions happen on closed bars only. A plan's geometry is frozen at entry.

string gsG1 = "01 · Pools and windows"
bool gsPoolPd = input.bool(true, "Prior day high / low", group = gsG1, tooltip = "The previous trading day's high and low. Gold's day runs 18:00 → 17:00 New York.")
bool gsPoolAsia = input.bool(true, "Asia high / low · 20:00–24:00", group = gsG1, tooltip = "The range of the bars opening 20:00–24:00 New York; a pool from the first bar after midnight.")
bool gsPoolLon = input.bool(true, "London high / low · 02:00–05:00", group = gsG1, tooltip = "The range of the bars opening 02:00–05:00 New York; a pool from the first bar after 05:00.")
string gsWindows = input.string("London + New York", "Entry windows", options = ["London + New York", "Continuous 01:00–11:00"], group = gsG1, tooltip = "A setup can only start on a bar that opens inside a window (New York time). The pools are used up by any bar that trades through them, window or not.")
bool gsWinLon = input.bool(true, "  London 02:00–05:00", group = gsG1)
bool gsWinNy = input.bool(true, "  New York 07:00–11:00", group = gsG1)

string gsG2 = "02 · Sweep and flip"
float gsDepth = input.float(0.05, "Sweep depth · ATR beyond the level", minval = 0, maxval = 5, step = 0.05, group = gsG2, tooltip = "The raid must reach at least this far beyond the outermost pool it takes, in ATR(14).")
int gsReclaim = input.int(3, "Close back inside within · bars", minval = 0, maxval = 20, group = gsG2, tooltip = "The close back inside the swept level may come on the raid bar or on this many bars after it. Otherwise price was accepted beyond the level (HELD).")
string gsFailOn = input.string("A close back beyond the level", "A sweep fails on", options = ["A close back beyond the level", "Any new extreme"], group = gsG2, tooltip = "While the flip is awaited: a close back beyond the swept level ends the setup, and a new wick only moves the extreme (and the stop) further; or any new extreme ends it.")
string gsConfirm = input.string("FVG flip", "Confirmation", options = ["FVG flip", "Close back only"], group = gsG2, tooltip = "FVG flip: a close through the nearest opposing fair value gap. Close back only: the sweep's own close is the trigger.")
int gsLookback = input.int(30, "Gap born within · bars before the sweep", minval = 3, maxval = 200, group = gsG2)
int gsFlipBars = input.int(12, "Flip within · bars after the sweep", minval = 0, maxval = 100, group = gsG2)
float gsMinLeg = input.float(1.0, "Leg from the extreme · at least ATR", minval = 0, maxval = 10, step = 0.1, group = gsG2, tooltip = "The flip close must be at least this far from the sweep's extreme.")

string gsG3 = "03 · Plan"
string gsEntryMode = input.string("Flip close", "Entry", options = ["Flip close", "Retest close"], group = gsG3, tooltip = "Flip close: the flip's close is the entry. Retest close: after the flip, the first close back inside the gap within the retest bars.")
int gsRetestBars = input.int(12, "  Retest within · bars", minval = 1, maxval = 100, group = gsG3)
float gsBuffer = input.float(0.1, "Stop buffer · ATR beyond the extreme", minval = 0, maxval = 3, step = 0.05, group = gsG3)
float gsMaxStop = input.float(6.0, "Skip if the stop is wider than · ATR", minval = 0.5, maxval = 50, step = 0.5, group = gsG3)
float gsTargetR = input.float(2.0, "Target · R", minval = 0.5, maxval = 20, step = 0.5, group = gsG3, tooltip = "A design choice, not a tested setting. 1R is the distance from the entry to the stop; the 1R milestone is recorded on the way.")
string gsExitAt = input.string("16:45", "Flat at · HH:MM New York", group = gsG3, tooltip = "An open plan closes at the close of the bar that ends at or after this time; no entry on or after it. Gold's daily break starts at 17:00.")
string gsSide = input.string("Both", "Direction", options = ["Both", "Long only", "Short only"], group = gsG3)

string gsG4 = "04 · Costs and record"
float gsCost = input.float(0.40, "Estimated round-trip cost · price", minval = 0, step = 0.05, group = gsG4, tooltip = "Spread plus slippage for entry and exit together, in the chart's price (0.40 = 40 cents an ounce on spot gold). Every R on the desk is after this estimate. Set your own broker's.")
int gsPctMin = input.int(20, "Show percentages from N closed plans", minval = 5, maxval = 500, group = gsG4, tooltip = "Below this many closed plans the desk shows counts only: a percentage of a few plans says little.")

// ── clock: New York, by the bar's open
string gsTz = "America/New_York"
float gsTick = syminfo.mintick
bool gsClosed = barstate.isconfirmed
f_gsClock(string hm) =>
    array<string> parts = str.split(hm, ":")
    int out = -1
    if array.size(parts) == 2
        float h = str.tonumber(array.get(parts, 0))
        float m = str.tonumber(array.get(parts, 1))
        if not na(h) and not na(m)
            out := int(h) * 60 + int(m)
    out
// A trading day starts at 18:00: its id is the New York date six hours later.
f_gsDayId(int t) =>
    int t6 = t + 6 * 3600000
    year(t6, "America/New_York") * 10000 + month(t6, "America/New_York") * 100 + dayofmonth(t6, "America/New_York")
int gsExitMin = f_gsClock(gsExitAt) < 0 ? 16 * 60 + 45 : f_gsClock(gsExitAt)
int gsDow = dayofweek(time, gsTz)
int gsHm = hour(time, gsTz) * 60 + minute(time, gsTz)
int gsDayNow = f_gsDayId(time)
int gsCloseHm = hour(time_close, gsTz) * 60 + minute(time_close, gsTz)
int gsCloseDay = f_gsDayId(time_close)
// dayofweek: 1 = Sunday … 7 = Saturday.
bool gsGoldShut = gsDow == dayofweek.saturday or (gsDow == dayofweek.sunday and gsHm < 1080) or (gsDow == dayofweek.friday and gsHm >= 1020) or (gsHm >= 1020 and gsHm < 1080)
bool gsInAsia = gsHm >= 1200
bool gsInLon = gsHm >= 120 and gsHm < 300
string gsWinNow = gsWindows == "Continuous 01:00–11:00" ? (gsHm >= 60 and gsHm < 660 ? (gsHm < 420 ? "London" : "New York") : "") : (gsWinLon and gsHm >= 120 and gsHm < 300) ? "London" : (gsWinNy and gsHm >= 420 and gsHm < 660) ? "New York" : ""
bool gsAvailable = chart.is_standard and timeframe.isintraday and timeframe.in_seconds() <= 3600
string gsUnavailable = gsAvailable ? "" : not chart.is_standard ? "standard candles needed" : "an intraday chart of 1 hour or less is needed"

// ── state
type GSPool
    string name
    int side
    float price
    bool fresh = true
    int bornBar = na
    int takenBar = na
    int day = 0

type GSGap
    int dir
    int born
    int bornBar
    float bottom
    float top
    bool killed = false

// The setup in progress: 0 idle · 1 raid · 2 swept · 3 flipped (waiting for the retest).
type GSSetup
    int state = 0
    int dir = 0
    string window = ""
    float ref = na
    string pool = ""
    string pools = ""
    int poolsN = 0
    float extreme = na
    float depthAtr = na
    int raidN = na
    int raidBar = na
    int sweepN = na
    int sweepBar = na
    float gapB = na
    float gapT = na
    int gapBar = na
    float gapAtr = na
    int flipN = na
    int flipBar = na
    float legAtr = na
    float atrFlip = na
    float stop = na

// The plan (dir 0 = none). Its geometry is frozen at entry; a copy goes to gsDone when it ends.
type GSPlan
    int dir = 0
    int day = 0
    string window = ""
    string pool = ""
    int poolsN = 0
    float depthAtr = na
    float legAtr = na
    float gapAtr = na
    float riskAtr = na
    int raidBar = na
    int sweepBar = na
    int flipBar = na
    int gapBar = na
    int entryN = na
    int entryBar = na
    int entryTime = na
    string how = ""
    float extreme = na
    float gapB = na
    float gapT = na
    float entry = na
    float stop = na
    float risk = na
    float tp1 = na
    float target = na
    bool tp1Hit = false
    int tp1Bar = na
    int exitBar = na
    int exitTime = na
    float exitPrice = na
    string ending = ""
    float grossR = na
    float netR = na

type GSStat
    int plans = 0
    int wins = 0
    float sumR = 0.0
    int nTarget = 0
    int nStop = 0
    int nTime = 0
    int nTp1 = 0
    int raids = 0
    int sweeps = 0
    int flips = 0
    int held = 0
    int noGap = 0
    int failed = 0
    int noFlip = 0
    int noEntry = 0

// What happened on this bar.
type GSEv
    int raid = 0
    int sweep = 0
    int flip = 0
    int entry = 0
    bool exit = false
    string why = ""
    float r = na
    int exitDir = 0
    bool tp1 = false
    string stopped = ""
    string pool = ""

var GSSetup gsS = GSSetup.new()
var GSPlan gsP = GSPlan.new()
var GSStat gsSt = GSStat.new()
var array<GSPool> gsPools = array.new<GSPool>()
var array<GSPool> gsPoolLog = array.new<GSPool>()
var array<GSGap> gsGaps = array.new<GSGap>()
var array<GSPlan> gsDone = array.new<GSPlan>()
var array<int> gsEvBar = array.new<int>()
var array<string> gsEvWhat = array.new<string>()
var array<float> gsEvPx = array.new<float>()
GSEv gsEv = GSEv.new()
var float gsAtr = na
var float gsTrSum = 0.0
var int gsTrN = 0
var float gsPrevC = na
var int gsN = -1
var int gsDay = 0
var float gsDayH = na
var float gsDayL = na
var float gsAsiaH = na
var float gsAsiaL = na
var bool gsAsiaDone = false
var float gsLonH = na
var float gsLonL = na
var bool gsLonDone = false
var int gsRestN = -1
var float gsH1 = na
var float gsL1 = na
var int gsD1 = 0
var float gsH2 = na
var float gsL2 = na
var int gsD2 = 0
// The day's story for the desk, in words (a field, so the helpers below can extend it).
type GSText
    string log = ""
var GSText gsTx = GSText.new()

f_gsRText(float v) =>
    (v < 0 ? "−" : "+") + str.tostring(math.abs(v), "0.0") + "R"
f_gsHhmm() =>
    str.tostring(hour(time, "America/New_York"), "00") + ":" + str.tostring(minute(time, "America/New_York"), "00")
f_gsLogAdd(string what) =>
    gsTx.log := gsTx.log + (gsTx.log == "" ? "" : " · ") + f_gsHhmm() + what
f_gsNote(string what) =>
    array.push(gsEvBar, bar_index)
    array.push(gsEvWhat, what)
    array.push(gsEvPx, close)
    if array.size(gsEvBar) > 200
        array.shift(gsEvBar)
        array.shift(gsEvWhat)
        array.shift(gsEvPx)
f_gsPoolNew(string name, int side, float price, int day) =>
    GSPool p = GSPool.new(name, side, price, true, bar_index, na, day)
    array.push(gsPools, p)
    array.push(gsPoolLog, p)
    if array.size(gsPoolLog) > 120
        array.shift(gsPoolLog)
f_gsReset(string why) =>
    // A setup ends without a plan: remembered for the desk and the alerts.
    gsEv.stopped := why
    gsS.state := 0
    gsS.dir := 0
    if why == "HELD"
        gsSt.held += 1
    else if why == "NO GAP"
        gsSt.noGap += 1
    else if why == "SWEEP FAILED"
        gsSt.failed += 1
    else if why == "NO FLIP" or why == "NO RETEST"
        gsSt.noFlip += 1
    else
        gsSt.noEntry += 1
    f_gsNote(why)
    f_gsLogAdd(" " + str.lower(why))

// Entry at this close, or a refusal. Returns true when a plan starts.
f_gsEnter(float px, string how) =>
    int d = gsS.dir
    float risk = (px - gsS.stop) * d
    bool ok = false
    if not (risk > 0)
        f_gsReset("NO ENTRY · stop not beyond entry")
    else if risk > gsMaxStop * gsS.atrFlip
        f_gsReset("NO ENTRY · stop too wide")
    else if not (gsCloseDay == gsDayNow and gsCloseHm < gsExitMin)
        f_gsReset("NO ENTRY · too late in the day")
    else
        ok := true
        gsP.dir := d
        gsP.day := gsDayNow
        gsP.window := gsS.window
        gsP.pool := gsS.pool
        gsP.poolsN := gsS.poolsN
        gsP.depthAtr := gsS.depthAtr
        gsP.legAtr := gsS.legAtr
        gsP.gapAtr := gsS.gapAtr
        gsP.riskAtr := risk / gsS.atrFlip
        gsP.raidBar := gsS.raidBar
        gsP.sweepBar := gsS.sweepBar
        gsP.flipBar := gsS.flipBar
        gsP.gapBar := gsS.gapBar
        gsP.entryN := gsN
        gsP.entryBar := bar_index
        gsP.entryTime := time
        gsP.how := how
        gsP.extreme := gsS.extreme
        gsP.gapB := gsS.gapB
        gsP.gapT := gsS.gapT
        gsP.entry := px
        gsP.stop := gsS.stop
        gsP.risk := risk
        gsP.tp1 := px + d * risk
        gsP.target := px + d * gsTargetR * risk
        gsP.tp1Hit := false
        gsP.tp1Bar := na
        gsP.exitBar := na
        gsP.exitTime := na
        gsP.exitPrice := na
        gsP.ending := ""
        gsP.grossR := na
        gsP.netR := na
        gsS.state := 4
        gsEv.entry := d
        f_gsNote(d == 1 ? "ENTRY LONG" : "ENTRY SHORT")
        f_gsLogAdd((d == 1 ? " ▲ long " : " ▼ short ") + str.tostring(px, format.mintick))
    ok

// The flip on this bar, if the close goes through the gap far enough from the extreme.
f_gsFlip() =>
    int d = gsS.dir
    bool through = d == -1 ? close < gsS.gapB : close > gsS.gapT
    float leg = (gsS.extreme - close) * -d
    bool done = false
    if through and leg >= gsMinLeg * gsAtr
        done := true
        gsS.flipN := gsN
        gsS.flipBar := bar_index
        gsS.legAtr := leg / gsAtr
        gsS.atrFlip := gsAtr
        gsS.stop := d == -1 ? math.ceil((gsS.extreme + gsBuffer * gsAtr) / gsTick - 1e-9) * gsTick : math.floor((gsS.extreme - gsBuffer * gsAtr) / gsTick + 1e-9) * gsTick
        gsEv.flip := d
        gsSt.flips += 1
        f_gsNote("FLIP")
        f_gsLogAdd(" flip")
        if gsEntryMode == "Flip close"
            f_gsEnter(close, "flip close")
        else
            gsS.state := 3
    done

// The sweep on this bar: pick the gap to invert (or trigger at once with "Close back only").
f_gsSweep() =>
    gsS.sweepN := gsN
    gsS.sweepBar := bar_index
    gsEv.sweep := gsS.dir
    gsEv.pool := gsS.pool
    gsSt.sweeps += 1
    f_gsNote("SWEEP " + gsS.pool)
    f_gsLogAdd(" swept " + gsS.pool)
    if gsConfirm == "Close back only"
        gsS.legAtr := (gsS.extreme - close) * -gsS.dir / gsAtr
        gsS.atrFlip := gsAtr
        gsS.flipN := gsN
        gsS.flipBar := bar_index
        gsS.stop := gsS.dir == -1 ? math.ceil((gsS.extreme + gsBuffer * gsAtr) / gsTick - 1e-9) * gsTick : math.floor((gsS.extreme - gsBuffer * gsAtr) / gsTick + 1e-9) * gsTick
        f_gsEnter(close, "reclaim close")
    else
        int want = -gsS.dir
        GSGap best = na
        for g in gsGaps
            if g.dir == want and not g.killed and g.born >= gsN - gsLookback and g.born < gsN
                if na(best)
                    best := g
                else if want == 1 ? g.bottom > best.bottom : g.top < best.top
                    best := g
        if na(best)
            f_gsReset("NO GAP")
        else
            gsS.gapB := best.bottom
            gsS.gapT := best.top
            gsS.gapBar := best.bornBar
            gsS.gapAtr := (best.top - best.bottom) / gsAtr
            gsS.state := 2
            f_gsFlip()
    // The branches above return different types; the function returns the setup state.
    gsS.state

f_gsEnd(float px, string why) =>
    float gross = (px - gsP.entry) * gsP.dir / gsP.risk
    float net = gross - gsCost / gsP.risk
    gsP.exitBar := bar_index
    gsP.exitTime := time
    gsP.exitPrice := px
    gsP.ending := why
    gsP.grossR := gross
    gsP.netR := net

if gsClosed and gsAvailable and not gsGoldShut
    gsN += 1
    // (A) ATR over session bars, this bar included.
    float tr = na(gsPrevC) ? high - low : math.max(high - low, math.abs(high - gsPrevC), math.abs(low - gsPrevC))
    if gsTrN < 14
        gsTrSum += tr
        gsTrN += 1
        if gsTrN == 14
            gsAtr := gsTrSum / 14
    else
        gsAtr := (tr + 13 * gsAtr) / 14
    gsPrevC := close

    // (B) A new trading day: yesterday's range becomes the prior-day pools; the session pools start again.
    if gsDayNow != gsDay
        for p in gsPools
            if p.fresh
                p.takenBar := bar_index - 1
        array.clear(gsPools)
        if gsDay != 0 and gsPoolPd and not na(gsDayH)
            f_gsPoolNew("PDH", 1, gsDayH, gsDayNow)
            f_gsPoolNew("PDL", -1, gsDayL, gsDayNow)
        gsDay := gsDayNow
        gsDayH := na
        gsDayL := na
        gsAsiaH := na
        gsAsiaL := na
        gsAsiaDone := false
        gsLonH := na
        gsLonL := na
        gsLonDone := false
        gsTx.log := ""
    if not gsAsiaDone and not na(gsAsiaH) and not gsInAsia
        gsAsiaDone := true
        if gsPoolAsia
            f_gsPoolNew("Asia high", 1, gsAsiaH, gsDayNow)
            f_gsPoolNew("Asia low", -1, gsAsiaL, gsDayNow)
    if not gsLonDone and not na(gsLonH) and not gsInLon
        gsLonDone := true
        if gsPoolLon
            f_gsPoolNew("London high", 1, gsLonH, gsDayNow)
            f_gsPoolNew("London low", -1, gsLonL, gsDayNow)

    // (C) The open plan: a later day, stop first, target, then the time exit.
    if gsP.dir != 0 and gsN > gsP.entryN
        int d = gsP.dir
        bool stopHit = d == 1 ? low <= gsP.stop : high >= gsP.stop
        bool targetHit = d == 1 ? high >= gsP.target : low <= gsP.target
        bool lateDay = gsDayNow != gsP.day
        if lateDay
            f_gsEnd(open, "TIME")
        else if stopHit
            f_gsEnd((d == 1 ? open <= gsP.stop : open >= gsP.stop) ? open : gsP.stop, "STOP")
        else if targetHit
            f_gsEnd(gsP.target, "TARGET")
        else if gsCloseDay == gsP.day and gsCloseHm >= gsExitMin
            f_gsEnd(close, "TIME")
        if not gsP.tp1Hit and not stopHit and not lateDay and (d == 1 ? high >= gsP.tp1 : low <= gsP.tp1)
            gsP.tp1Hit := true
            gsP.tp1Bar := bar_index
            gsEv.tp1 := true
        if gsP.ending != ""
            gsEv.exit := true
            gsEv.why := gsP.ending
            gsEv.r := gsP.netR
            gsEv.exitDir := gsP.dir
            gsSt.plans += 1
            gsSt.wins += gsP.netR > 0 ? 1 : 0
            gsSt.sumR += gsP.netR
            gsSt.nTarget += gsP.ending == "TARGET" ? 1 : 0
            gsSt.nStop += gsP.ending == "STOP" ? 1 : 0
            gsSt.nTime += gsP.ending == "TIME" ? 1 : 0
            gsSt.nTp1 += gsP.tp1Hit ? 1 : 0
            f_gsNote(gsP.ending)
            f_gsLogAdd(" " + str.lower(gsP.ending) + " " + f_gsRText(gsP.netR))
            array.push(gsDone, gsP.copy())
            if array.size(gsDone) > 300
                array.shift(gsDone)
            gsP.dir := 0
            gsRestN := gsN
            gsS.state := 0
            gsS.dir := 0

    // (D) Pools this bar trades through are used up, whatever else happens.
    int penHN = 0
    int penLN = 0
    float penHMax = na
    float penLMin = na
    string penHName = ""
    string penLName = ""
    string penHAll = ""
    string penLAll = ""
    for p in gsPools
        if p.fresh and p.side == 1 and high > p.price
            p.fresh := false
            p.takenBar := bar_index
            penHN += 1
            penHAll += (penHAll == "" ? "" : " + ") + p.name
            if na(penHMax) or p.price > penHMax
                penHMax := p.price
                penHName := p.name
        else if p.fresh and p.side == -1 and low < p.price
            p.fresh := false
            p.takenBar := bar_index
            penLN += 1
            penLAll += (penLAll == "" ? "" : " + ") + p.name
            if na(penLMin) or p.price < penLMin
                penLMin := p.price
                penLName := p.name

    // (E) The setup: RAID → SWEPT → (FLIPPED →) plan.
    if gsP.dir == 0
        if gsS.state == 1
            int d = gsS.dir
            gsS.extreme := d == -1 ? math.max(gsS.extreme, high) : math.min(gsS.extreme, low)
            int moreN = d == -1 ? penHN : penLN
            if moreN > 0
                gsS.poolsN += moreN
                gsS.pools += " + " + (d == -1 ? penHAll : penLAll)
                float outer = d == -1 ? penHMax : penLMin
                if d == -1 ? outer > gsS.ref : outer < gsS.ref
                    gsS.ref := outer
                    gsS.pool := d == -1 ? penHName : penLName
            if d == -1 ? close < gsS.ref : close > gsS.ref
                f_gsSweep()
            else if gsN - gsS.raidN >= gsReclaim
                f_gsReset("HELD")
        else if gsS.state == 2
            int d = gsS.dir
            bool beyond = d == -1 ? high > gsS.extreme : low < gsS.extreme
            bool onClose = gsFailOn == "A close back beyond the level"
            if onClose and beyond
                gsS.extreme := d == -1 ? high : low
            if onClose ? (d == -1 ? close > gsS.ref : close < gsS.ref) : beyond
                f_gsReset("SWEEP FAILED")
            else if not f_gsFlip() and gsN - gsS.sweepN >= gsFlipBars
                f_gsReset("NO FLIP")
        else if gsS.state == 3
            int d = gsS.dir
            if d == -1 ? high >= gsS.stop : low <= gsS.stop
                f_gsReset("NO ENTRY · stop traded before the retest")
            else if close >= gsS.gapB and close <= gsS.gapT
                f_gsEnter(close, "retest close")
            else if gsN - gsS.flipN >= gsRetestBars
                f_gsReset("NO RETEST")
        else if gsS.state == 0 and gsN != gsRestN and not na(gsAtr) and gsTrN >= 14
            bool up = penHN > 0 and gsSide != "Long only"
            bool dn = penLN > 0 and gsSide != "Short only"
            if gsWinNow != "" and up != dn
                int d = up ? -1 : 1
                float outer = up ? penHMax : penLMin
                float depth = d == -1 ? high - outer : outer - low
                if depth >= gsDepth * gsAtr
                    gsS := GSSetup.new(1, d, gsWinNow, outer, up ? penHName : penLName, up ? penHAll : penLAll, up ? penHN : penLN, d == -1 ? high : low, depth / gsAtr, gsN, bar_index)
                    gsEv.raid := d
                    gsEv.pool := gsS.pool
                    gsSt.raids += 1
                    f_gsNote("RAID " + gsS.pool)
                    f_gsLogAdd(" raid " + gsS.pool)
                    if d == -1 ? close < gsS.ref : close > gsS.ref
                        f_gsSweep()

    // (F) Gaps: a close through a gap kills it; a gap completes on this bar (three bars of the same trading day).
    for g in gsGaps
        if not g.killed and g.born < gsN and (g.dir == 1 ? close < g.bottom : close > g.top)
            g.killed := true
    if gsN >= 2 and gsD2 == gsDayNow
        if low > gsH2
            array.push(gsGaps, GSGap.new(1, gsN, bar_index, gsH2, low, false))
        if high < gsL2
            array.push(gsGaps, GSGap.new(-1, gsN, bar_index, high, gsL2, false))
    while array.size(gsGaps) > 0 and array.first(gsGaps).born < gsN - 2 * gsLookback
        array.shift(gsGaps)
    gsH2 := gsH1
    gsL2 := gsL1
    gsD2 := gsD1
    gsH1 := high
    gsL1 := low
    gsD1 := gsDayNow

    // (G) Today's range and the session ranges include this bar.
    gsDayH := na(gsDayH) ? high : math.max(gsDayH, high)
    gsDayL := na(gsDayL) ? low : math.min(gsDayL, low)
    if gsInAsia and not gsAsiaDone
        gsAsiaH := na(gsAsiaH) ? high : math.max(gsAsiaH, high)
        gsAsiaL := na(gsAsiaL) ? low : math.min(gsAsiaL, low)
    if gsInLon and not gsLonDone
        gsLonH := na(gsLonH) ? high : math.max(gsLonH, high)
        gsLonL := na(gsLonL) ? low : math.min(gsLonL, low)

// ═══ STRATEGY LAB · strategy.pinefrag (strategy only) ═════════════════════════════════════════════════════════
// TradingView's broker emulator runs the desk's plans. Orders process on the bar close, like the desk's decisions:
//   entry  a market order at the entry close and, in the same calculation, one exit order with the frozen stop and
//          target, so the position is protected from the first bar after entry;
//   end    every plan end cancels pending orders first (cancel_all after close_all would cancel the close), then
//          closes anything still held at that close (the time exit, or an emulator fill that differed).
// The desk stays the reference. The emulator orders a bar's high and low its own way, so its fills can differ; that
// difference is what the Strategy Tester shows. A strategy does not run on the forming candle. Commission is set in
// Properties: cash per contract 0.20 a side = the desk's 0.40 round-trip estimate on spot gold (1 contract = 1 oz).

string gsG5 = "05 · Strategy Lab"
float gsRiskPct = input.float(1.0, "Risk per plan · % of equity", minval = 0.1, maxval = 10, step = 0.1, group = gsG5, tooltip = "The loss at the stop, as a share of equity, before costs.")
float gsExposurePct = input.float(90, "Largest position · % of equity", minval = 1, maxval = 1000, step = 1, group = gsG5, tooltip = "Caps a position's value. The script declares 100 % margin; 90 % leaves room for costs. Raise it only for leveraged trading, together with the margin settings.")

// Quantity: the smaller of the risk budget and the exposure cap, in the account currency (a symbol quoted in
// another currency is converted), rounded down to the symbol's contract step. Zero means no affordable size.
f_gsQty(float risk, float price) =>
    float conv = strategy.convert_to_account(1.0)
    float unitRisk = risk * syminfo.pointvalue * conv
    float unitNotional = math.abs(price) * syminfo.pointvalue * conv
    float step = syminfo.mincontract > 0 ? syminfo.mincontract : 1.0
    float equity = math.max(0, strategy.equity)
    float units = unitRisk > 0 and unitNotional > 0 ? math.min(equity * gsRiskPct / 100 / unitRisk, equity * gsExposurePct / 100 / unitNotional) : 0.0
    math.floor(units / step + 1e-9) * step

var int gsLabSkipped = 0

// Every plan end: cancel pending orders, then close what the emulator still holds.
if gsClosed and gsEv.exit
    strategy.cancel_all()
    if strategy.position_size != 0
        strategy.close_all(comment = "DESK " + gsEv.why)
// Entry and its protection in the same calculation. A position the emulator still holds is not doubled.
if gsClosed and gsEv.entry != 0
    float qty = f_gsQty(gsP.risk, gsP.entry)
    if strategy.position_size != 0
        gsLabSkipped += 1
    else if qty > 0
        string id = gsEv.entry == 1 ? "GS L" : "GS S"
        strategy.entry(id, gsEv.entry == 1 ? strategy.long : strategy.short, qty = qty, comment = (gsEv.entry == 1 ? "▲ " : "▼ ") + gsP.pool)
        strategy.exit(id + " exit", id, stop = gsP.stop, limit = gsP.target, comment_loss = "STOP", comment_profit = "TARGET")

// ═══ DISPLAY · visuals.pinefrag ═════════════════════════════════════════════════════════════════════════════════
// Reads engine state and draws it. It never assigns an engine variable, requests data, trades or alerts
// (tests/display.test.mjs enforces this), so a display change cannot change a plan or a result.
// Desk standard: state line · reason · ribbon · steps (✓ / ✗ / —, ● required) · plan in price and R · today ·
// record (counts first, % only from the threshold) · footer. Co-Pilot: NOW · WHY · PLAN · LIMITS.
// Layers: the desk and the live drawings follow every tick; the history is redrawn once per closed bar.

string gsvG = "06 · View"
string gsvTheme = input.string("Standard", "Theme", options = ["Standard", "Colorblind-safe"], group = gsvG)
string gsvDeskPos = input.string("Top right", "Desk position", options = ["Top right", "Top left", "Bottom right", "Bottom left", "Off"], group = gsvG)
string gsvRows = input.string("Compact", "Desk rows", options = ["Compact", "Full"], group = gsvG, tooltip = "Full adds every pool of the day, the last plan and the average result.")
string gsvPilot = input.string("Brief", "Co-Pilot", options = ["Standard", "Brief", "Off"], group = gsvG, tooltip = "The desk in plain words. Brief shows NOW and PLAN; Standard adds WHY and LIMITS.")
string gsvPilotPos = input.string("Bottom left", "Co-Pilot position", options = ["Bottom left", "Bottom right", "Top left", "Top right"], group = gsvG)
string gsvTextSize = input.string("Normal", "Text size", options = ["Small", "Normal", "Large"], group = gsvG)
int gsvDays = input.int(2, "Days drawn", minval = 1, maxval = 30, group = gsvG, tooltip = "Pools, sessions and plans of this many trading days (today included), within the last 1,500 bars.")
bool gsvPools = input.bool(true, "Liquidity pools", group = gsvG)
bool gsvSessions = input.bool(true, "Asia and London boxes", group = gsvG)
bool gsvZones = input.bool(true, "Risk / reward zones", group = gsvG)
bool gsvMisses = input.bool(true, "Mark setups that ended without a plan (◌)", group = gsvG)
bool gsvTint = input.bool(false, "Tint candles while a plan is open", group = gsvG)

// Colour carries meaning: teal = long / target, coral = short / stop, gold = liquidity and a setup in progress.
bool gsvCb = gsvTheme == "Colorblind-safe"
color gsvUp = gsvCb ? #56B4E9 : #26A69A
color gsvDown = gsvCb ? #E69F00 : #EF5350
color gsvGold = gsvCb ? #F0E442 : #F2B33D
color gsvAsia = #7E8CE0
color gsvInk = #E6E9F0
color gsvMuted = #8A93A6
color gsvGrey = #6B7280
color gsvPanel = color.new(#10151F, 6)
string gsvSz = gsvTextSize == "Small" ? size.tiny : gsvTextSize == "Large" ? size.normal : size.small
string gsvSzState = gsvTextSize == "Small" ? size.small : gsvTextSize == "Large" ? size.large : size.normal

f_gsvCorner(string p) =>
    p == "Top left" ? position.top_left : p == "Bottom right" ? position.bottom_right : p == "Bottom left" ? position.bottom_left : position.top_right
f_gsvPx(float v) =>
    na(v) ? "—" : str.tostring(v, format.mintick)
f_gsvR(float v) =>
    na(v) ? "—" : math.abs(v) < 0.05 ? "0.0R" : (v < 0 ? "−" : "+") + str.tostring(math.abs(v), "0.0") + "R"
f_gsvHm(int mins) =>
    str.tostring(int(mins / 60) % 24, "00") + ":" + str.tostring(mins % 60, "00")
f_gsvAt(int t) =>
    str.tostring(hour(t, "America/New_York"), "00") + ":" + str.tostring(minute(t, "America/New_York"), "00")
f_gsvLeft(int mins) =>
    mins <= 0 ? "closing" : (mins >= 60 ? str.tostring(int(mins / 60)) + " h " : "") + str.tostring(mins % 60) + " m left"
f_gsvMark(int s) =>
    s == 1 ? "✓ met" : s == 0 ? "✗ not met" : s == -1 ? "— no data" : s == -3 ? "— waiting" : "— off"
f_gsvTone(int s) =>
    s == 1 ? gsvUp : s == 0 ? gsvDown : gsvMuted
f_gsvEnding(string why) =>
    why == "TARGET" ? "TARGET" : why == "STOP" ? "STOP" : why == "TIME" ? "FLAT AT THE TIME EXIT" : why
f_gsvEndMark(string why, float r) =>
    why == "TARGET" ? "✓" : why == "STOP" ? "✗" : r > 0.05 ? "✓" : r < -0.05 ? "✗" : "◌"
f_gsvWrap(string txt, int columns) =>
    array<string> words = str.split(txt, " ")
    string output = ""
    int width = 0
    for word in words
        if width > 0 and width + str.length(word) + 1 > columns
            output += "\n"
            width := 0
        output += (width > 0 ? " " : "") + word
        width += str.length(word) + 1
    output
f_gsvSide(int d) =>
    d == 1 ? "long" : "short"

// ── windows, in New York minutes
bool gsvCont = gsWindows == "Continuous 01:00–11:00"
int gsvWinEnd = gsvCont ? 660 : gsWinNow == "London" ? 300 : 660
string gsvWinTxt = gsvCont ? "01:00–11:00" : gsWinNow == "London" ? "London 02:00–05:00" : "New York 07:00–11:00"
// The next window start after this minute of the day: later today, tomorrow, or Monday (no windows at the weekend).
f_gsvNextWin(int hm) =>
    int dow = dayofweek(time, "America/New_York")
    bool later = gsvCont ? hm >= 60 : not ((gsWinLon and hm < 120) or (gsWinNy and hm < 420))
    string day = dow == dayofweek.saturday or dow == dayofweek.sunday or (dow == dayofweek.friday and later) ? "Monday " : later ? "tomorrow " : ""
    string win = gsvCont ? "01:00" : (not later and gsWinLon and hm < 120) or (later and gsWinLon) ? "London 02:00" : gsWinNy ? "New York 07:00" : ""
    win == "" ? "none (both windows off)" : day + win

// ── what the desk shows (display variables; the engine's objects are only read)
string gsvState = ""
string gsvReason = ""
string gsvNow = ""
string gsvPlan = ""
color gsvTone = gsvMuted
string gsvRib = ""
int gsvDir = 0
string gsvNearUp = ""
string gsvNearDn = ""
int gsvFresh = 0
int gsvPoolsToday = 0
if barstate.islastconfirmedhistory or barstate.isrealtime
    // Nearest fresh pools above and below the close.
    float upPx = na
    float dnPx = na
    for p in gsPools
        gsvPoolsToday += 1
        if p.fresh
            gsvFresh += 1
            if p.price >= close and (na(upPx) or p.price < upPx)
                upPx := p.price
                gsvNearUp := p.name + " " + f_gsvPx(p.price) + " (+" + str.tostring(p.price - close, format.mintick) + ")"
            if p.price < close and (na(dnPx) or p.price > dnPx)
                dnPx := p.price
                gsvNearDn := p.name + " " + f_gsvPx(p.price) + " (−" + str.tostring(close - p.price, format.mintick) + ")"
    gsvDir := gsP.dir != 0 ? gsP.dir : gsS.state != 0 ? gsS.dir : 0
    string r1 = gsvFresh > 0 ? "✓" : "·"
    string r2 = "·"
    string r3 = "·"
    string r4 = "·"
    string r5 = "·"
    if not gsAvailable
        gsvState := "— UNAVAILABLE · " + timeframe.period + " chart"
        gsvReason := gsUnavailable == "standard candles needed" ? "Heikin Ashi, Renko and other synthetic candles move the closes. Use standard candles." : "Use an intraday chart of 1 hour or less (5 or 15 minutes on gold)."
        gsvNow := "This chart cannot run the rule. " + gsvReason
    else if gsTrN < 14
        gsvState := "○ WARMING UP"
        gsvReason := "The ATR needs 14 session bars."
        gsvNow := gsvReason
    else if gsP.dir != 0
        float openR = (close - gsP.entry) * gsP.dir / gsP.risk
        gsvState := "● IN TRADE · " + (gsP.dir == 1 ? "LONG" : "SHORT") + " · " + f_gsvR(openR) + (gsP.tp1Hit ? " · 1R reached" : "")
        gsvTone := gsP.dir == 1 ? gsvUp : gsvDown
        gsvReason := "Stop " + f_gsvPx(gsP.stop) + " · 1R " + f_gsvPx(gsP.tp1) + (gsP.tp1Hit ? " ✓" : "") + " · target " + f_gsvPx(gsP.target) + " · flat at " + gsExitAt
        gsvNow := "In a " + f_gsvSide(gsP.dir) + " from " + f_gsvPx(gsP.entry) + " after the " + gsP.pool + " sweep (" + gsP.how + "), " + str.tostring(bar_index - gsP.entryBar) + " bars ago, " + f_gsvR(openR) + " at this close before costs."
        gsvPlan := "Stop first on every closed bar: the stop " + f_gsvPx(gsP.stop) + " is beyond the sweep's extreme " + f_gsvPx(gsP.extreme) + ", where the idea is wrong. The target " + f_gsvPx(gsP.target) + " ends it; otherwise it is flat at " + gsExitAt + " New York."
        r2 := "✓"
        r3 := "✓"
        r4 := "✓"
        r5 := "▶"
    else if gsGoldShut
        gsvState := "◌ GOLD IS CLOSED"
        gsvReason := "Spot gold trades Sunday 18:00 → Friday 17:00 New York, with a break 17:00–18:00. These bars are skipped."
        gsvNow := gsvReason
    else if gsS.state == 1
        int left = math.max(0, gsReclaim - (gsN - gsS.raidN))
        gsvState := "● RAID · " + gsS.pool + " · " + (gsS.dir == -1 ? "above" : "below")
        gsvTone := gsvGold
        gsvReason := "A close back " + (gsS.dir == -1 ? "below " : "above ") + f_gsvPx(gsS.ref) + " makes it a sweep (" + str.tostring(left) + (left == 1 ? " bar" : " bars") + " left); otherwise price was accepted beyond the level."
        gsvNow := "Price is raiding the " + gsS.pool + " (" + f_gsvPx(gsS.ref) + ") in the " + gsS.window + " window, extreme " + f_gsvPx(gsS.extreme) + ". " + gsvReason
        r2 := "▶"
    else if gsS.state == 2
        int left = math.max(0, gsFlipBars - (gsN - gsS.sweepN))
        float lvl = gsS.dir == -1 ? math.min(gsS.gapB, gsS.extreme - gsMinLeg * gsAtr) : math.max(gsS.gapT, gsS.extreme + gsMinLeg * gsAtr)
        gsvState := "● SWEPT · " + gsS.pool + " · waiting for the flip"
        gsvTone := gsvGold
        gsvReason := "A close " + (gsS.dir == -1 ? "below " : "above ") + f_gsvPx(lvl) + " flips the gap " + f_gsvPx(gsS.gapB) + "–" + f_gsvPx(gsS.gapT) + " (" + str.tostring(left) + (left == 1 ? " bar" : " bars") + " left). " + (gsFailOn == "Any new extreme" ? "A new extreme ends it." : "A close back " + (gsS.dir == -1 ? "above " : "below ") + f_gsvPx(gsS.ref) + " ends it.")
        gsvNow := "The " + gsS.pool + " was swept (extreme " + f_gsvPx(gsS.extreme) + "). The desk now waits for a close through the nearest opposing gap, the flip that confirms the reversal."
        r2 := "✓"
        r3 := "▶"
    else if gsS.state == 3
        int left = math.max(0, gsRetestBars - (gsN - gsS.flipN))
        gsvState := "● FLIPPED · waiting for the retest"
        gsvTone := gsvGold
        gsvReason := "A close back inside " + f_gsvPx(gsS.gapB) + "–" + f_gsvPx(gsS.gapT) + " enters " + f_gsvSide(gsS.dir) + " (" + str.tostring(left) + (left == 1 ? " bar" : " bars") + " left); a touch of the stop " + f_gsvPx(gsS.stop) + " cancels."
        gsvNow := "The gap flipped after the " + gsS.pool + " sweep. Retest mode waits for a close back inside the flipped gap."
        r2 := "✓"
        r3 := "✓"
        r4 := "▶"
    else if gsWinNow != ""
        int left = gsvWinEnd - gsHm
        gsvState := "○ WATCHING · " + gsWinNow + " window · " + str.tostring(gsvFresh) + (gsvFresh == 1 ? " fresh pool" : " fresh pools")
        gsvTone := gsvGold
        gsvReason := gsvFresh == 0 ? "Every pool of today is used up. The next ones: Asia and London ranges, then tomorrow's prior-day levels." : "A raid of a fresh pool, then a close back inside it, starts a setup (" + f_gsvLeft(left) + ")."
        gsvNow := "Watching the " + gsWinNow + " window. " + (gsvNearUp != "" ? "Above: " + gsvNearUp + ". " : "") + (gsvNearDn != "" ? "Below: " + gsvNearDn + ". " : "") + (gsvFresh == 0 ? "No fresh pool is left today." : "")
    else
        gsvState := "◌ OUTSIDE THE WINDOWS · next " + f_gsvNextWin(gsHm)
        gsvReason := "Setups start only in " + (gsvCont ? "the 01:00–11:00 window" : (gsWinLon ? "London 02:00–05:00" : "") + (gsWinLon and gsWinNy ? " and " : "") + (gsWinNy ? "New York 07:00–11:00" : "")) + " (New York time). Pools still get used up now."
        gsvNow := "Outside the entry windows. " + (gsvNearUp != "" ? "Above: " + gsvNearUp + ". " : "") + (gsvNearDn != "" ? "Below: " + gsvNearDn + "." : "")
    gsvRib := "01 POOLS " + r1 + "  02 SWEEP " + r2 + "  03 FLIP " + r3 + "  04 PLAN " + r4 + "  05 RESULT " + r5
    if gsvPlan == ""
        gsvPlan := "Rule: sweep of the prior day, Asia or London high/low in " + (gsvCont ? "01:00–11:00" : "the London or New York window") + " → a close through the nearest opposing gap" + (gsEntryMode == "Retest close" ? " → a close back inside it" : "") + " → entry at that close, stop beyond the sweep's extreme, target " + str.tostring(gsTargetR, "0.0#") + "R, flat at " + gsExitAt + "."

// ── desk and Co-Pilot
var table gsvDesk = table.new(f_gsvCorner(gsvDeskPos), 2, 40, frame_width = 0, border_width = 0)
string gsvPilotCorner = gsvPilotPos != gsvDeskPos ? gsvPilotPos : gsvDeskPos == "Bottom left" ? "Bottom right" : "Bottom left"
var table gsvPilotT = table.new(f_gsvCorner(gsvPilotCorner), 1, 7, frame_width = 0, border_width = 0)
int gsvPOff = gsvPilotCorner == "Top left" ? 1 : 0
int gsvOff = gsvDeskPos == "Top left" ? 1 : 0
f_gsvRow(int r, string a, string b, color ca, color cb) =>
    table.cell(gsvDesk, 0, r + gsvOff, a, text_color = ca, bgcolor = gsvPanel, text_size = gsvSz, text_halign = text.align_left)
    table.cell(gsvDesk, 1, r + gsvOff, b, text_color = cb, bgcolor = gsvPanel, text_size = gsvSz, text_halign = text.align_left)
f_gsvWide(int r, string txt, color c, bool bold, string tip) =>
    table.cell(gsvDesk, 0, r + gsvOff, txt, text_color = c, bgcolor = gsvPanel, text_size = bold ? gsvSzState : gsvSz, text_halign = text.align_left, text_formatting = bold ? text.format_bold : text.format_none, tooltip = tip)
    table.merge_cells(gsvDesk, 0, r + gsvOff, 1, r + gsvOff)
// The rule is built for 5–15 minute candles: from 30 minutes a candle is a large part of a window and the 2R target has
// little room before 16:45; TradingView loads only a few days of 1–4 minute candles, too few for this chart's record.
int gsvTfSec = timeframe.in_seconds()
string gsvTfMins = str.tostring(gsvTfSec / 60, "#")
string gsvTfNote = gsvTfSec >= 1800 ? "TIMEFRAME · built for 5–15 minutes: on " + gsvTfMins + "-minute candles a plan has little room for its target before 16:45" : gsvTfSec < 300 ? "TIMEFRAME · built for 5–15 minutes: TradingView loads only a few days of " + gsvTfMins + "-minute candles, too few for a record" : ""
// One step row: the mark, a detail, and "● required" (every step of the sequence is required).
f_gsvStep(int r, string name, int s, string detail) =>
    f_gsvRow(r, name, f_gsvMark(s) + (detail == "" ? "" : " · " + detail) + "  ● required", gsvInk, f_gsvTone(s))

f_gsvDrawDesk() =>
    table.clear(gsvDesk, 0, 0, 1, 39)
    if gsvDeskPos != "Off"
        if gsvOff == 1
            table.cell(gsvDesk, 0, 0, "", height = 14, bgcolor = na)
            table.cell(gsvDesk, 1, 0, "", height = 14, bgcolor = na)
        bool full = gsvRows == "Full"
        bool inPlan = gsP.dir != 0
        int st = gsS.state
        // Step states: 1 met · 0 not met · -1 no data · -3 waiting.
        int sWin = inPlan or st > 0 ? 1 : gsWinNow != "" ? 1 : 0
        int sPool = inPlan or st > 0 ? 1 : gsvFresh > 0 ? 1 : 0
        int sSweep = inPlan or st >= 2 ? 1 : st == 1 ? -3 : -3
        int sGap = inPlan or st >= 2 ? 1 : -3
        int sFlip = inPlan or st == 3 ? 1 : -3
        int met = (sWin == 1 ? 1 : 0) + (sPool == 1 ? 1 : 0) + (sSweep == 1 ? 1 : 0) + (sGap == 1 ? 1 : 0) + (sFlip == 1 ? 1 : 0)
        f_gsvWide(0, "GOLD SWEEP DESK · " + syminfo.ticker + " · " + timeframe.period + (GS_IS_STRATEGY ? " · STRATEGY LAB" : ""), gsvMuted, false, "Gold Sweep Desk " + GS_VERSION + " · a paper reference decided on closed bars, New York time." + (GS_IS_STRATEGY ? " The Strategy Tester shows TradingView's fills of the same plans." : "") + " Fills at your broker can differ.")
        f_gsvWide(1, gsvState, gsvTone, true, "Pools → raid → sweep → flip → plan → result.")
        f_gsvWide(2, f_gsvWrap(gsvReason, 58), gsvInk, false, "")
        f_gsvWide(3, gsvRib, gsvMuted, false, "01 fresh pools · 02 a raid and a close back inside · 03 the gap flips · 04 the plan · 05 its result")
        f_gsvWide(4, "STEPS" + (gsvDir != 0 ? " · for a " + f_gsvSide(gsvDir) : "") + " · " + str.tostring(met) + " of 5 required met", gsvMuted, false, "")
        f_gsvStep(5, "Window", sWin, inPlan or st > 0 ? (inPlan ? gsP.window : gsS.window) : gsWinNow != "" ? gsvWinTxt + " · " + f_gsvLeft(gsvWinEnd - gsHm) : "closed · next " + f_gsvNextWin(gsHm))
        f_gsvStep(6, "Fresh pool", sPool, inPlan ? gsP.pool : st > 0 ? gsS.pool : str.tostring(gsvFresh) + " of " + str.tostring(gsvPoolsToday) + " today")
        f_gsvStep(7, "Sweep · close back inside", sSweep, inPlan ? gsP.pool + " · extreme " + f_gsvPx(gsP.extreme) : st >= 2 ? gsS.pool + " · extreme " + f_gsvPx(gsS.extreme) : st == 1 ? "raid under way" : "")
        f_gsvStep(8, "Opposing gap", sGap, inPlan ? f_gsvPx(gsP.gapB) + "–" + f_gsvPx(gsP.gapT) : st >= 2 ? f_gsvPx(gsS.gapB) + "–" + f_gsvPx(gsS.gapT) : "")
        f_gsvStep(9, "Flip close ≥ " + str.tostring(gsMinLeg, "0.0#") + " ATR from the extreme", sFlip, inPlan ? f_gsvAt(gsP.entryTime) : st == 3 ? "done" : "")
        int r = 10
        if gsvNearUp != "" or gsvNearDn != ""
            f_gsvRow(r, "Nearest fresh", (gsvNearUp != "" ? "▲ " + gsvNearUp : "") + (gsvNearUp != "" and gsvNearDn != "" ? "\n" : "") + (gsvNearDn != "" ? "▼ " + gsvNearDn : ""), gsvMuted, gsvGold)
            r += 1
        if full
            for p in gsPools
                if r < 24
                    f_gsvRow(r, "  " + p.name, f_gsvPx(p.price) + (p.fresh ? " · fresh" : " · taken"), gsvMuted, p.fresh ? gsvGold : gsvGrey)
                    r += 1
        if inPlan
            f_gsvWide(r, "PLAN · " + f_gsvSide(gsP.dir) + " · " + gsP.how + " · frozen at entry", gsvMuted, false, "Frozen at entry.")
            f_gsvRow(r + 1, "Entry", f_gsvPx(gsP.entry) + " · " + str.tostring(bar_index - gsP.entryBar) + " bars ago", gsvMuted, gsvGold)
            f_gsvRow(r + 2, "Stop · 1R", f_gsvPx(gsP.stop) + " · " + str.tostring(math.abs(close - gsP.stop), format.mintick) + " away", gsvMuted, gsvDown)
            f_gsvRow(r + 3, "1R", f_gsvPx(gsP.tp1) + (gsP.tp1Hit ? " ✓" : " · " + str.tostring(math.abs(gsP.tp1 - close), format.mintick) + " away"), gsvMuted, gsvUp)
            f_gsvRow(r + 4, "Target · " + str.tostring(gsTargetR, "0.0#") + "R", f_gsvPx(gsP.target) + " · " + str.tostring(math.abs(gsP.target - close), format.mintick) + " away", gsvMuted, gsvUp)
            r += 5
        else
            f_gsvWide(r, f_gsvWrap("PLAN · " + gsvPlan, 58), gsvMuted, false, "")
            r += 1
        if gsTx.log != ""
            f_gsvWide(r, f_gsvWrap("TODAY " + gsTx.log, 58), gsvInk, false, "New York times.")
            r += 1
        string counts = "THIS CHART " + str.tostring(gsSt.raids) + " raids · " + str.tostring(gsSt.sweeps) + " sweeps · " + str.tostring(gsSt.flips) + " flips · " + (gsSt.plans == 0 ? "no closed plan yet" : str.tostring(gsSt.plans) + " plans: target " + str.tostring(gsSt.nTarget) + " · stop " + str.tostring(gsSt.nStop) + " · time " + str.tostring(gsSt.nTime) + " · reached 1R " + str.tostring(gsSt.nTp1))
        f_gsvWide(r, f_gsvWrap(counts, 58), gsvInk, false, "Counts of this chart's history. History on this chart, not a forecast.")
        r += 1
        if full
            string avgTxt = gsSt.plans == 0 ? "Average: needs a closed plan" : "Average " + f_gsvR(gsSt.sumR / gsSt.plans) + " over " + str.tostring(gsSt.plans) + " plans after an estimated " + str.tostring(gsCost, "0.00") + " round trip" + (gsSt.plans >= gsPctMin ? " · " + str.tostring(math.round(100.0 * gsSt.wins / gsSt.plans)) + "% closed above 0R" : "")
            f_gsvWide(r, f_gsvWrap(avgTxt, 58), gsvMuted, false, "Net R after the estimated cost in 04. A percentage appears only from " + str.tostring(gsPctMin) + " closed plans.")
            string ended = "Ended before a plan: held " + str.tostring(gsSt.held) + " · no gap " + str.tostring(gsSt.noGap) + " · sweep failed " + str.tostring(gsSt.failed) + " · no flip " + str.tostring(gsSt.noFlip) + " · refused " + str.tostring(gsSt.noEntry)
            f_gsvWide(r + 1, f_gsvWrap(ended, 58), gsvMuted, false, "")
            r += 2
        if gsvTfNote != ""
            f_gsvWide(r, f_gsvWrap(gsvTfNote, 58), gsvGold, false, "The rule's windows and its 16:45 exit are set in minutes of the New York day.")
            r += 1
        f_gsvWide(r, "Rules, not odds · history, not a forecast · ProEA Lab", gsvMuted, false, "")

f_gsvDrawPilot() =>
    table.clear(gsvPilotT, 0, 0, 0, 6)
    if gsvPilot != "Off"
        string why = "Above an old high and below an old low sit other traders' stops. A raid through such a level that closes back inside took that liquidity without accepting the new price. The flip, a close through the nearest opposing gap, is the sign that the move has turned; the sweep's extreme is where the idea is wrong."
        string limits = "A rule, not a forecast. The pools are price levels, not an order book. Results are this chart's history after an estimated " + str.tostring(gsCost, "0.00") + " round trip; fills at your broker can differ."
        int o = gsvPOff
        if o == 1
            table.cell(gsvPilotT, 0, 0, "", height = 14, bgcolor = na)
        table.cell(gsvPilotT, 0, 0 + o, "CO-PILOT", text_color = gsvMuted, bgcolor = gsvPanel, text_size = size.tiny, text_halign = text.align_left)
        table.cell(gsvPilotT, 0, 1 + o, f_gsvWrap("NOW · " + gsvNow, 60), text_color = gsvInk, bgcolor = gsvPanel, text_size = gsvSz, text_halign = text.align_left)
        if gsvPilot == "Standard"
            table.cell(gsvPilotT, 0, 2 + o, f_gsvWrap("WHY · " + why, 60), text_color = gsvInk, bgcolor = gsvPanel, text_size = gsvSz, text_halign = text.align_left)
        table.cell(gsvPilotT, 0, 3 + o, f_gsvWrap("PLAN · " + gsvPlan, 60), text_color = gsvInk, bgcolor = gsvPanel, text_size = gsvSz, text_halign = text.align_left)
        if gsvPilot == "Standard"
            table.cell(gsvPilotT, 0, 4 + o, f_gsvWrap("LIMITS · " + limits, 60), text_color = gsvMuted, bgcolor = gsvPanel, text_size = gsvSz, text_halign = text.align_left)
        if gsvPilotCorner == "Bottom left" or gsvPilotCorner == "Bottom right"
            table.cell(gsvPilotT, 0, 6, "", height = 5, bgcolor = na)

// ── chart layers: bounded handles, never further back than the history buffer (max_bars_back = 2000)
var array<box> gsvHB = array.new<box>()
var array<line> gsvHL = array.new<line>()
var array<label> gsvHT = array.new<label>()
var array<box> gsvLB = array.new<box>()
var array<line> gsvLL = array.new<line>()
var array<label> gsvLT = array.new<label>()
f_gsvClear(array<box> bs, array<line> ls, array<label> ts) =>
    for b in bs
        box.delete(b)
    for l in ls
        line.delete(l)
    for x in ts
        label.delete(x)
    array.clear(bs)
    array.clear(ls)
    array.clear(ts)
int gsvTfMin = math.max(1, int(timeframe.in_seconds() / 60))

// Short names on the chart; the desk and the tooltips use the full ones.
f_gsvShort(string name) =>
    name == "Asia high" ? "ASIA H" : name == "Asia low" ? "ASIA L" : name == "London high" ? "LDN H" : name == "London low" ? "LDN L" : name
// A pool's tag sits where its line ends: the candle that took it, or just right of the last candle while fresh.
f_gsvTagX(GSPool p) =>
    na(p.takenBar) ? bar_index + 3 : math.max(p.takenBar, math.max(p.bornBar, bar_index - 1500))
// A tag is about eight candles wide: tags within 12 candles and 1 ATR of each other would print over each other,
// so the upper one moves above its line and the lower one below it (a middle one of three stays on its line).
f_gsvPlace(int pi, int oldestDay, array<int> tagDays) =>
    GSPool p = array.get(gsPoolLog, pi)
    int x = f_gsvTagX(p)
    float near = nz(gsAtr, 0)
    bool above = false
    bool below = false
    for [qi, q] in gsPoolLog
        if qi != pi and q.day >= oldestDay and q.bornBar >= bar_index - 1500 and array.includes(tagDays, q.day) and math.abs(f_gsvTagX(q) - x) <= 12 and math.abs(q.price - p.price) <= near
            if q.price > p.price or (q.price == p.price and qi > pi)
                above := true
            else
                below := true
    below and not above ? label.style_label_lower_left : above and not below ? label.style_label_upper_left : label.style_label_left
f_gsvDrawPool(GSPool p, bool today, string place) =>
    int x1 = math.max(p.bornBar, bar_index - 1500)
    int x2 = f_gsvTagX(p)
    bool live = today and p.fresh
    color c = live ? gsvGold : gsvGrey
    array.push(gsvHL, line.new(x1, p.price, x2, p.price, color = color.new(c, live ? 10 : today ? 35 : 60), style = live ? line.style_solid : line.style_dotted, width = live ? 2 : 1))
    if today
        array.push(gsvHT, label.new(x2, p.price, f_gsvShort(p.name) + (p.fresh ? " " + f_gsvPx(p.price) : " ✕"), style = place, color = color.new(#10151F, 20), textcolor = color.new(c, p.fresh ? 0 : 20), size = size.small, tooltip = p.name + " " + f_gsvPx(p.price) + (p.fresh ? " · fresh: no bar has traded through it yet" : " · taken")))

f_gsvDrawSession(GSPool hi, GSPool lo, int mins, color c, string name) =>
    int x2 = hi.bornBar - 1
    int x1 = math.max(x2 - int(mins / gsvTfMin) + 1, bar_index - 1500)
    if x2 > x1
        array.push(gsvHB, box.new(x1, hi.price, x2, lo.price, border_color = color.new(c, 70), bgcolor = color.new(c, 92), text = name, text_color = color.new(c, 30), text_size = size.small, text_halign = text.align_left, text_valign = text.align_top))

f_gsvDrawPlan(GSPlan pl, bool isOpen) =>
    int xa = math.max(pl.entryBar, bar_index - 1500)
    int xb = isOpen ? bar_index + 2 : math.max(pl.exitBar, xa)
    int xg = math.max(pl.gapBar - 2, bar_index - 1500)
    if not na(pl.gapB) and pl.gapBar >= bar_index - 1500
        array.push(gsvHB, box.new(xg, pl.gapT, math.max(pl.flipBar, xg), pl.gapB, border_color = color.new(gsvGold, 55), bgcolor = color.new(gsvGold, 85), text = "FLIP", text_color = color.new(gsvGold, 20), text_size = size.tiny, text_halign = text.align_right, text_valign = text.align_center))
    if pl.sweepBar >= bar_index - 1500
        array.push(gsvHT, label.new(pl.sweepBar, pl.extreme, "SWEPT " + pl.pool, style = pl.dir == -1 ? label.style_label_down : label.style_label_up, color = color.new(gsvGold, 20), textcolor = #0C131D, size = size.small, tooltip = "Raid of the " + pl.pool + " and a close back inside · extreme " + f_gsvPx(pl.extreme)))
    if gsvZones
        array.push(gsvHB, box.new(xa, math.max(pl.entry, pl.stop), xb, math.min(pl.entry, pl.stop), border_color = color.new(gsvDown, 100), bgcolor = color.new(gsvDown, isOpen ? 84 : 93)))
        array.push(gsvHB, box.new(xa, math.max(pl.entry, pl.target), xb, math.min(pl.entry, pl.target), border_color = color.new(gsvUp, 100), bgcolor = color.new(gsvUp, isOpen ? 84 : 93)))
    array.push(gsvHL, line.new(xa, pl.tp1, xb, pl.tp1, color = color.new(gsvUp, isOpen ? 35 : 65), style = line.style_dashed))
    array.push(gsvHL, line.new(xa, pl.entry, xb, pl.entry, color = color.new(gsvGold, isOpen ? 10 : 50)))
    if pl.entryBar >= bar_index - 1500
        array.push(gsvHT, label.new(pl.entryBar, pl.entry, (pl.dir == 1 ? "▲ LONG " : "▼ SHORT ") + f_gsvPx(pl.entry), style = pl.dir == 1 ? label.style_label_up : label.style_label_down, color = color.new(pl.dir == 1 ? gsvUp : gsvDown, 15), textcolor = #0C131D, size = size.small, tooltip = pl.how + " after the " + pl.pool + " sweep · stop " + f_gsvPx(pl.stop) + " · 1R " + f_gsvPx(pl.tp1) + " · target " + f_gsvPx(pl.target)))
    if not isOpen and pl.exitBar >= bar_index - 1500
        bool above = pl.exitPrice >= pl.entry
        color c = pl.netR > 0.05 ? gsvUp : pl.netR < -0.05 ? gsvDown : gsvGrey
        array.push(gsvHT, label.new(pl.exitBar, pl.exitPrice, f_gsvEndMark(pl.ending, pl.netR) + " " + f_gsvEnding(pl.ending) + " " + f_gsvR(pl.netR), style = above ? label.style_label_down : label.style_label_up, color = color.new(c, 15), textcolor = #0C131D, size = size.small, tooltip = "Exit " + f_gsvPx(pl.exitPrice) + " · " + f_gsvR(pl.grossR) + " before costs, " + f_gsvR(pl.netR) + " after the estimated cost"))

f_gsvDrawHistory() =>
    f_gsvClear(gsvHB, gsvHL, gsvHT)
    // The trading days to draw: the latest gsvDays distinct day ids in the pool log.
    int oldestDay = gsDay
    int seen = 0
    int lastDay = -1
    int i = array.size(gsPoolLog) - 1
    while i >= 0 and seen < gsvDays
        GSPool p = array.get(gsPoolLog, i)
        if p.day != lastDay
            seen += 1
            lastDay := p.day
            oldestDay := p.day
        i -= 1
    // Pool names are written for today and for every drawn day that had a plan.
    array<int> tagDays = array.from(gsDay)
    for pl in gsDone
        if pl.day >= oldestDay
            array.push(tagDays, pl.day)
    GSPool asiaHi = na
    GSPool lonHi = na
    for [pi, p] in gsPoolLog
        if p.day >= oldestDay and p.bornBar >= bar_index - 1500
            if gsvPools
                bool tagged = array.includes(tagDays, p.day)
                f_gsvDrawPool(p, tagged, tagged ? f_gsvPlace(pi, oldestDay, tagDays) : label.style_label_left)
            if gsvSessions and p.name == "Asia high"
                asiaHi := p
            if gsvSessions and p.name == "Asia low" and not na(asiaHi)
                f_gsvDrawSession(asiaHi, p, 240, gsvAsia, "ASIA")
            if gsvSessions and p.name == "London high"
                lonHi := p
            if gsvSessions and p.name == "London low" and not na(lonHi)
                f_gsvDrawSession(lonHi, p, 180, gsvGold, "LONDON")
    int j = array.size(gsDone) - 1
    while j >= 0
        GSPlan pl = array.get(gsDone, j)
        if pl.day < oldestDay or bar_index - pl.entryBar >= 1500
            break
        f_gsvDrawPlan(pl, false)
        j -= 1
    if gsP.dir != 0 and bar_index - gsP.entryBar < 1500
        f_gsvDrawPlan(gsP, true)
    if gsvMisses
        int k = array.size(gsEvBar) - 1
        int marks = 0
        while k >= 0 and marks < 40
            int eb = array.get(gsEvBar, k)
            if bar_index - eb >= 1500
                break
            string w = array.get(gsEvWhat, k)
            if w == "HELD" or w == "NO GAP" or w == "SWEEP FAILED" or w == "NO FLIP" or w == "NO RETEST" or str.startswith(w, "NO ENTRY")
                array.push(gsvHT, label.new(eb, array.get(gsEvPx, k), "◌", style = label.style_label_center, color = color.new(#000000, 100), textcolor = color.new(gsvGrey, 10), size = size.tiny, tooltip = str.lower(w) + " · the setup ended without a plan"))
                marks += 1
            k -= 1

f_gsvDrawLive() =>
    f_gsvClear(gsvLB, gsvLL, gsvLT)
    if gsP.dir == 0 and gsS.state != 0
        int x1 = math.max(gsS.raidBar, bar_index - 1500)
        color c = gsS.dir == -1 ? gsvDown : gsvUp
        array.push(gsvLL, line.new(x1, gsS.extreme, bar_index + 3, gsS.extreme, color = color.new(c, 20), width = 2))
        array.push(gsvLT, label.new(bar_index + 3, gsS.extreme, (gsS.state == 1 ? "RAID " : "SWEPT ") + gsS.pool + " · extreme " + f_gsvPx(gsS.extreme), style = label.style_label_left, color = color.new(#10151F, 10), textcolor = c, size = size.small))
        if gsS.state >= 2 and not na(gsS.gapB)
            int xg = math.max(gsS.gapBar - 2, bar_index - 1500)
            array.push(gsvLB, box.new(xg, gsS.gapT, bar_index + 3, gsS.gapB, border_color = color.new(gsvGold, 20), border_style = line.style_dashed, bgcolor = color.new(gsvGold, 85), text = gsS.state == 2 ? "GAP TO FLIP" : "FLIPPED · RETEST", text_color = color.new(gsvGold, 10), text_size = size.tiny, text_halign = text.align_right, text_valign = text.align_center))
        if gsS.state == 3
            array.push(gsvLL, line.new(x1, gsS.stop, bar_index + 3, gsS.stop, color = color.new(gsvDown, 30), style = line.style_dashed))

// Draw on the last historical bar and on every realtime execution. A strategy never runs on the forming bar, so
// barstate.islast alone would leave the Strategy Lab blank while the market is open.
if barstate.islastconfirmedhistory or barstate.isrealtime
    if barstate.islastconfirmedhistory or barstate.isconfirmed
        f_gsvDrawHistory()
    f_gsvDrawLive()
    f_gsvDrawDesk()
    f_gsvDrawPilot()

barcolor(gsvTint and gsP.dir != 0 ? color.new(gsP.dir == 1 ? gsvUp : gsvDown, 15) : na, title = "Plan tint")
