Fractal Model Desk

//@version=6

// FRACTAL MODEL DESK 2.1.0 | MIT | Copyright 2026 ProEA Lab
// Original implementation informed by public rules and separately documented source audits.
// Raw sweeps are observations. Automated delivery review is not full model validation.
// Closed-bar V/displacement proxies, overlap caution, and immutable review histories.
// HTF closure known at first chart-bar close in next HTF period. POI and higher bias require assessment.

indicator("Fractal Model Desk · Setup Atlas", "FM Atlas", overlay = true, max_labels_count = 500, max_lines_count = 500, max_boxes_count = 100)

// Setup engine: no orders, positions, grade, session, or daily-trade gates.
// C1 = reference HTF candle; C2 = sweep candle. All timestamps are observation times.
type Setup
    string key = ""
    int dir = 0
    int frameNo = 0
    int c1Time = na
    int c2Time = na
    int seenTime = na
    float c1High = na
    float c1Low = na
    float seedExt = na
    float ext = na
    float bodyExt = na
    float anchor = na
    int anchorTime = na
    int extremeTime = na
    int cisdTime = na
    int cisdFrame = na
    float cisd = na
    float projOrigin = na
    float unit = na
    bool cisdFailed = false
    int cisdFailTime = na
    float c2Open = na
    float c2High = na
    float c2Low = na
    float c2Close = na
    int c2KnownTime = na
    bool c2Valid = false
    int closure = 0
    int closureTime = na
    int c3Time = na
    int c3Frame = na
    int c4Time = na
    int c4Frame = na
    bool c3Held = true
    bool c3Strong = false
    float c3Eq = na
    int stage = 2
    float invalidLevel = na
    bool done = false
    string status = "C2 developing"
    int endTime = na
    float endPrice = na
    int fvgTime = na
    float fvgTop = na
    float fvgBot = na
    int touchTime = na
    int liqTime = na
    bool dualSweep = false
type FmEvent
    string key = ""
    string kind = ""
    int stamp = na
    float price = na
    int dir = 0
    string detail = ""
type Engine
    int frameTime = na
    int frameNo = 0
    bool ready = false
    float frameOpen = na
    float frameHigh = na
    float frameLow = na
    float frameClose = na
    bool seededBull = false
    bool seededBear = false
    int runDir = 0
    float runOpen = na
    int runTime = na
    float runBody = na
    float lastBullOpen = na
    int lastBullTime = na
    float lastBullBody = na
    float lastBearOpen = na
    int lastBearTime = na
    float lastBearBody = na
    float prevHigh = na
    float prevLow = na
    float prev2High = na
    float prev2Low = na
    int prevTime = na
    int prev2Time = na
    int total = 0
    int confirmed = 0
    int invalidated = 0
    int evicted = 0

f_event(array<FmEvent> events, Setup s, string kind, int stamp, float price, string detail) =>
    array.push(events, FmEvent.new(s.key, kind, stamp, price, s.dir, detail))

f_level(Setup s, float multiple) =>
    s.projOrigin + s.dir * multiple * s.unit

type FmBar
    float o = na
    float h = na
    float l = na
    float c = na
    int stamp = na
    int closedAt = na
    int frame = na
    float po = na
    float ph = na
    float pl = na
    float pc = na
    int pt = na

f_finish(Setup s, array<FmEvent> events, string reason, int stamp, float price) =>
    s.done := true
    s.status := reason
    s.endTime := stamp
    s.endPrice := price
    f_event(events, s, "END", stamp, price, reason)

// Called ONCE per confirmed chart bar. Synthetic probes call this identical function.
// HTF closes are observed at the first confirmed chart bar of the following frame.
f_step(Engine e, array<Setup> book, array<FmEvent> events, FmBar b, int keep, bool useBody, bool wickInvalid) =>
    array.clear(events)
    bool newFrame = na(e.frameTime) or b.frame != e.frameTime
    if newFrame
        e.ready := not na(e.frameTime) or b.stamp == b.frame
        e.frameTime := b.frame
        e.frameNo += 1
        e.frameOpen := b.o
        e.frameHigh := b.h
        e.frameLow := b.l
        e.seededBull := false
        e.seededBear := false
    else
        e.frameHigh := math.max(e.frameHigh, b.h)
        e.frameLow := math.min(e.frameLow, b.l)
    e.frameClose := b.c

    // Consecutive candle bodies; a doji ends the run. Keep the extreme-producing run.
    int bodyDir = b.c > b.o ? 1 : b.c < b.o ? -1 : 0
    if bodyDir != 0
        if bodyDir != e.runDir
            e.runOpen := b.o
            e.runTime := b.stamp
            e.runBody := b.c
        else
            e.runBody := bodyDir == 1 ? math.max(e.runBody, b.c) : math.min(e.runBody, b.c)
        if bodyDir == 1
            e.lastBullOpen := e.runOpen
            e.lastBullTime := e.runTime
            e.lastBullBody := e.runBody
        else
            e.lastBearOpen := e.runOpen
            e.lastBearTime := e.runTime
            e.lastBearBody := e.runBody
    e.runDir := bodyDir

    // Advance every existing setup independently, including opposing setups.
    if array.size(book) > 0
        for s in book
            if not s.done
                int age = e.frameNo - s.frameNo + 2
                s.stage := math.min(age, 4)
                if newFrame
                    bool priorMatches = age == 3 ? b.pt == s.c2Time : age == 4 ? b.pt == s.c3Frame : age == 5 ? b.pt == s.c4Frame : true
                    if not priorMatches
                        f_finish(s, events, "HTF data gap", b.closedAt, b.c)
                    else if age == 3
                        s.c2Open := b.po
                        s.c2High := b.ph
                        s.c2Low := b.pl
                        s.c2Close := b.pc
                        s.c2KnownTime := b.closedAt
                        s.c2Valid := b.pc > s.c1Low and b.pc < s.c1High
                        s.c3Time := b.closedAt
                        s.c3Frame := b.frame
                        if s.c2Valid
                            s.closure := 2
                            s.closureTime := b.closedAt
                            s.invalidLevel := s.dir == 1 ? b.pl : b.ph
                            s.status := "C2 closed / C3 watch"
                            e.confirmed += 1
                            f_event(events, s, "C2_CLOSED", b.closedAt, b.pc, "C2 closed strictly inside C1")
                        else
                            s.status := "C2 failed / C3 reversal watch"
                            f_event(events, s, "C2_FAILED", b.closedAt, b.pc, "C2 did not close inside C1; retained")
                        f_event(events, s, "C3", b.closedAt, b.o, "Third HTF candle; no new trade required")
                    else if age == 4
                        if s.closure == 0
                            bool bodyBreak = s.dir == 1 ? b.pc > math.max(s.c2Open, s.c2Close) : b.pc < math.min(s.c2Open, s.c2Close)
                            bool held = s.c3Held and (s.dir == 1 ? b.pl >= s.c2Low : b.ph <= s.c2High)
                            if bodyBreak and held
                                s.closure := 3
                                s.closureTime := b.closedAt
                                s.invalidLevel := s.dir == 1 ? s.c2Low : s.c2High
                                e.confirmed += 1
                                f_event(events, s, "C3_CLOSED", b.closedAt, b.pc, "C3 body-break reversal; C2 extreme held")
                            else
                                f_finish(s, events, "No C2/C3 closure", b.closedAt, b.pc)
                        if not s.done
                            s.c3Strong := s.dir == 1 ? b.pc > s.c2High and b.pc > b.po : b.pc < s.c2Low and b.pc < b.po
                            s.c3Eq := (b.ph + b.pl) / 2
                            s.c4Time := b.closedAt
                            s.c4Frame := b.frame
                            s.status := s.c3Strong ? "C4 expansion watch" : "C4 / weak C3 close"
                            f_event(events, s, "C4", b.closedAt, b.o, s.status)
                    else if age >= 5
                        f_finish(s, events, s.closure > 0 ? "C4 window complete" : "Unconfirmed", b.closedAt, b.pc)

                if not s.done
                    if age == 3 and s.closure == 0
                        s.c3Held := s.c3Held and (s.dir == 1 ? b.l >= s.c2Low : b.h <= s.c2High)
                    // Only a developing C2 can move the candidate extreme and its series.
                    bool extends = age == 2 and (s.dir == 1 ? b.l < s.ext : b.h > s.ext)
                    if na(s.cisdTime) and extends
                        s.ext := s.dir == 1 ? b.l : b.h
                        s.extremeTime := b.stamp
                        s.anchor := s.dir == 1 ? e.lastBearOpen : e.lastBullOpen
                        s.anchorTime := s.dir == 1 ? e.lastBearTime : e.lastBullTime
                        s.bodyExt := s.dir == 1 ? e.lastBearBody : e.lastBullBody
                    // A failed early trigger remains a fact; HTF closure is evaluated separately.
                    if not na(s.cisdTime) and not s.cisdFailed and b.closedAt > s.cisdTime
                        bool earlyBroken = s.dir == 1 ? (wickInvalid ? b.l < s.ext : b.c < s.ext) : (wickInvalid ? b.h > s.ext : b.c > s.ext)
                        if earlyBroken
                            s.cisdFailed := true
                            s.cisdFailTime := b.closedAt
                            f_event(events, s, "CISD_FAILED", b.closedAt, b.c, "Frozen CISD extreme violated; earlier signal retained")
                    // No new C4 CISD. C2 early and C3 confirmations remain visibly distinct from HTF closure.
                    if na(s.cisdTime) and age <= 3 and not na(s.anchor)
                        float origin = useBody ? s.bodyExt : s.ext
                        float signedLeg = (s.anchor - origin) * s.dir
                        bool crossed = s.dir == 1 ? b.c > s.anchor : b.c < s.anchor
                        if crossed and not na(origin) and signedLeg > 0
                            s.cisd := s.anchor
                            s.cisdTime := b.closedAt
                            s.cisdFrame := b.frame
                            s.projOrigin := origin
                            s.unit := signedLeg
                            f_event(events, s, "CISD", b.closedAt, s.cisd, age == 2 ? "Early C2 CISD; HTF closure still pending" : "C3 CISD")
                    if s.closure > 0
                        bool broken = s.dir == 1 ? (wickInvalid ? b.l < s.invalidLevel : b.c < s.invalidLevel) : (wickInvalid ? b.h > s.invalidLevel : b.c > s.invalidLevel)
                        if broken
                            e.invalidated += 1
                            f_finish(s, events, "Invalidated", b.closedAt, b.c)
                    if not s.done
                        // FVG is optional context: only a gap observed since this extreme, never a backfilled entry.
                        if not na(s.cisdTime) and not s.cisdFailed and na(s.fvgTime) and not na(e.prev2Time) and e.prev2Time >= s.extremeTime
                            bool gap = s.dir == 1 ? b.l > e.prev2High : b.h < e.prev2Low
                            if gap
                                s.fvgTime := b.closedAt
                                s.fvgTop := s.dir == 1 ? b.l : e.prev2Low
                                s.fvgBot := s.dir == 1 ? e.prev2High : b.h
                                f_event(events, s, "FVG", b.closedAt, (s.fvgTop + s.fvgBot) / 2, "First newly observed FVG after CISD")
                        if not na(s.fvgTime) and na(s.touchTime) and b.closedAt > s.fvgTime and b.h >= s.fvgBot and b.l <= s.fvgTop
                            s.touchTime := b.closedAt
                            f_event(events, s, "RETEST", b.closedAt, b.c, "Range overlaps known FVG; context, not an entry")
                        float liquidity = s.dir == 1 ? s.c1High : s.c1Low
                        if s.closure > 0 and na(s.liqTime) and (s.dir == 1 ? b.h >= liquidity : b.l <= liquidity)
                            s.liqTime := b.closedAt
                            f_event(events, s, "LIQUIDITY", b.closedAt, liquidity, "C1 opposite extreme reached after closure; setup retained")

    // A wick beyond C1 starts a candidate even if the LTF bar is still outside C1.
    // Deduplicate by HTF time + side, not by trade state. Both sides of an outside bar survive.
    if e.ready and not na(b.ph) and not na(b.pl)
        bool bullSweep = b.l < b.pl
        bool bearSweep = b.h > b.ph
        for direction = -1 to 1 by 2
            bool detected = direction == 1 ? bullSweep and not e.seededBull : bearSweep and not e.seededBear
            if detected
                Setup s = Setup.new()
                s.key := str.tostring(b.frame) + (direction == 1 ? "-L" : "-S")
                s.dir := direction
                s.frameNo := e.frameNo
                s.c1Time := b.pt
                s.c2Time := b.frame
                s.seenTime := b.closedAt
                s.c1High := b.ph
                s.c1Low := b.pl
                s.seedExt := direction == 1 ? b.l : b.h
                s.ext := s.seedExt
                s.extremeTime := b.stamp
                s.anchor := direction == 1 ? e.lastBearOpen : e.lastBullOpen
                s.anchorTime := direction == 1 ? e.lastBearTime : e.lastBullTime
                s.bodyExt := direction == 1 ? e.lastBearBody : e.lastBullBody
                s.dualSweep := bullSweep and bearSweep
                array.push(book, s)
                if e.seededBull or e.seededBear
                    for sibling in book
                        if sibling.c2Time == b.frame
                            sibling.dualSweep := true
                e.total += 1
                if direction == 1
                    e.seededBull := true
                else
                    e.seededBear := true
                f_event(events, s, "SWEEP", b.closedAt, direction == 1 ? b.pl : b.ph, s.dualSweep ? "Both C1 extremes swept; order unknown" : "C2 candidate; awaiting HTF close")
                // Same-bar CISD is knowable at this close; never infer intrabar sweep/close fills.
                float origin = useBody ? s.bodyExt : s.ext
                float signedLeg = (s.anchor - origin) * direction
                bool crossed = direction == 1 ? b.c > s.anchor : b.c < s.anchor
                if not na(s.anchor) and not na(origin) and signedLeg > 0 and crossed
                    s.cisd := s.anchor
                    s.cisdTime := b.closedAt
                    s.cisdFrame := b.frame
                    s.projOrigin := origin
                    s.unit := signedLeg
                    f_event(events, s, "CISD", b.closedAt, s.cisd, "Early C2 CISD; HTF closure still pending")

    // Capacity is the ONLY removal path. Preserve live records; evict oldest finished first.
    while array.size(book) > keep
        int removeAt = na
        for i = 0 to array.size(book) - 1
            if na(removeAt) and array.get(book, i).done
                removeAt := i
        if na(removeAt)
            break
        array.remove(book, removeAt)
        e.evicted += 1
    e.prev2High := e.prevHigh
    e.prev2Low := e.prevLow
    e.prev2Time := e.prevTime
    e.prevHigh := b.h
    e.prevLow := b.l
    e.prevTime := b.stamp

// Delivery review is a separate, causal assessment of raw structural observations.
// Thresholds below are disclosed implementation heuristics, not TTrades' exact rules.
type ContextRules
    int maxVBars = 3
    float minEfficiency = 0.7
    float minBodyAtr = 0.8
    float minBodyFraction = 0.6
    float minBreakAtr = 0.05
    float chopOverlap = 0.7
    int repeatedSweeps = 3
    bool useChop = true
    int minSamples = 14
type LocalSweep
    int dir = 0
    int stamp = na
    float level = na
    int pivotTime = na
    int knownTime = na
type ContextState
    array<FmBar> tape = na
    array<FmBar> frames = na
    array<LocalSweep> localSweeps = na
    float atr = na
    float atrBefore = na
    int samples = 0
    int frame = na
    float previousClose = na
    float pivotLow = na
    float pivotHigh = na
    int pivotLowTime = na
    int pivotHighTime = na
    int pivotLowKnown = na
    int pivotHighKnown = na
    bool lowTaken = false
    bool highTaken = false
    int reviews = 0
    int withdrawals = 0
type ContextRecord
    string key = ""
    int dir = 0
    int trackedExtreme = na
    int legBars = 0
    float legPath = 0
    float legClose = na
    float efficiency = na
    float bodyAtr = na
    float bodyFraction = na
    float breakAtr = na
    bool measured = false
    bool vShape = false
    bool displacement = false
    bool chop = false
    int reviewTime = na
    float reviewPrice = na
    string reviewModel = ""
    string evidence = ""
    string reason = "Waiting for closure and delivery"
    string lifecycle = "Assessing"
    int endedAt = na
    float endPrice = na
    int internalSweepTime = na
    float internalLevel = na

f_newContextState() =>
    ContextState.new(tape = array.new<FmBar>(), frames = array.new<FmBar>(), localSweeps = array.new<LocalSweep>())

f_contextFind(array<ContextRecord> records, string key) =>
    ContextRecord found = na
    for item in records
        if item.key == key
            found := item
            break
    found

f_contextActive(ContextRecord item) =>
    not na(item) and not na(item.reviewTime) and na(item.endedAt)

f_contextNumber(float value) => na(value) ? "unknown" : str.tostring(value, "0.00")

f_contextOverlap(FmBar a, FmBar b) =>
    float denominator = math.min(a.h - a.l, b.h - b.l)
    denominator > 0 ? math.max(0, math.min(a.h, b.h) - math.max(a.l, b.l)) / denominator : 1.0

f_contextChop(ContextState state, array<Setup> book, ContextRules rules) =>
    bool result = false
    if rules.useChop and array.size(state.frames) >= 3
        int n = array.size(state.frames)
        FmBar older = array.get(state.frames, n - 3)
        FmBar middle = array.get(state.frames, n - 2)
        FmBar latest = array.get(state.frames, n - 1)
        int count = 0
        for s in book
            if s.c2Time >= older.stamp and s.c2Time <= latest.stamp
                count += 1
        result := count >= rules.repeatedSweeps and f_contextOverlap(older, middle) >= rules.chopOverlap and f_contextOverlap(middle, latest) >= rules.chopOverlap
    result

// No labels are backdated: local pivots become known after their right-hand bar closes.
// This is a local swing sweep / possible inducement sequence, not inferred intent,
// and not TTrades' 'internal liquidity', which refers to FVGs.
f_contextLocalSwings(ContextState state, FmBar b) =>
    if not na(state.pivotLow) and not state.lowTaken and state.pivotLowKnown <= b.stamp and b.l < state.pivotLow
        state.lowTaken := true
        if b.c > state.pivotLow
            array.push(state.localSweeps, LocalSweep.new(1, b.closedAt, state.pivotLow, state.pivotLowTime, state.pivotLowKnown))
    if not na(state.pivotHigh) and not state.highTaken and state.pivotHighKnown <= b.stamp and b.h > state.pivotHigh
        state.highTaken := true
        if b.c < state.pivotHigh
            array.push(state.localSweeps, LocalSweep.new(-1, b.closedAt, state.pivotHigh, state.pivotHighTime, state.pivotHighKnown))
    if array.size(state.tape) >= 2
        FmBar left = array.get(state.tape, array.size(state.tape) - 2)
        FmBar middle = array.get(state.tape, array.size(state.tape) - 1)
        if middle.l < left.l and middle.l < b.l
            state.pivotLow := middle.l
            state.pivotLowTime := middle.stamp
            state.pivotLowKnown := b.closedAt
            state.lowTaken := false
        if middle.h > left.h and middle.h > b.h
            state.pivotHigh := middle.h
            state.pivotHighTime := middle.stamp
            state.pivotHighKnown := b.closedAt
            state.highTaken := false
    while array.size(state.localSweeps) > 32
        array.shift(state.localSweeps)

f_contextStep(ContextState state, array<ContextRecord> records, array<FmEvent> reviewEvents, array<Setup> book, ContextRules rules, FmBar b) =>
    array.clear(reviewEvents)
    state.atrBefore := state.atr
    bool warm = state.samples >= rules.minSamples and not na(state.atrBefore) and state.atrBefore > 0
    if na(state.frame) or state.frame != b.frame
        state.frame := b.frame
        if not na(b.pt)
            FmBar closedFrame = FmBar.new(b.po, b.ph, b.pl, b.pc, b.pt, b.frame, b.pt)
            array.push(state.frames, closedFrame)
            if array.size(state.frames) > 3
                array.shift(state.frames)
    f_contextLocalSwings(state, b)
    bool rangeChop = f_contextChop(state, book, rules)
    map<string, ContextRecord> byKey = map.new<string, ContextRecord>()
    map<string, bool> retainedKeys = map.new<string, bool>()
    for item in records
        map.put(byKey, item.key, item)
    for s in book
        map.put(retainedKeys, s.key, true)
        ContextRecord q = map.contains(byKey, s.key) ? map.get(byKey, s.key) : na
        if na(q)
            q := ContextRecord.new(key = s.key, dir = s.dir)
            // Only a separately observed, earlier local sweep can supply this note.
            // Same-bar outer and local sweeps have unknown ordering and do not qualify.
            for local in state.localSweeps
                if local.dir == s.dir and local.stamp <= b.stamp and local.stamp < s.seenTime and local.stamp >= s.c1Time and local.level > s.c1Low and local.level < s.c1High
                    q.internalSweepTime := local.stamp
                    q.internalLevel := local.level
            array.push(records, q)
            map.put(byKey, s.key, q)
        if not q.measured and not s.done
            if na(q.trackedExtreme) or q.trackedExtreme != s.extremeTime
                q.trackedExtreme := s.extremeTime
                q.legBars := 1
                q.legPath := math.abs(b.c - s.ext)
            else
                q.legBars += 1
                q.legPath += math.abs(b.c - q.legClose)
            q.legClose := b.c
            if not na(s.cisdTime)
                q.measured := true
                q.efficiency := q.legPath > 0 ? math.min(1, math.max(0, (b.c - s.ext) * s.dir) / q.legPath) : 0
                q.bodyAtr := warm ? math.abs(b.c - b.o) / state.atrBefore : na
                q.bodyFraction := b.h > b.l ? math.abs(b.c - b.o) / (b.h - b.l) : 0
                q.breakAtr := warm ? (b.c - s.cisd) * s.dir / state.atrBefore : na
                bool decisive = warm and q.breakAtr >= rules.minBreakAtr
                q.vShape := decisive and q.legBars <= rules.maxVBars and q.efficiency >= rules.minEfficiency
                q.displacement := decisive and (b.c - b.o) * s.dir > 0 and q.bodyAtr >= rules.minBodyAtr and q.bodyFraction >= rules.minBodyFraction
                q.reviewModel := q.vShape and q.displacement ? "V + displacement" : q.vShape ? "V reversal" : q.displacement ? "Displacement" : "Marginal / slow CISD"
                q.evidence := "CISD quality observed at " + str.tostring(b.closedAt) + "; bars from extreme=" + str.tostring(q.legBars) + "; path efficiency=" + f_contextNumber(q.efficiency) + "; body/prior ATR=" + f_contextNumber(q.bodyAtr) + "; body/range=" + f_contextNumber(q.bodyFraction) + "; close beyond CISD/prior ATR=" + f_contextNumber(q.breakAtr) + ". Configurable proxies; POI and higher bias remain manual."
                q.evidence += na(q.internalSweepTime) ? " No separately known prior local swing sweep; inducement intent unknown." : " Earlier local swing sweep/reclaim observed at " + str.tostring(q.internalSweepTime) + "; level=" + str.tostring(q.internalLevel, "0.################") + ". Possible inducement context, not proof of intent."
        q.chop := rangeChop
        bool paired = s.closure == 2 ? s.cisdFrame == s.c2Time : s.closure == 3 ? s.cisdFrame == s.c3Frame : false
        string blocker = s.done ? s.status : s.cisdFailed ? "Frozen CISD failed" : s.dualSweep ? "Two-sided sweep / direction unresolved" : not na(s.liqTime) ? "C1 objective already reached" : rangeChop ? "Repeated sweeps in overlapping HTF ranges" : not q.measured ? "Waiting for CISD" : na(q.bodyAtr) ? "Insufficient prior volatility history at first CISD; no later reassessment" : not (q.vShape or q.displacement) ? "Marginal or slow CISD; delivery unclear" : s.closure == 0 ? "Waiting for HTF closure" : not paired ? "CISD and closure belong to different stages" : ""
        if na(q.reviewTime)
            q.reason := blocker == "" ? "Delivery checks met; POI / bias manual" : blocker
            q.lifecycle := s.done or s.cisdFailed or s.dualSweep or (q.measured and (na(q.bodyAtr) or not (q.vShape or q.displacement))) ? "Excluded" : "Assessing"
            if blocker == ""
                q.reviewTime := b.closedAt
                q.reviewPrice := b.c
                q.lifecycle := "Review"
                state.reviews += 1
                f_event(reviewEvents, s, "DELIVERY_REVIEW", b.closedAt, b.c, q.reviewModel + "; " + q.evidence + " Chop check clear when reviewed. This is not full model validation or an entry.")
        else if na(q.endedAt) and blocker != ""
            q.endedAt := b.closedAt
            q.endPrice := b.c
            q.reason := blocker
            q.lifecycle := s.done and s.status == "C4 window complete" ? "Complete" : "Withdrawn"
            state.withdrawals += 1
            f_event(reviewEvents, s, "REVIEW_END", b.closedAt, b.c, blocker + "; original review retained")
    // Retention follows the raw ledger only; a noisy or failed record is not erased.
    int i = array.size(records) - 1
    while i >= 0
        if not map.contains(retainedKeys, array.get(records, i).key)
            array.remove(records, i)
        i -= 1
    float tr = na(state.previousClose) ? b.h - b.l : math.max(b.h - b.l, math.max(math.abs(b.h - state.previousClose), math.abs(b.l - state.previousClose)))
    state.samples += 1
    state.atr := na(state.atr) ? tr : state.samples <= 14 ? (state.atr * (state.samples - 1) + tr) / state.samples : (state.atr * 13 + tr) / 14
    state.previousClose := b.c
    array.push(state.tape, b)
    if array.size(state.tape) > 3
        array.shift(state.tape)

// Independent IC continuation observations. No orders and no parent-state mutation.
// One attempt per reviewed parent per C3/C4 frame. Parent review must precede the
// opposing leg. Anatomy and the stricter FVG/delivery review are separate facts.
// The HTF-open wick, parent-FVG and ATR rules are disclosed product heuristics.
type IcRecord
    string key = ""
    string parentKey = ""
    int dir = 0
    int frame = na
    int stage = 0
    int parentReviewTime = na
    int legTime = na
    int seenTime = na
    float level = na
    float frameOpen = na
    float legExtreme = na
    bool openSwept = false
    float leftHigh = na
    float leftLow = na
    float middleHigh = na
    float middleLow = na
    int middleTime = na
    float swingLevel = na
    int swingTime = na
    int swingKnownTime = na
    int formedTime = na
    float formedPrice = na
    float protectedLevel = na
    int protectedTime = na
    int protectedKnownTime = na
    int poiTime = na
    int poiKnownTime = na
    float poiTop = na
    float poiBot = na
    int reviewTime = na
    float bodyAtr = na
    float bodyFraction = na
    float breakAtr = na
    int takenTime = na
    int endedAt = na
    string formationReason = ""
    string endReason = ""
    string reason = "Opposing leg; waiting for swing and close-through"

f_icFind(array<IcRecord> records, string key) =>
    IcRecord found = na
    for item in records
        if item.key == key
            found := item
            break
    found

f_icParent(array<Setup> setups, string key) =>
    Setup found = na
    for item in setups
        if item.key == key
            found := item
            break
    found

f_icActive(IcRecord item) =>
    not na(item) and not na(item.reviewTime) and na(item.takenTime) and na(item.endedAt)

f_icEmit(array<FmEvent> events, IcRecord item, string kind, int stamp, float price, string detail) =>
    // Copy scalar values into a new event; later lifecycle changes cannot rewrite it.
    array.push(events, FmEvent.new(item.key, kind, stamp, price, item.dir, "ic_reviewed=" + str.tostring(not na(item.reviewTime)) + "; parent=" + item.parentKey + "; " + detail))

f_icEnd(IcRecord item, array<FmEvent> events, FmBar b, string reason) =>
    if na(item.endedAt)
        item.endedAt := b.closedAt
        item.endReason := reason
        item.reason := reason
        f_icEmit(events, item, "IC_END", b.closedAt, b.c, reason + "; original observations retained")

f_icObservePoi(IcRecord item, Setup parent, FmBar b) =>
    // A gap first created by this bar is not available at its open. Equality
    // permits a gap known at the preceding close, before the current bar begins.
    if na(item.poiTime) and not na(parent.fvgTime) and parent.fvgTime <= b.stamp and parent.fvgTop > parent.fvgBot and b.h >= parent.fvgBot and b.l <= parent.fvgTop
        item.poiTime := b.closedAt
        item.poiKnownTime := parent.fvgTime
        item.poiTop := parent.fvgTop
        item.poiBot := parent.fvgBot

f_icProgress(IcRecord item, Setup parent, array<FmEvent> events, ContextState state, ContextRules rules, FmBar b) =>
    f_icObservePoi(item, parent, b)
    item.legExtreme := item.dir == 1 ? math.min(item.legExtreme, b.l) : math.max(item.legExtreme, b.h)
    item.openSwept := item.openSwept or (item.dir == 1 ? b.l < item.frameOpen : b.h > item.frameOpen)
    // Current bar is the right neighbor. No swing is known at its middle bar.
    bool strictSwing = item.dir == 1 ? item.middleLow < item.leftLow and item.middleLow < b.l : item.middleHigh > item.leftHigh and item.middleHigh > b.h
    float candidate = item.dir == 1 ? item.middleLow : item.middleHigh
    if item.middleTime >= item.legTime and strictSwing
        if na(item.swingLevel) or (item.dir == 1 ? candidate < item.swingLevel : candidate > item.swingLevel)
            item.swingLevel := candidate
            item.swingTime := item.middleTime
            item.swingKnownTime := b.closedAt
    bool crossed = (b.c - item.level) * item.dir > 0
    // The stored swing must still be the actual leg extreme; a lower/higher
    // unconfirmed current wick cannot leave an already-broken protected swing.
    bool holds = not na(item.swingLevel) and item.swingLevel == item.legExtreme
    if b.stamp > item.legTime and item.openSwept and crossed and holds
        item.formedTime := b.closedAt
        item.formedPrice := b.c
        item.protectedLevel := item.swingLevel
        item.protectedTime := item.swingTime
        item.protectedKnownTime := item.swingKnownTime
        bool warm = state.samples > rules.minSamples and not na(state.atrBefore) and state.atrBefore > 0
        item.bodyAtr := warm ? math.abs(b.c - b.o) / state.atrBefore : na
        item.bodyFraction := b.h > b.l ? math.abs(b.c - b.o) / (b.h - b.l) : 0
        item.breakAtr := warm ? (b.c - item.level) * item.dir / state.atrBefore : na
        bool decisive = warm and (b.c - b.o) * item.dir > 0 and item.bodyAtr >= rules.minBodyAtr and item.bodyFraction >= rules.minBodyFraction and item.breakAtr >= rules.minBreakAtr
        item.formationReason := na(item.poiTime) ? "IC anatomy; parent FVG POI not observed" : not warm ? "IC anatomy; insufficient prior volatility history" : not decisive ? "IC anatomy; decisive delivery check not met" : "IC FVG and delivery checks met; higher bias / full POI context manual"
        item.reason := item.formationReason
        f_icEmit(events, item, "IC_ANATOMY", b.closedAt, b.c, "Fixed opposing open crossed after a strict local swing; protected price=" + str.tostring(item.protectedLevel, "0.################") + "; swing time=" + str.tostring(item.protectedTime) + "; " + item.formationReason)
        if not na(item.poiTime) and decisive
            item.reviewTime := b.closedAt
            f_icEmit(events, item, "IC_REVIEW", b.closedAt, b.c, "Previously known parent FVG overlapped; decisive close met configurable ATR/body checks; nested continuation observation, not an entry")
    item.leftHigh := item.middleHigh
    item.leftLow := item.middleLow
    item.middleHigh := b.h
    item.middleLow := b.l
    item.middleTime := b.stamp

// Call after f_step and f_contextStep, once per confirmed chart bar. Keep the IC
// event buffer separate from raw/context events; callers may concatenate copies.
f_icStep(array<IcRecord> icBook, array<FmEvent> icEvents, array<Setup> setups, array<ContextRecord> contexts, Engine engine, ContextState state, ContextRules rules, FmBar b, int keep) =>
    array.clear(icEvents)
    for item in icBook
        // Continue marking taken swings even after their frame/parent has ended,
        // while the completed record remains inside the disclosed retention cap.
        if not na(item.formedTime) and na(item.takenTime) and b.stamp >= item.formedTime
            bool taken = item.dir == 1 ? b.l < item.protectedLevel : b.h > item.protectedLevel
            if taken
                item.takenTime := b.closedAt
                item.reason := "Protected IC swing taken; parent record unchanged"
                f_icEmit(icEvents, item, "IC_TAKEN", b.closedAt, item.protectedLevel, item.reason)
                if na(item.endedAt)
                    item.endedAt := b.closedAt
                    item.endReason := "Protected IC swing taken"
        if na(item.endedAt)
            Setup parent = f_icParent(setups, item.parentKey)
            ContextRecord context = f_contextFind(contexts, item.parentKey)
            if b.frame != item.frame
                f_icEnd(item, icEvents, b, "IC frame ended")
            else if na(parent)
                f_icEnd(item, icEvents, b, "Parent left retained history")
            else if not f_contextActive(context) or parent.done or parent.stage < 3 or parent.stage > 4
                f_icEnd(item, icEvents, b, "Parent review ended or withdrawn")
            else if na(item.formedTime)
                f_icProgress(item, parent, icEvents, state, rules, b)

    for parent in setups
        ContextRecord context = f_contextFind(contexts, parent.key)
        bool eligible = f_contextActive(context) and not parent.done and (parent.stage == 3 or parent.stage == 4)
        if eligible
            // The raw engine has just consumed this bar. A run that started before
            // parent review cannot acquire a parent retroactively partway through.
            bool firstOppositeBody = engine.runDir == -parent.dir and engine.runTime == b.stamp
            bool parentKnown = context.reviewTime <= b.stamp
            string key = parent.key + ":IC:" + str.tostring(b.frame) + ":1"
            if firstOppositeBody and parentKnown and na(f_icFind(icBook, key))
                IcRecord item = IcRecord.new()
                item.key := key
                item.parentKey := parent.key
                item.dir := parent.dir
                item.frame := b.frame
                item.stage := parent.stage
                item.parentReviewTime := context.reviewTime
                item.legTime := b.stamp
                item.seenTime := b.closedAt
                item.level := b.o
                item.frameOpen := engine.frameOpen
                item.legExtreme := parent.dir == 1 ? b.l : b.h
                item.openSwept := parent.dir == 1 ? b.l < engine.frameOpen : b.h > engine.frameOpen
                // f_step updates prev2 to the bar immediately preceding b.
                item.leftHigh := engine.prev2High
                item.leftLow := engine.prev2Low
                item.middleHigh := b.h
                item.middleLow := b.l
                item.middleTime := b.stamp
                f_icObservePoi(item, parent, b)
                array.push(icBook, item)

    // Keep current-frame completed records as deduplication tombstones. The cap
    // may temporarily exceed keep when all records are active/current-frame.
    while array.size(icBook) > keep
        int removeAt = na
        for i = 0 to array.size(icBook) - 1
            IcRecord item = array.get(icBook, i)
            if na(removeAt) and not na(item.endedAt) and item.frame != b.frame
                removeAt := i
        if na(removeAt)
            break
        array.remove(icBook, removeAt)
    array.size(icBook)

gModel = "Structure"
inAuto = input.bool(true, "Automatic HTF pairing", group = gModel)
inTf = input.timeframe("60", "Manual higher timeframe", group = gModel)
inBody = input.bool(false, "Projection anchor: body (default wick)", group = gModel, tooltip = "Origin and leg use the same anchor. 1x equals frozen CISD. These are leg multiples, not statistical standard deviations.")
inWickInvalid = input.bool(true, "Invalidate on wick through extreme (off = close)", group = gModel, tooltip = "Strictly beyond; equal touches do not invalidate. Failed early CISD is retained separately from HTF closure.")
inHistory = input.int(24, "Setups retained", minval = 8, maxval = 40, group = gModel, tooltip = "Developing, confirmed, failed and completed setups. Only oldest completed records are evicted at capacity. Live setups are preserved.")
inJson = input.bool(true, "JSON event batch alerts", group = "Alerts", tooltip = "One payload per confirmed bar contains all events and original setup IDs. Create an Any alert() function call alert.")
inAlertScope = input.string("Delivery review", "Event stream", options = ["Delivery review", "All observations"], group = "Alerts", tooltip = "Default: automated delivery reviews, IC reviews and their later outcomes. All observations also includes neutral raw sweeps, CISD and stage facts. Neither stream is a buy/sell instruction.")
gContext = "Delivery review · disclosed proxies"
inVMax = input.int(3, "V reversal: maximum bars from extreme", minval = 1, maxval = 12, group = gContext)
inEfficiency = input.float(0.7, "V reversal: minimum path efficiency", minval = 0.1, maxval = 1, step = 0.05, group = gContext, tooltip = "Net directional travel from the wick divided by total close-to-close travel, including the extreme-to-close segment. A configurable approximation of a clean reversal.")
inBodyAtr = input.float(0.8, "Displacement: minimum body / prior ATR14", minval = 0.1, maxval = 3, step = 0.1, group = gContext)
inBodyFraction = input.float(0.6, "Displacement: minimum body / range", minval = 0.1, maxval = 1, step = 0.05, group = gContext)
inBreakAtr = input.float(0.05, "Decisive close: distance past CISD / prior ATR14", minval = 0.01, maxval = 1, step = 0.01, group = gContext)
inChop = input.bool(true, "Pause reviews in repeated overlapping ranges", group = gContext)
inOverlap = input.float(0.7, "Chop: minimum pairwise overlap of 3 closed HTFs", minval = 0.1, maxval = 1, step = 0.05, group = gContext)
inRepeat = input.int(3, "Chop: sweep observations across those 3 HTFs", minval = 2, maxval = 6, group = gContext, tooltip = "Both adjacent overlaps must pass and the sweep count must reach this threshold. This is a declared noise heuristic, not a universal regime detector.")
int chartSeconds = timeframe.in_seconds()
string autoTf = chartSeconds <= 60 ? "15" : chartSeconds <= 300 ? "60" : chartSeconds <= 900 ? "240" : chartSeconds <= 3600 ? "1D" : chartSeconds <= 14400 ? "1W" : "1M"
string htfTf = inAuto ? autoTf : inTf
if barstate.isfirst and (not chart.is_standard or na(chartSeconds) or timeframe.in_seconds(htfTf) <= chartSeconds)
    runtime.error("Use standard time-based bars and an HTF strictly greater than the chart timeframe.")
[pO1, pH1, pL1, pC1, pT1, pO2, pH2, pL2, pC2, pT2, pO3, pH3, pL3, pC3, pT3] = request.security(syminfo.tickerid, htfTf, [open[1], high[1], low[1], close[1], time[1], open[2], high[2], low[2], close[2], time[2], open[3], high[3], low[3], close[3], time[3]], lookahead = barmerge.lookahead_on)
int htfTime = time(htfTf)
int htfEnd = time_close(htfTf)
if not na(htfEnd) and time_close > htfEnd
    runtime.error("Chart bars must fit entirely inside the selected HTF. Choose an aligned pair such as 5m / 1H.")
var array<Setup> setups = array.new<Setup>()
var Engine engine = Engine.new()
var array<FmEvent> events = array.new<FmEvent>()
var array<ContextRecord> contexts = array.new<ContextRecord>()
var ContextState contextState = f_newContextState()
var ContextRules contextRules = ContextRules.new(maxVBars = inVMax, minEfficiency = inEfficiency, minBodyAtr = inBodyAtr, minBodyFraction = inBodyFraction, minBreakAtr = inBreakAtr, chopOverlap = inOverlap, repeatedSweeps = inRepeat, useChop = inChop)
var array<FmEvent> reviewEvents = array.new<FmEvent>()
var array<IcRecord> icBook = array.new<IcRecord>()
var array<FmEvent> icEvents = array.new<FmEvent>()
if barstate.isconfirmed
    FmBar b = FmBar.new(open, high, low, close, time, time_close, htfTime, pO1, pH1, pL1, pC1, pT1)
    f_step(engine, setups, events, b, inHistory, inBody, inWickInvalid)
    f_contextStep(contextState, contexts, reviewEvents, setups, contextRules, b)
    f_icStep(icBook, icEvents, setups, contexts, engine, contextState, contextRules, b, 24)
plot(engine.total, "Audit / candidates observed", display = display.data_window)
plot(engine.confirmed, "Audit / HTF closures", display = display.data_window)
plot(engine.invalidated, "Audit / structural invalidations", display = display.data_window)
plot(engine.evicted, "Audit / capacity evictions", display = display.data_window)
plot(contextState.reviews, "Review / automated delivery checks met", display = display.data_window)
plot(contextState.withdrawals, "Review / ended or withdrawn", display = display.data_window)

// Display owns its handles; the engine owns setup facts. A finished setup is never
// removed by the renderer. Handles disappear only after its key leaves retention.
string fmVisualGroup = "Display · setup history"
string fmView = input.string("Focus", "View", options=["Focus", "Audit"], group=fmVisualGroup, tooltip="Focus shows the two most recently observed delivery reviews, including later withdrawn or completed reviews. Audit reveals retained raw observations. Display filtering never deletes engine history.")
string fmPalette = input.string("Colorblind", "Direction palette", options=["Colorblind", "Classic"], group=fmVisualGroup)
string fmProjectionScope = input.string("Latest review", "Projection visibility", options=["Latest review", "Selected reviews", "All retained", "Off"], group=fmVisualGroup, tooltip="Latest review uses observation time, never later success. Focus always limits projections to its two selected reviews; All retained is available in Audit. Prices remain frozen CISD-leg multiples, not statistical standard deviations.")
bool fmShowProjections = fmProjectionScope != "Off"
bool fmShowFvg = input.bool(true, "Show first FVG after CISD", group=fmVisualGroup, tooltip="Context only. Audit starts the box at gap observation; Focus starts no earlier than delivery review. A touch requires a later bar.")
bool fmShowStages = input.bool(false, "Audit: show C3 / C4 stage markers", group=fmVisualGroup)
bool fmShowDeveloping = input.bool(false, "Audit: preview developing CISD level", group=fmVisualGroup, tooltip="A neutral dashed rail for a pending observation. This level may move before confirmation; it is not a delivery review.")
bool fmShowHtf = input.bool(true, "Show higher-timeframe candles", group=fmVisualGroup)
bool fmShowDesk = input.bool(true, "Show recent setup ledger", group=fmVisualGroup)
bool fmShowIc = input.bool(true, "Show latest two IC observations", group=fmVisualGroup, tooltip="Focus shows the latest two IC delivery reviews, including later failures. Audit also shows neutral IC anatomy without known FVG or decisive delivery. IC history is independent of parent structure; 24 records retained with active/current-frame overflow protected.")
string fmDeskPosition = input.string("Bottom right", "Ledger position", options=["Bottom right", "Bottom left", "Top right", "Top left"], group=fmVisualGroup)
string fmDeskText = input.string("Small", "Ledger text size", options=["Small", "Normal", "Tiny"], group=fmVisualGroup)
string fmTablePosition = fmDeskPosition == "Bottom left" ? position.bottom_left : fmDeskPosition == "Top right" ? position.top_right : fmDeskPosition == "Top left" ? position.top_left : position.bottom_right
string fmTableSize = fmDeskText == "Normal" ? size.normal : fmDeskText == "Tiny" ? size.tiny : size.small
color fmBull = fmPalette == "Colorblind" ? color.rgb(0, 158, 173) : color.rgb(34, 171, 148)
color fmBear = fmPalette == "Colorblind" ? color.rgb(218, 139, 36) : color.rgb(239, 83, 80)
color fmInk = chart.fg_color
color fmPaper = chart.bg_color
color fmMuted = color.new(fmInk, 48)
color fmReview = color.rgb(56, 189, 248)
bool fmAudit = fmView == "Audit"
int fmDeskRows = fmAudit ? 9 : 6

type SetupInk
    string key = ""
    line reference = na
    line delivery = na
    line level1 = na
    line level2 = na
    line level25 = na
    line level4 = na
    line invalidation = na
    box gap = na
    label seed = na
    label cisd = na
    label c2 = na
    label c3 = na
    label c4 = na
    label earlyFailure = na
    label finish = na
    label gapSeen = na
    label gapTouch = na
    label liquidity = na
    label review = na
    label reviewOutcome = na

type CandleInk
    box body = na
    line wick = na
    label caption = na

var array<SetupInk> fmInks = array.new<SetupInk>()
var map<string, SetupInk> fmInkByKey = map.new<string, SetupInk>()
var array<CandleInk> fmCandles = array.new<CandleInk>()
var line fmPrevHigh = na
var line fmPrevLow = na
var line fmPrevEq = na
var line fmDeveloping = na
var label fmDevelopingCaption = na
var table fmDesk = table.new(fmTablePosition, 5, fmDeskRows, bgcolor=color.new(fmPaper, 8), border_color=color.new(fmInk, 88), border_width=1, frame_color=color.new(fmInk, 75), frame_width=1)

f_fmLine(line handle, int left, int right, float price, color ink, string style, int width) =>
    line result = handle
    if na(result)
        result := line.new(left, price, right, price, xloc=xloc.bar_time, extend=extend.none, color=ink, style=style, width=width)
    else
        line.set_xy1(result, left, price)
        line.set_xy2(result, right, price)
        line.set_color(result, ink)
    result

f_fmLabel(int stamp, float price, string captionText, color ink, string labelStyle, string tip) =>
    label.new(stamp, price, captionText, xloc=xloc.bar_time, yloc=yloc.price, color=color.new(fmPaper, 12), style=labelStyle, textcolor=ink, size=size.tiny, tooltip=tip)

f_fmTime(int stamp) =>
    na(stamp) ? "—" : str.format_time(stamp, "MM-dd HH:mm", syminfo.timezone)

f_fmPrice(float price) =>
    str.tostring(price, format.mintick)

f_fmLabelVisibility(label handle, bool visible, color ink) =>
    if not na(handle)
        label.set_textcolor(handle, visible ? ink : color.new(ink, 100))
        label.set_color(handle, color.new(fmPaper, visible ? 12 : 100))

f_fmShort(string value) =>
    str.length(value) > 38 ? str.substring(value, 0, 35) + "…" : value

f_fmErase(SetupInk ink) =>
    line.delete(ink.reference)
    line.delete(ink.delivery)
    line.delete(ink.level1)
    line.delete(ink.level2)
    line.delete(ink.level25)
    line.delete(ink.level4)
    line.delete(ink.invalidation)
    box.delete(ink.gap)
    label.delete(ink.seed)
    label.delete(ink.cisd)
    label.delete(ink.c2)
    label.delete(ink.c3)
    label.delete(ink.c4)
    label.delete(ink.earlyFailure)
    label.delete(ink.finish)
    label.delete(ink.gapSeen)
    label.delete(ink.gapTouch)
    label.delete(ink.liquidity)
    label.delete(ink.review)
    label.delete(ink.reviewOutcome)

f_fmPaint(Setup s, ContextRecord q, SetupInk ink, bool selected, string projectionKey) =>
    bool reviewed = not na(q) and not na(q.reviewTime)
    bool reviewVisible = reviewed and (fmAudit or selected)
    bool railsVisible = fmAudit or reviewVisible
    bool ended = reviewed and not na(q.endedAt)
    int observedEnd = na(s.endTime) ? time_close : s.endTime
    int right = not fmAudit and ended ? q.endedAt : observedEnd
    int reviewStart = reviewed ? q.reviewTime : s.seenTime
    color railInk = fmAudit ? fmMuted : color.new(fmReview, ended ? 78 : 35)
    string identity = "Observation " + s.key + "\nFirst seen " + f_fmTime(s.seenTime) + " (" + syminfo.timezone + ")"
    string seedStyle = s.dir == 1 ? label.style_label_up : label.style_label_down
    float reference = s.dir == 1 ? s.c1Low : s.c1High
    int referenceStart = fmAudit ? s.c1Time : math.max(s.c1Time, reviewStart)
    ink.reference := f_fmLine(ink.reference, referenceStart, right, reference, color.new(fmInk, railsVisible ? 78 : 100), line.style_dotted, 1)
    // Raw observations are permanently neutral. A later review gets a NEW marker.
    if na(ink.seed)
        ink.seed := f_fmLabel(s.seenTime, s.seedExt, s.dir == 1 ? "C2 · low swept" : "C2 · high swept", fmMuted, seedStyle, identity + "\nRaw C1 " + (s.dir == 1 ? "low " : "high ") + f_fmPrice(reference) + " sweep.\nThis is not a directional recommendation or a context-qualified model.\nAudit references the original candle; Focus begins its rails only when delivery review is observed.")
    if not na(s.cisdTime)
        int cisdStart = fmAudit ? s.cisdTime : math.max(s.cisdTime, reviewStart)
        bool deliveryVisible = railsVisible and (fmAudit or s.cisdTime <= right)
        ink.delivery := f_fmLine(ink.delivery, cisdStart, right, s.cisd, deliveryVisible ? railInk : color.new(fmInk, 100), line.style_solid, 1)
        if na(ink.cisd)
            string levels = "\nFrozen leg multiples, not statistical σ:\n1 = " + f_fmPrice(f_level(s, 1)) + " · 2 = " + f_fmPrice(f_level(s, 2)) + "\n2.5 = " + f_fmPrice(f_level(s, 2.5)) + " · 4 = " + f_fmPrice(f_level(s, 4))
            ink.cisd := f_fmLabel(s.cisdTime, s.cisd, "CISD observed", fmMuted, seedStyle, identity + "\nCandle-series open crossed at " + f_fmTime(s.cisdTime) + ".\nThis price observation alone does not pass delivery or POI checks." + levels)
        if fmShowProjections and not na(s.unit)
            bool projectionVisible = deliveryVisible and (fmProjectionScope == "All retained" or (fmProjectionScope == "Selected reviews" and selected) or s.key == projectionKey)
            color projectionInk = fmAudit ? fmInk : fmReview
            ink.level1 := f_fmLine(ink.level1, cisdStart, right, f_level(s, 1), color.new(projectionInk, projectionVisible ? (ended ? 85 : 72) : 100), line.style_dotted, 1)
            ink.level2 := f_fmLine(ink.level2, cisdStart, right, f_level(s, 2), color.new(projectionInk, projectionVisible ? (ended ? 82 : 54) : 100), line.style_dashed, 1)
            ink.level25 := f_fmLine(ink.level25, cisdStart, right, f_level(s, 2.5), color.new(projectionInk, projectionVisible ? (ended ? 85 : 66) : 100), line.style_dotted, 1)
            ink.level4 := f_fmLine(ink.level4, cisdStart, right, f_level(s, 4), color.new(projectionInk, projectionVisible ? (ended ? 85 : 72) : 100), line.style_dashed, 1)
    if not na(s.c2KnownTime)
        if na(ink.c2)
            string fact = s.c2Valid ? "C2 · inside C1" : "C2 · outside C1"
            ink.c2 := f_fmLabel(s.c2KnownTime, s.c2Close, fact, fmMuted, label.style_label_left, identity + "\nC2 closed " + (s.c2Valid ? "strictly inside" : "outside or on the boundary of") + " the entire C1 range.\nKnown " + f_fmTime(s.c2KnownTime) + ".\nThis is a closure fact, not delivery-context approval.")
        if not na(s.invalidLevel) and not na(s.closureTime)
            int invalidStart = fmAudit ? s.closureTime : math.max(s.closureTime, reviewStart)
            bool invalidVisible = railsVisible and (fmAudit or s.closureTime <= right)
            ink.invalidation := f_fmLine(ink.invalidation, invalidStart, right, s.invalidLevel, color.new(fmInk, invalidVisible ? 80 : 100), line.style_dashed, 1)
    if fmShowStages and not na(s.c3Time) and na(ink.c3)
        ink.c3 := f_fmLabel(s.c3Time, reference, "C3 stage", fmMuted, label.style_label_left, identity + "\nC3 stage observed " + f_fmTime(s.c3Time) + ". No context approval implied.")
    if (fmShowStages or s.closure == 3) and not na(s.c4Time) and na(ink.c4)
        ink.c4 := f_fmLabel(s.c4Time, reference, s.closure == 3 ? "C3 closure observed" : "C4 stage", fmMuted, label.style_label_left, identity + "\nObserved " + f_fmTime(s.c4Time) + ".\nC3 directional close beyond the C2 range: " + (s.c3Strong ? "yes" : "no") + ". Delivery review remains separate.")
    if s.cisdFailed and not na(s.cisdFailTime) and na(ink.earlyFailure)
        ink.earlyFailure := f_fmLabel(s.cisdFailTime, s.ext, "· CISD failed", fmMuted, label.style_label_left, identity + "\nFrozen sweep extreme violated " + f_fmTime(s.cisdFailTime) + ".\nOriginal observations stay recorded; structural invalidation is separate.")
    if fmShowFvg and not na(s.fvgTime)
        int gapStart = fmAudit ? s.fvgTime : math.max(s.fvgTime, reviewStart)
        bool gapVisible = railsVisible and (fmAudit or s.fvgTime <= right)
        if na(ink.gap)
            ink.gap := box.new(gapStart, s.fvgTop, right, s.fvgBot, xloc=xloc.bar_time, border_color=color.new(fmInk, 100), bgcolor=color.new(fmInk, 100))
            ink.gapSeen := f_fmLabel(s.fvgTime, s.dir == 1 ? s.fvgBot : s.fvgTop, "FVG observed", fmMuted, seedStyle, identity + "\nGap observed " + f_fmTime(s.fvgTime) + ".\n" + f_fmPrice(s.fvgBot) + " – " + f_fmPrice(s.fvgTop) + ".\nA gap alone does not pass delivery checks.")
        box.set_left(ink.gap, gapStart)
        box.set_right(ink.gap, right)
        box.set_border_color(ink.gap, color.new(fmAudit ? fmInk : fmReview, gapVisible ? 80 : 100))
        box.set_bgcolor(ink.gap, color.new(fmAudit ? fmInk : fmReview, gapVisible ? 96 : 100))
        if not na(s.touchTime) and na(ink.gapTouch)
            ink.gapTouch := f_fmLabel(s.touchTime, (s.fvgTop + s.fvgBot) / 2, "· FVG touch", fmMuted, label.style_label_left, identity + "\nLater bar overlap observed " + f_fmTime(s.touchTime) + ". Context only.")
    if not na(s.liqTime) and na(ink.liquidity)
        ink.liquidity := f_fmLabel(s.liqTime, s.dir == 1 ? s.c1High : s.c1Low, "C1 opposite level reached", fmMuted, label.style_label_left, identity + "\nOpposite C1 extreme reached " + f_fmTime(s.liqTime) + ".\nThis is not a trade result or setup-quality verdict.")
    if s.done and not na(s.endTime) and na(ink.finish)
        ink.finish := f_fmLabel(s.endTime, s.endPrice, "· " + s.status, fmMuted, label.style_label_left, identity + "\n" + s.status + " at " + f_fmTime(s.endTime) + ".\nRaw observation history remains available in Audit.")
    if reviewed and na(ink.review)
        string levels = "\nFrozen CISD " + f_fmPrice(s.cisd) + "\nLeg multiples: 1 = " + f_fmPrice(f_level(s, 1)) + " · 2 = " + f_fmPrice(f_level(s, 2)) + "\n2.5 = " + f_fmPrice(f_level(s, 2.5)) + " · 4 = " + f_fmPrice(f_level(s, 4))
        ink.review := f_fmLabel(q.reviewTime, q.reviewPrice, "Delivery review\nPOI / bias manual", fmReview, label.style_label_left, "Delivery checks observed " + f_fmTime(q.reviewTime) + " (" + syminfo.timezone + ")\nObservation " + s.key + "\nModel: " + q.reviewModel + "\nFrozen evidence: " + q.evidence + levels + "\nAutomated evidence for review; POI, bias and a trading decision remain manual.\nThis marker is never backdated to the original sweep.")
    if ended and na(ink.reviewOutcome)
        ink.reviewOutcome := f_fmLabel(q.endedAt, q.endPrice, q.lifecycle == "Withdrawn" ? "· Review withdrawn" : "· Review complete", fmMuted, label.style_label_left, "Delivery review " + s.key + "\n" + q.lifecycle + " at " + f_fmTime(q.endedAt) + " (" + syminfo.timezone + ")\n" + q.reason + "\nThe original review and its evidence remain unchanged.")
    // Opacity is a view choice. No event label is removed, moved, or recast as success.
    f_fmLabelVisibility(ink.seed, fmAudit, fmMuted)
    f_fmLabelVisibility(ink.cisd, fmAudit, fmMuted)
    f_fmLabelVisibility(ink.c2, fmAudit, fmMuted)
    f_fmLabelVisibility(ink.c3, fmAudit, fmMuted)
    f_fmLabelVisibility(ink.c4, fmAudit, fmMuted)
    f_fmLabelVisibility(ink.earlyFailure, fmAudit, color.new(fmInk, 65))
    f_fmLabelVisibility(ink.finish, fmAudit, color.new(fmInk, 65))
    f_fmLabelVisibility(ink.gapSeen, fmAudit, fmMuted)
    f_fmLabelVisibility(ink.gapTouch, fmAudit, fmMuted)
    f_fmLabelVisibility(ink.liquidity, fmAudit, fmMuted)
    f_fmLabelVisibility(ink.review, reviewVisible, fmReview)
    f_fmLabelVisibility(ink.reviewOutcome, reviewVisible, fmMuted)
    ink

// Reconcile by key, not array position; concurrent directions and adjacent models
// retain independent histories. Updating on EVERY close freezes completed rails
// identically in historical calculation, replay and subsequent real-time bars.
// Selection depends ONLY on immutable reviewTime. A later withdrawal/completion
// cannot remove an otherwise selected review or turn Focus into a winners filter.
int fmFirst = -1
int fmSecond = -1
int fmFirstTime = na
int fmSecondTime = na
int fmReviewCount = 0
int fmExcludedCount = 0
int fmAssessingCount = 0
int fmPendingIndex = -1
string fmProjectionKey = ""
string fmLatestReason = "Waiting for a raw observation"
if array.size(setups) > 0
    for i = 0 to array.size(setups) - 1
        Setup s = array.get(setups, i)
        ContextRecord q = f_contextFind(contexts, s.key)
        if not na(q)
            fmLatestReason := q.reason
            fmExcludedCount += q.lifecycle == "Excluded" ? 1 : 0
            fmAssessingCount += q.lifecycle == "Assessing" ? 1 : 0
            if not na(q.reviewTime)
                fmReviewCount += 1
                if na(fmFirstTime) or q.reviewTime >= fmFirstTime
                    fmSecond := fmFirst
                    fmSecondTime := fmFirstTime
                    fmFirst := i
                    fmFirstTime := q.reviewTime
                    fmProjectionKey := s.key
                else if na(fmSecondTime) or q.reviewTime >= fmSecondTime
                    fmSecond := i
                    fmSecondTime := q.reviewTime
        if not s.done and s.stage <= 3 and na(s.cisdTime) and not na(s.anchor)
            fmPendingIndex := i
if barstate.isconfirmed
    map<string, bool> retainedKeys = map.new<string, bool>()
    if array.size(setups) > 0
        for i = 0 to array.size(setups) - 1
            Setup s = array.get(setups, i)
            map.put(retainedKeys, s.key, true)
    int fmOld = array.size(fmInks) - 1
    while fmOld >= 0
        SetupInk stale = array.get(fmInks, fmOld)
        if not map.contains(retainedKeys, stale.key)
            f_fmErase(stale)
            map.remove(fmInkByKey, stale.key)
            array.remove(fmInks, fmOld)
        fmOld -= 1
    if array.size(setups) > 0
        for i = 0 to array.size(setups) - 1
            Setup s = array.get(setups, i)
            if not map.contains(fmInkByKey, s.key)
                SetupInk fresh = SetupInk.new(key=s.key)
                array.push(fmInks, fresh)
                map.put(fmInkByKey, s.key, fresh)
            SetupInk ink = map.get(fmInkByKey, s.key)
            ContextRecord q = f_contextFind(contexts, s.key)
            f_fmPaint(s, q, ink, i == fmFirst or i == fmSecond, fmProjectionKey)
    if fmAudit and fmShowDeveloping and fmPendingIndex >= 0
        Setup pending = array.get(setups, fmPendingIndex)
        fmDeveloping := f_fmLine(fmDeveloping, pending.seenTime, time_close, pending.anchor, color.new(fmInk, 70), line.style_dashed, 1)
        string tip = "Developing level for observation " + pending.key + ".\nCurrent candle-series open: " + f_fmPrice(pending.anchor) + ".\nThis level may move before confirmation. No delivery review or directional recommendation is implied."
        if na(fmDevelopingCaption)
            fmDevelopingCaption := f_fmLabel(time_close, pending.anchor, "Developing CISD · unconfirmed", fmMuted, label.style_label_left, tip)
        else
            label.set_xy(fmDevelopingCaption, time_close, pending.anchor)
            label.set_text(fmDevelopingCaption, "Developing CISD · unconfirmed")
            label.set_textcolor(fmDevelopingCaption, fmMuted)
            label.set_color(fmDevelopingCaption, color.new(fmPaper, 12))
            label.set_tooltip(fmDevelopingCaption, tip)
    else
        if not na(fmDeveloping)
            line.set_color(fmDeveloping, color.new(fmInk, 100))
            label.set_text(fmDevelopingCaption, "")
            label.set_color(fmDevelopingCaption, color.new(fmPaper, 100))

f_fmCandle(CandleInk ink, int center, int halfWidth, float o, float h, float l, float c, string caption, string tip, bool forming) =>
    color direction = c >= o ? fmBull : fmBear
    float top = math.max(o, c)
    float bottom = math.min(o, c)
    if not na(o)
        if na(ink.body)
            ink.wick := line.new(center, l, center, h, xloc=xloc.bar_time, color=direction, width=1)
            ink.body := box.new(center - halfWidth, top, center + halfWidth, bottom, xloc=xloc.bar_time, border_color=direction, bgcolor=color.new(direction, forming ? 87 : 64))
            ink.caption := f_fmLabel(center, l, caption, forming ? fmInk : fmMuted, label.style_label_up, tip)
        else
            line.set_xy1(ink.wick, center, l)
            line.set_xy2(ink.wick, center, h)
            line.set_color(ink.wick, direction)
            box.set_lefttop(ink.body, center - halfWidth, top)
            box.set_rightbottom(ink.body, center + halfWidth, bottom)
            box.set_border_color(ink.body, direction)
            box.set_bgcolor(ink.body, color.new(direction, forming ? 87 : 64))
            label.set_xy(ink.caption, center, l)
            label.set_text(ink.caption, caption)
            label.set_tooltip(ink.caption, tip)
    ink

if barstate.isfirst
    for i = 0 to 3
        array.push(fmCandles, CandleInk.new())
    table.merge_cells(fmDesk, 0, 0, 4, 0)
    table.merge_cells(fmDesk, 0, 1, 4, 1)
    table.merge_cells(fmDesk, 0, fmDeskRows - 1, 4, fmDeskRows - 1)

if barstate.islast
    // Preview is display-only: the engine never consumes this forming OHLC.
    int fmStep = int(timeframe.in_seconds() * 1000)
    if fmShowHtf and fmStep > 0
        bool frameIsCurrent = engine.frameTime == htfTime
        float previewOpen = frameIsCurrent ? engine.frameOpen : open
        float previewHigh = frameIsCurrent ? math.max(engine.frameHigh, high) : high
        float previewLow = frameIsCurrent ? math.min(engine.frameLow, low) : low
        float previewClose = close
        int secondsLeft = int(math.max(0, (htfEnd - (barstate.isrealtime ? timenow : time_close)) / 1000))
        string clockText = str.tostring(int(secondsLeft / 60)) + ":" + str.tostring(secondsLeft % 60, "00")
        array<float> os = array.from(pO3, pO2, pO1, previewOpen)
        array<float> hs = array.from(pH3, pH2, pH1, previewHigh)
        array<float> ls = array.from(pL3, pL2, pL1, previewLow)
        array<float> cs = array.from(pC3, pC2, pC1, previewClose)
        array<int> ts = array.from(pT3, pT2, pT1, htfTime)
        for i = 0 to 3
            int center = time + fmStep * (8 + i * 5)
            bool forming = i == 3
            string caption = forming ? htfTf + " · FORMING\n" + clockText : str.format_time(array.get(ts, i), "HH:mm", syminfo.timezone)
            string tip = (forming ? "LIVE / FORMING — not setup confirmation" : "Closed HTF candle") + "\n" + htfTf + " · " + f_fmTime(array.get(ts, i)) + " (" + syminfo.timezone + ")\nO " + f_fmPrice(array.get(os, i)) + "   H " + f_fmPrice(array.get(hs, i)) + "\nL " + f_fmPrice(array.get(ls, i)) + "   C " + f_fmPrice(array.get(cs, i)) + "\nEQ " + f_fmPrice((array.get(hs, i) + array.get(ls, i)) / 2)
            f_fmCandle(array.get(fmCandles, i), center, fmStep, array.get(os, i), array.get(hs, i), array.get(ls, i), array.get(cs, i), caption, tip, forming)
        if not na(pH1)
            fmPrevHigh := f_fmLine(fmPrevHigh, time + fmStep * 16, time + fmStep * 25, pH1, color.new(fmInk, 65), line.style_dotted, 1)
            fmPrevLow := f_fmLine(fmPrevLow, time + fmStep * 16, time + fmStep * 25, pL1, color.new(fmInk, 65), line.style_dotted, 1)
            fmPrevEq := f_fmLine(fmPrevEq, time + fmStep * 16, time + fmStep * 25, (pH1 + pL1) / 2, color.new(fmInk, 80), line.style_dashed, 1)
    if fmShowDesk
        table.cell(fmDesk, 0, 0, "FRACTAL MODEL DESK · " + str.upper(fmView) + " / " + htfTf, text_color=fmInk, text_size=fmTableSize, text_halign=text.align_left, bgcolor=color.new(fmInk, 91))
        table.cell(fmDesk, 0, 1, "Observed " + str.tostring(engine.total) + " · Retained " + str.tostring(array.size(setups)) + "/" + str.tostring(inHistory) + "\nIn retained: reviews " + str.tostring(fmReviewCount) + " · excluded " + str.tostring(fmExcludedCount) + " · assessing " + str.tostring(fmAssessingCount), text_color=fmMuted, text_size=fmTableSize, text_halign=text.align_left, tooltip="Raw observation count is separate from delivery reviews. Retention evictions: " + str.tostring(engine.evicted) + ". Exclusion means current automated delivery checks were not met; it does not delete the observation.")
        array<string> headers = fmAudit ? array.from("C2 OPEN", "SWEEP", "OBSERVATIONS", "CONTEXT", "REASON") : array.from("REVIEWED", "SWEEP", "EVIDENCE", "STATE", "CURRENT REASON")
        for col = 0 to 4
            table.cell(fmDesk, col, 2, array.get(headers, col), text_color=fmMuted, text_size=fmTableSize, text_halign=text.align_left, tooltip="Times: " + syminfo.timezone + ". Review time is when automated delivery evidence became observable. A review still needs manual POI and bias assessment.")
        for row = 0 to (fmAudit ? 4 : 1)
            int idx = fmAudit ? array.size(setups) - 1 - row : row == 0 ? fmFirst : fmSecond
            if idx >= 0
                Setup s = array.get(setups, idx)
                ContextRecord q = f_contextFind(contexts, s.key)
                string closureText = s.closure > 0 ? "C" + str.tostring(s.closure) + " close seen" : not na(s.c2KnownTime) ? "C2 outside" : "C2 pending"
                string cisdText = s.cisdFailed ? "CISD failed" : not na(s.cisdTime) ? "CISD observed" : "CISD pending"
                string reason = na(q) ? "Awaiting context assessment" : q.reason
                string lifecycle = na(q) ? "Assessing" : q.lifecycle
                string identity = "Observation " + s.key + "\nC2 open: " + f_fmTime(s.c2Time) + "\nSweep observed: " + f_fmTime(s.seenTime) + "\nCISD: " + f_fmTime(s.cisdTime) + "\nClosure known: " + f_fmTime(s.closureTime) + "\nTimes: " + syminfo.timezone
                identity += not na(q) and not na(q.internalSweepTime) ? "\nEarlier local sweep/reclaim " + f_fmTime(q.internalSweepTime) + " at " + f_fmPrice(q.internalLevel) + "; possible inducement context, intent unknown." : "\nNo separately known prior local swing sweep; inducement intent unknown."
                string evidence = fmAudit ? closureText + "\n" + cisdText : q.reviewModel
                string evidenceTip = fmAudit ? identity + "\n" + s.status : "Review observed " + f_fmTime(q.reviewTime) + ".\nFrozen evidence: " + q.evidence + "\nManual POI and bias assessment required."
                table.cell(fmDesk, 0, row + 3, f_fmTime(fmAudit ? s.c2Time : q.reviewTime), text_color=fmInk, text_size=fmTableSize, text_halign=text.align_left, tooltip=identity)
                table.cell(fmDesk, 1, row + 3, (s.dir == 1 ? "Low swept" : "High swept") + (s.dualSweep ? "\nBoth extremes" : ""), text_color=fmMuted, text_size=fmTableSize, text_halign=text.align_left)
                table.cell(fmDesk, 2, row + 3, evidence, text_color=fmAudit ? fmMuted : fmReview, text_size=fmTableSize, text_halign=text.align_left, tooltip=evidenceTip)
                table.cell(fmDesk, 3, row + 3, lifecycle, text_color=fmMuted, text_size=fmTableSize)
                table.cell(fmDesk, 4, row + 3, f_fmShort(reason), text_color=fmMuted, text_size=fmTableSize, text_halign=text.align_left, tooltip=reason)
            else
                for col = 0 to 4
                    string emptyText = row == 0 and col == 0 ? (fmAudit ? "No observations" : "No delivery review") : row == 0 and col == 4 ? f_fmShort(fmLatestReason) : ""
                    table.cell(fmDesk, col, row + 3, emptyText, text_color=fmMuted, text_size=fmTableSize, text_halign=text.align_left, tooltip=row == 0 ? "Latest observation: " + fmLatestReason : "")
        table.cell(fmDesk, 0, fmDeskRows - 1, "Automated delivery checks · POI / bias manual\nTimes: " + syminfo.timezone + " · " + (fmAudit ? "Raw audit history" : "Latest 2 reviews · outcomes preserved"), text_color=fmMuted, text_size=fmTableSize, text_halign=text.align_left, tooltip="Focus selects two records by immutable review observation time, including later withdrawn and completed reviews. It never selects by trade outcome. Audit exposes retained raw facts. Hidden drawings remain recorded. Ledger times use the exchange timezone, which can differ from chart display time. Automated delivery evidence is not manual POI or directional-bias approval.")

// Two reusable display slots bound IC drawings independently of retained history.
// Rails start when anatomy is observed, never at the historical swing location.
var array<line> fmIcRails = array.new<line>()
var array<label> fmIcLabels = array.new<label>()
if barstate.isconfirmed and fmShowIc
    for rail in fmIcRails
        line.delete(rail)
    for caption in fmIcLabels
        label.delete(caption)
    array.clear(fmIcRails)
    array.clear(fmIcLabels)
    array<IcRecord> selectedIc = array.new<IcRecord>()
    if array.size(icBook) > 0
        for item in icBook
            if not na(item.formedTime) and (fmAudit or not na(item.reviewTime))
                int slot = array.size(selectedIc)
                if array.size(selectedIc) > 0
                    for n = 0 to array.size(selectedIc) - 1
                        if item.formedTime >= array.get(selectedIc, n).formedTime
                            slot := n
                            break
                array.insert(selectedIc, slot, item)
                if array.size(selectedIc) > 2
                    array.pop(selectedIc)
        for item in selectedIc
            bool reviewed = not na(item.reviewTime)
            int endTime = na(item.endedAt) ? time_close : item.endedAt
            string tip = "IC " + item.key + "\nParent " + item.parentKey + "\nAnatomy observed " + f_fmTime(item.formedTime) + "\nProtected swing " + f_fmPrice(item.protectedLevel) + " at " + f_fmTime(item.protectedTime) + "\nSwing known " + f_fmTime(item.protectedKnownTime) + "\n" + item.formationReason + "\nCurrent: " + item.reason + "\nChild swing taken does not itself invalidate the parent."
            array.push(fmIcRails, line.new(item.formedTime, item.protectedLevel, endTime, item.protectedLevel, xloc=xloc.bar_time, color=reviewed ? color.new(fmReview, 45) : fmMuted, style=line.style_dotted))
            array.push(fmIcLabels, f_fmLabel(item.formedTime, item.formedPrice, reviewed ? "IC delivery review\nPOI / bias assessment" : "IC anatomy\nContext incomplete", reviewed ? fmReview : fmMuted, label.style_label_left, tip))
            if not na(item.endedAt)
                array.push(fmIcLabels, f_fmLabel(item.endedAt, item.protectedLevel, "IC ended", fmMuted, label.style_label_left, "Observed " + f_fmTime(item.endedAt) + "\n" + item.endReason + (not na(item.takenTime) ? "\nProtected swing taken " + f_fmTime(item.takenTime) : "") + "\nOriginal IC anatomy retained; parent assessed independently."))

f_jsonNumber(float value) => na(value) ? "null" : str.tostring(value, "0.################")
f_escape(string value) => str.replace_all(str.replace_all(value, "\\", "\\\\"), "\"", "\\\"")
f_eventClass(string kind) => kind == "DELIVERY_REVIEW" ? "delivery_review" : kind == "REVIEW_END" ? "review_outcome" : kind == "IC_REVIEW" ? "ic_review" : kind == "IC_ANATOMY" ? "ic_anatomy" : kind == "IC_TAKEN" or kind == "IC_END" ? "ic_outcome" : "raw_observation"
bool alertSweep = false
bool alertCisd = false
bool alertClosure = false
bool alertFailure = false
bool alertRetest = false
bool alertReview = false
bool alertReviewEnd = false
bool alertIc = false
bool alertIcEnd = false
array<FmEvent> outboundEvents = array.new<FmEvent>()
if barstate.isconfirmed
    for event in reviewEvents
        array.push(outboundEvents, event)
    for event in icEvents
        if inAlertScope == "All observations" or event.kind == "IC_REVIEW" or ((event.kind == "IC_TAKEN" or event.kind == "IC_END") and str.contains(event.detail, "ic_reviewed=true;"))
            array.push(outboundEvents, event)
    if inAlertScope == "All observations"
        for event in events
            array.push(outboundEvents, event)
if barstate.isconfirmed and array.size(outboundEvents) > 0
    string payload = ""
    for event in outboundEvents
        alertSweep := alertSweep or event.kind == "SWEEP"
        alertCisd := alertCisd or event.kind == "CISD"
        alertClosure := alertClosure or event.kind == "C2_CLOSED" or event.kind == "C3_CLOSED"
        alertFailure := alertFailure or event.kind == "C2_FAILED" or event.kind == "CISD_FAILED" or (event.kind == "END" and event.detail != "C4 window complete")
        alertRetest := alertRetest or event.kind == "RETEST"
        alertReview := alertReview or event.kind == "DELIVERY_REVIEW"
        alertReviewEnd := alertReviewEnd or event.kind == "REVIEW_END"
        alertIc := alertIc or event.kind == "IC_REVIEW"
        alertIcEnd := alertIcEnd or event.kind == "IC_TAKEN" or event.kind == "IC_END"
        payload += (payload == "" ? "" : ",") + "{\"id\":\"" + event.key + "\",\"event\":\"" + event.kind + "\",\"classification\":\"" + f_eventClass(event.kind) + "\",\"observed_at\":" + str.tostring(event.stamp) + ",\"direction\":" + str.tostring(event.dir) + ",\"price\":" + f_jsonNumber(event.price) + ",\"detail\":\"" + f_escape(event.detail) + "\"}"
    if inJson
        alert("{\"schema\":\"fm-desk-v2.1\",\"rules_version\":\"2.1.0\",\"scope\":\"" + inAlertScope + "\",\"full_model_validation\":false,\"symbol\":\"" + f_escape(syminfo.tickerid) + "\",\"chart_tf\":\"" + timeframe.period + "\",\"htf\":\"" + htfTf + "\",\"events\":[" + payload + "]}", alert.freq_once_per_bar_close)
alertcondition(alertReview, "Delivery checks met — review context", "Fractal Model Desk: automated delivery checks met; POI and higher bias still need assessment. Not an entry instruction.")
alertcondition(alertReviewEnd, "Reviewed context ended", "Fractal Model Desk: previously reviewed context ended or was withdrawn; original observation retained.")
alertcondition(alertIc, "IC delivery checks met — review context", "Fractal Model Desk: nested IC FVG and delivery checks met; higher bias and full POI context remain manual.")
alertcondition(alertIcEnd, "IC context ended or swing taken", "Fractal Model Desk: retained IC observation ended or its protected swing was taken. Parent structure is assessed independently.")
alertcondition(alertSweep, "Audit only · raw sweep", "Fractal Model Desk: raw sweep observed; no model validation.")
alertcondition(alertCisd, "Audit only · raw CISD", "Fractal Model Desk: raw close through series open; no quality or context validation.")
alertcondition(alertClosure, "Audit only · HTF closure", "Fractal Model Desk: structural closure observed; no complete model validation.")
alertcondition(alertFailure, "Audit only · failure", "Fractal Model Desk: failed observation retained in audit history.")
alertcondition(alertRetest, "Audit only · FVG overlap", "Fractal Model Desk: range overlaps a previously known FVG; context only.")

//@version=6

// FRACTAL MODEL DESK 2.1.0 | MIT | Copyright 2026 ProEA Lab
// Original implementation informed by public rules and separately documented source audits.
// Raw sweeps are observations. Automated delivery review is not full model validation.
// Closed-bar V/displacement proxies, overlap caution, and immutable review histories.
// HTF closure known at first chart-bar close in next HTF period. POI and higher bias require assessment.

// Strategy Lab is an optional execution experiment, not the definition of a setup.

strategy("Fractal Model Desk · Strategy Lab v2", "FM Lab v2", overlay = true, max_labels_count = 500, max_lines_count = 500, max_boxes_count = 100, initial_capital = 100000, default_qty_type = strategy.percent_of_equity, default_qty_value = 10, pyramiding = 0, commission_type = strategy.commission.percent, commission_value = 0.02, slippage = 1, process_orders_on_close = true, calc_on_every_tick = false, calc_on_order_fills = false)

// Setup engine: no orders, positions, grade, session, or daily-trade gates.
// C1 = reference HTF candle; C2 = sweep candle. All timestamps are observation times.
type Setup
    string key = ""
    int dir = 0
    int frameNo = 0
    int c1Time = na
    int c2Time = na
    int seenTime = na
    float c1High = na
    float c1Low = na
    float seedExt = na
    float ext = na
    float bodyExt = na
    float anchor = na
    int anchorTime = na
    int extremeTime = na
    int cisdTime = na
    int cisdFrame = na
    float cisd = na
    float projOrigin = na
    float unit = na
    bool cisdFailed = false
    int cisdFailTime = na
    float c2Open = na
    float c2High = na
    float c2Low = na
    float c2Close = na
    int c2KnownTime = na
    bool c2Valid = false
    int closure = 0
    int closureTime = na
    int c3Time = na
    int c3Frame = na
    int c4Time = na
    int c4Frame = na
    bool c3Held = true
    bool c3Strong = false
    float c3Eq = na
    int stage = 2
    float invalidLevel = na
    bool done = false
    string status = "C2 developing"
    int endTime = na
    float endPrice = na
    int fvgTime = na
    float fvgTop = na
    float fvgBot = na
    int touchTime = na
    int liqTime = na
    bool dualSweep = false
type FmEvent
    string key = ""
    string kind = ""
    int stamp = na
    float price = na
    int dir = 0
    string detail = ""
type Engine
    int frameTime = na
    int frameNo = 0
    bool ready = false
    float frameOpen = na
    float frameHigh = na
    float frameLow = na
    float frameClose = na
    bool seededBull = false
    bool seededBear = false
    int runDir = 0
    float runOpen = na
    int runTime = na
    float runBody = na
    float lastBullOpen = na
    int lastBullTime = na
    float lastBullBody = na
    float lastBearOpen = na
    int lastBearTime = na
    float lastBearBody = na
    float prevHigh = na
    float prevLow = na
    float prev2High = na
    float prev2Low = na
    int prevTime = na
    int prev2Time = na
    int total = 0
    int confirmed = 0
    int invalidated = 0
    int evicted = 0

f_event(array<FmEvent> events, Setup s, string kind, int stamp, float price, string detail) =>
    array.push(events, FmEvent.new(s.key, kind, stamp, price, s.dir, detail))

f_level(Setup s, float multiple) =>
    s.projOrigin + s.dir * multiple * s.unit

type FmBar
    float o = na
    float h = na
    float l = na
    float c = na
    int stamp = na
    int closedAt = na
    int frame = na
    float po = na
    float ph = na
    float pl = na
    float pc = na
    int pt = na

f_finish(Setup s, array<FmEvent> events, string reason, int stamp, float price) =>
    s.done := true
    s.status := reason
    s.endTime := stamp
    s.endPrice := price
    f_event(events, s, "END", stamp, price, reason)

// Called ONCE per confirmed chart bar. Synthetic probes call this identical function.
// HTF closes are observed at the first confirmed chart bar of the following frame.
f_step(Engine e, array<Setup> book, array<FmEvent> events, FmBar b, int keep, bool useBody, bool wickInvalid) =>
    array.clear(events)
    bool newFrame = na(e.frameTime) or b.frame != e.frameTime
    if newFrame
        e.ready := not na(e.frameTime) or b.stamp == b.frame
        e.frameTime := b.frame
        e.frameNo += 1
        e.frameOpen := b.o
        e.frameHigh := b.h
        e.frameLow := b.l
        e.seededBull := false
        e.seededBear := false
    else
        e.frameHigh := math.max(e.frameHigh, b.h)
        e.frameLow := math.min(e.frameLow, b.l)
    e.frameClose := b.c

    // Consecutive candle bodies; a doji ends the run. Keep the extreme-producing run.
    int bodyDir = b.c > b.o ? 1 : b.c < b.o ? -1 : 0
    if bodyDir != 0
        if bodyDir != e.runDir
            e.runOpen := b.o
            e.runTime := b.stamp
            e.runBody := b.c
        else
            e.runBody := bodyDir == 1 ? math.max(e.runBody, b.c) : math.min(e.runBody, b.c)
        if bodyDir == 1
            e.lastBullOpen := e.runOpen
            e.lastBullTime := e.runTime
            e.lastBullBody := e.runBody
        else
            e.lastBearOpen := e.runOpen
            e.lastBearTime := e.runTime
            e.lastBearBody := e.runBody
    e.runDir := bodyDir

    // Advance every existing setup independently, including opposing setups.
    if array.size(book) > 0
        for s in book
            if not s.done
                int age = e.frameNo - s.frameNo + 2
                s.stage := math.min(age, 4)
                if newFrame
                    bool priorMatches = age == 3 ? b.pt == s.c2Time : age == 4 ? b.pt == s.c3Frame : age == 5 ? b.pt == s.c4Frame : true
                    if not priorMatches
                        f_finish(s, events, "HTF data gap", b.closedAt, b.c)
                    else if age == 3
                        s.c2Open := b.po
                        s.c2High := b.ph
                        s.c2Low := b.pl
                        s.c2Close := b.pc
                        s.c2KnownTime := b.closedAt
                        s.c2Valid := b.pc > s.c1Low and b.pc < s.c1High
                        s.c3Time := b.closedAt
                        s.c3Frame := b.frame
                        if s.c2Valid
                            s.closure := 2
                            s.closureTime := b.closedAt
                            s.invalidLevel := s.dir == 1 ? b.pl : b.ph
                            s.status := "C2 closed / C3 watch"
                            e.confirmed += 1
                            f_event(events, s, "C2_CLOSED", b.closedAt, b.pc, "C2 closed strictly inside C1")
                        else
                            s.status := "C2 failed / C3 reversal watch"
                            f_event(events, s, "C2_FAILED", b.closedAt, b.pc, "C2 did not close inside C1; retained")
                        f_event(events, s, "C3", b.closedAt, b.o, "Third HTF candle; no new trade required")
                    else if age == 4
                        if s.closure == 0
                            bool bodyBreak = s.dir == 1 ? b.pc > math.max(s.c2Open, s.c2Close) : b.pc < math.min(s.c2Open, s.c2Close)
                            bool held = s.c3Held and (s.dir == 1 ? b.pl >= s.c2Low : b.ph <= s.c2High)
                            if bodyBreak and held
                                s.closure := 3
                                s.closureTime := b.closedAt
                                s.invalidLevel := s.dir == 1 ? s.c2Low : s.c2High
                                e.confirmed += 1
                                f_event(events, s, "C3_CLOSED", b.closedAt, b.pc, "C3 body-break reversal; C2 extreme held")
                            else
                                f_finish(s, events, "No C2/C3 closure", b.closedAt, b.pc)
                        if not s.done
                            s.c3Strong := s.dir == 1 ? b.pc > s.c2High and b.pc > b.po : b.pc < s.c2Low and b.pc < b.po
                            s.c3Eq := (b.ph + b.pl) / 2
                            s.c4Time := b.closedAt
                            s.c4Frame := b.frame
                            s.status := s.c3Strong ? "C4 expansion watch" : "C4 / weak C3 close"
                            f_event(events, s, "C4", b.closedAt, b.o, s.status)
                    else if age >= 5
                        f_finish(s, events, s.closure > 0 ? "C4 window complete" : "Unconfirmed", b.closedAt, b.pc)

                if not s.done
                    if age == 3 and s.closure == 0
                        s.c3Held := s.c3Held and (s.dir == 1 ? b.l >= s.c2Low : b.h <= s.c2High)
                    // Only a developing C2 can move the candidate extreme and its series.
                    bool extends = age == 2 and (s.dir == 1 ? b.l < s.ext : b.h > s.ext)
                    if na(s.cisdTime) and extends
                        s.ext := s.dir == 1 ? b.l : b.h
                        s.extremeTime := b.stamp
                        s.anchor := s.dir == 1 ? e.lastBearOpen : e.lastBullOpen
                        s.anchorTime := s.dir == 1 ? e.lastBearTime : e.lastBullTime
                        s.bodyExt := s.dir == 1 ? e.lastBearBody : e.lastBullBody
                    // A failed early trigger remains a fact; HTF closure is evaluated separately.
                    if not na(s.cisdTime) and not s.cisdFailed and b.closedAt > s.cisdTime
                        bool earlyBroken = s.dir == 1 ? (wickInvalid ? b.l < s.ext : b.c < s.ext) : (wickInvalid ? b.h > s.ext : b.c > s.ext)
                        if earlyBroken
                            s.cisdFailed := true
                            s.cisdFailTime := b.closedAt
                            f_event(events, s, "CISD_FAILED", b.closedAt, b.c, "Frozen CISD extreme violated; earlier signal retained")
                    // No new C4 CISD. C2 early and C3 confirmations remain visibly distinct from HTF closure.
                    if na(s.cisdTime) and age <= 3 and not na(s.anchor)
                        float origin = useBody ? s.bodyExt : s.ext
                        float signedLeg = (s.anchor - origin) * s.dir
                        bool crossed = s.dir == 1 ? b.c > s.anchor : b.c < s.anchor
                        if crossed and not na(origin) and signedLeg > 0
                            s.cisd := s.anchor
                            s.cisdTime := b.closedAt
                            s.cisdFrame := b.frame
                            s.projOrigin := origin
                            s.unit := signedLeg
                            f_event(events, s, "CISD", b.closedAt, s.cisd, age == 2 ? "Early C2 CISD; HTF closure still pending" : "C3 CISD")
                    if s.closure > 0
                        bool broken = s.dir == 1 ? (wickInvalid ? b.l < s.invalidLevel : b.c < s.invalidLevel) : (wickInvalid ? b.h > s.invalidLevel : b.c > s.invalidLevel)
                        if broken
                            e.invalidated += 1
                            f_finish(s, events, "Invalidated", b.closedAt, b.c)
                    if not s.done
                        // FVG is optional context: only a gap observed since this extreme, never a backfilled entry.
                        if not na(s.cisdTime) and not s.cisdFailed and na(s.fvgTime) and not na(e.prev2Time) and e.prev2Time >= s.extremeTime
                            bool gap = s.dir == 1 ? b.l > e.prev2High : b.h < e.prev2Low
                            if gap
                                s.fvgTime := b.closedAt
                                s.fvgTop := s.dir == 1 ? b.l : e.prev2Low
                                s.fvgBot := s.dir == 1 ? e.prev2High : b.h
                                f_event(events, s, "FVG", b.closedAt, (s.fvgTop + s.fvgBot) / 2, "First newly observed FVG after CISD")
                        if not na(s.fvgTime) and na(s.touchTime) and b.closedAt > s.fvgTime and b.h >= s.fvgBot and b.l <= s.fvgTop
                            s.touchTime := b.closedAt
                            f_event(events, s, "RETEST", b.closedAt, b.c, "Range overlaps known FVG; context, not an entry")
                        float liquidity = s.dir == 1 ? s.c1High : s.c1Low
                        if s.closure > 0 and na(s.liqTime) and (s.dir == 1 ? b.h >= liquidity : b.l <= liquidity)
                            s.liqTime := b.closedAt
                            f_event(events, s, "LIQUIDITY", b.closedAt, liquidity, "C1 opposite extreme reached after closure; setup retained")

    // A wick beyond C1 starts a candidate even if the LTF bar is still outside C1.
    // Deduplicate by HTF time + side, not by trade state. Both sides of an outside bar survive.
    if e.ready and not na(b.ph) and not na(b.pl)
        bool bullSweep = b.l < b.pl
        bool bearSweep = b.h > b.ph
        for direction = -1 to 1 by 2
            bool detected = direction == 1 ? bullSweep and not e.seededBull : bearSweep and not e.seededBear
            if detected
                Setup s = Setup.new()
                s.key := str.tostring(b.frame) + (direction == 1 ? "-L" : "-S")
                s.dir := direction
                s.frameNo := e.frameNo
                s.c1Time := b.pt
                s.c2Time := b.frame
                s.seenTime := b.closedAt
                s.c1High := b.ph
                s.c1Low := b.pl
                s.seedExt := direction == 1 ? b.l : b.h
                s.ext := s.seedExt
                s.extremeTime := b.stamp
                s.anchor := direction == 1 ? e.lastBearOpen : e.lastBullOpen
                s.anchorTime := direction == 1 ? e.lastBearTime : e.lastBullTime
                s.bodyExt := direction == 1 ? e.lastBearBody : e.lastBullBody
                s.dualSweep := bullSweep and bearSweep
                array.push(book, s)
                if e.seededBull or e.seededBear
                    for sibling in book
                        if sibling.c2Time == b.frame
                            sibling.dualSweep := true
                e.total += 1
                if direction == 1
                    e.seededBull := true
                else
                    e.seededBear := true
                f_event(events, s, "SWEEP", b.closedAt, direction == 1 ? b.pl : b.ph, s.dualSweep ? "Both C1 extremes swept; order unknown" : "C2 candidate; awaiting HTF close")
                // Same-bar CISD is knowable at this close; never infer intrabar sweep/close fills.
                float origin = useBody ? s.bodyExt : s.ext
                float signedLeg = (s.anchor - origin) * direction
                bool crossed = direction == 1 ? b.c > s.anchor : b.c < s.anchor
                if not na(s.anchor) and not na(origin) and signedLeg > 0 and crossed
                    s.cisd := s.anchor
                    s.cisdTime := b.closedAt
                    s.cisdFrame := b.frame
                    s.projOrigin := origin
                    s.unit := signedLeg
                    f_event(events, s, "CISD", b.closedAt, s.cisd, "Early C2 CISD; HTF closure still pending")

    // Capacity is the ONLY removal path. Preserve live records; evict oldest finished first.
    while array.size(book) > keep
        int removeAt = na
        for i = 0 to array.size(book) - 1
            if na(removeAt) and array.get(book, i).done
                removeAt := i
        if na(removeAt)
            break
        array.remove(book, removeAt)
        e.evicted += 1
    e.prev2High := e.prevHigh
    e.prev2Low := e.prevLow
    e.prev2Time := e.prevTime
    e.prevHigh := b.h
    e.prevLow := b.l
    e.prevTime := b.stamp

// Delivery review is a separate, causal assessment of raw structural observations.
// Thresholds below are disclosed implementation heuristics, not TTrades' exact rules.
type ContextRules
    int maxVBars = 3
    float minEfficiency = 0.7
    float minBodyAtr = 0.8
    float minBodyFraction = 0.6
    float minBreakAtr = 0.05
    float chopOverlap = 0.7
    int repeatedSweeps = 3
    bool useChop = true
    int minSamples = 14
type LocalSweep
    int dir = 0
    int stamp = na
    float level = na
    int pivotTime = na
    int knownTime = na
type ContextState
    array<FmBar> tape = na
    array<FmBar> frames = na
    array<LocalSweep> localSweeps = na
    float atr = na
    float atrBefore = na
    int samples = 0
    int frame = na
    float previousClose = na
    float pivotLow = na
    float pivotHigh = na
    int pivotLowTime = na
    int pivotHighTime = na
    int pivotLowKnown = na
    int pivotHighKnown = na
    bool lowTaken = false
    bool highTaken = false
    int reviews = 0
    int withdrawals = 0
type ContextRecord
    string key = ""
    int dir = 0
    int trackedExtreme = na
    int legBars = 0
    float legPath = 0
    float legClose = na
    float efficiency = na
    float bodyAtr = na
    float bodyFraction = na
    float breakAtr = na
    bool measured = false
    bool vShape = false
    bool displacement = false
    bool chop = false
    int reviewTime = na
    float reviewPrice = na
    string reviewModel = ""
    string evidence = ""
    string reason = "Waiting for closure and delivery"
    string lifecycle = "Assessing"
    int endedAt = na
    float endPrice = na
    int internalSweepTime = na
    float internalLevel = na

f_newContextState() =>
    ContextState.new(tape = array.new<FmBar>(), frames = array.new<FmBar>(), localSweeps = array.new<LocalSweep>())

f_contextFind(array<ContextRecord> records, string key) =>
    ContextRecord found = na
    for item in records
        if item.key == key
            found := item
            break
    found

f_contextActive(ContextRecord item) =>
    not na(item) and not na(item.reviewTime) and na(item.endedAt)

f_contextNumber(float value) => na(value) ? "unknown" : str.tostring(value, "0.00")

f_contextOverlap(FmBar a, FmBar b) =>
    float denominator = math.min(a.h - a.l, b.h - b.l)
    denominator > 0 ? math.max(0, math.min(a.h, b.h) - math.max(a.l, b.l)) / denominator : 1.0

f_contextChop(ContextState state, array<Setup> book, ContextRules rules) =>
    bool result = false
    if rules.useChop and array.size(state.frames) >= 3
        int n = array.size(state.frames)
        FmBar older = array.get(state.frames, n - 3)
        FmBar middle = array.get(state.frames, n - 2)
        FmBar latest = array.get(state.frames, n - 1)
        int count = 0
        for s in book
            if s.c2Time >= older.stamp and s.c2Time <= latest.stamp
                count += 1
        result := count >= rules.repeatedSweeps and f_contextOverlap(older, middle) >= rules.chopOverlap and f_contextOverlap(middle, latest) >= rules.chopOverlap
    result

// No labels are backdated: local pivots become known after their right-hand bar closes.
// This is a local swing sweep / possible inducement sequence, not inferred intent,
// and not TTrades' 'internal liquidity', which refers to FVGs.
f_contextLocalSwings(ContextState state, FmBar b) =>
    if not na(state.pivotLow) and not state.lowTaken and state.pivotLowKnown <= b.stamp and b.l < state.pivotLow
        state.lowTaken := true
        if b.c > state.pivotLow
            array.push(state.localSweeps, LocalSweep.new(1, b.closedAt, state.pivotLow, state.pivotLowTime, state.pivotLowKnown))
    if not na(state.pivotHigh) and not state.highTaken and state.pivotHighKnown <= b.stamp and b.h > state.pivotHigh
        state.highTaken := true
        if b.c < state.pivotHigh
            array.push(state.localSweeps, LocalSweep.new(-1, b.closedAt, state.pivotHigh, state.pivotHighTime, state.pivotHighKnown))
    if array.size(state.tape) >= 2
        FmBar left = array.get(state.tape, array.size(state.tape) - 2)
        FmBar middle = array.get(state.tape, array.size(state.tape) - 1)
        if middle.l < left.l and middle.l < b.l
            state.pivotLow := middle.l
            state.pivotLowTime := middle.stamp
            state.pivotLowKnown := b.closedAt
            state.lowTaken := false
        if middle.h > left.h and middle.h > b.h
            state.pivotHigh := middle.h
            state.pivotHighTime := middle.stamp
            state.pivotHighKnown := b.closedAt
            state.highTaken := false
    while array.size(state.localSweeps) > 32
        array.shift(state.localSweeps)

f_contextStep(ContextState state, array<ContextRecord> records, array<FmEvent> reviewEvents, array<Setup> book, ContextRules rules, FmBar b) =>
    array.clear(reviewEvents)
    state.atrBefore := state.atr
    bool warm = state.samples >= rules.minSamples and not na(state.atrBefore) and state.atrBefore > 0
    if na(state.frame) or state.frame != b.frame
        state.frame := b.frame
        if not na(b.pt)
            FmBar closedFrame = FmBar.new(b.po, b.ph, b.pl, b.pc, b.pt, b.frame, b.pt)
            array.push(state.frames, closedFrame)
            if array.size(state.frames) > 3
                array.shift(state.frames)
    f_contextLocalSwings(state, b)
    bool rangeChop = f_contextChop(state, book, rules)
    map<string, ContextRecord> byKey = map.new<string, ContextRecord>()
    map<string, bool> retainedKeys = map.new<string, bool>()
    for item in records
        map.put(byKey, item.key, item)
    for s in book
        map.put(retainedKeys, s.key, true)
        ContextRecord q = map.contains(byKey, s.key) ? map.get(byKey, s.key) : na
        if na(q)
            q := ContextRecord.new(key = s.key, dir = s.dir)
            // Only a separately observed, earlier local sweep can supply this note.
            // Same-bar outer and local sweeps have unknown ordering and do not qualify.
            for local in state.localSweeps
                if local.dir == s.dir and local.stamp <= b.stamp and local.stamp < s.seenTime and local.stamp >= s.c1Time and local.level > s.c1Low and local.level < s.c1High
                    q.internalSweepTime := local.stamp
                    q.internalLevel := local.level
            array.push(records, q)
            map.put(byKey, s.key, q)
        if not q.measured and not s.done
            if na(q.trackedExtreme) or q.trackedExtreme != s.extremeTime
                q.trackedExtreme := s.extremeTime
                q.legBars := 1
                q.legPath := math.abs(b.c - s.ext)
            else
                q.legBars += 1
                q.legPath += math.abs(b.c - q.legClose)
            q.legClose := b.c
            if not na(s.cisdTime)
                q.measured := true
                q.efficiency := q.legPath > 0 ? math.min(1, math.max(0, (b.c - s.ext) * s.dir) / q.legPath) : 0
                q.bodyAtr := warm ? math.abs(b.c - b.o) / state.atrBefore : na
                q.bodyFraction := b.h > b.l ? math.abs(b.c - b.o) / (b.h - b.l) : 0
                q.breakAtr := warm ? (b.c - s.cisd) * s.dir / state.atrBefore : na
                bool decisive = warm and q.breakAtr >= rules.minBreakAtr
                q.vShape := decisive and q.legBars <= rules.maxVBars and q.efficiency >= rules.minEfficiency
                q.displacement := decisive and (b.c - b.o) * s.dir > 0 and q.bodyAtr >= rules.minBodyAtr and q.bodyFraction >= rules.minBodyFraction
                q.reviewModel := q.vShape and q.displacement ? "V + displacement" : q.vShape ? "V reversal" : q.displacement ? "Displacement" : "Marginal / slow CISD"
                q.evidence := "CISD quality observed at " + str.tostring(b.closedAt) + "; bars from extreme=" + str.tostring(q.legBars) + "; path efficiency=" + f_contextNumber(q.efficiency) + "; body/prior ATR=" + f_contextNumber(q.bodyAtr) + "; body/range=" + f_contextNumber(q.bodyFraction) + "; close beyond CISD/prior ATR=" + f_contextNumber(q.breakAtr) + ". Configurable proxies; POI and higher bias remain manual."
                q.evidence += na(q.internalSweepTime) ? " No separately known prior local swing sweep; inducement intent unknown." : " Earlier local swing sweep/reclaim observed at " + str.tostring(q.internalSweepTime) + "; level=" + str.tostring(q.internalLevel, "0.################") + ". Possible inducement context, not proof of intent."
        q.chop := rangeChop
        bool paired = s.closure == 2 ? s.cisdFrame == s.c2Time : s.closure == 3 ? s.cisdFrame == s.c3Frame : false
        string blocker = s.done ? s.status : s.cisdFailed ? "Frozen CISD failed" : s.dualSweep ? "Two-sided sweep / direction unresolved" : not na(s.liqTime) ? "C1 objective already reached" : rangeChop ? "Repeated sweeps in overlapping HTF ranges" : not q.measured ? "Waiting for CISD" : na(q.bodyAtr) ? "Insufficient prior volatility history at first CISD; no later reassessment" : not (q.vShape or q.displacement) ? "Marginal or slow CISD; delivery unclear" : s.closure == 0 ? "Waiting for HTF closure" : not paired ? "CISD and closure belong to different stages" : ""
        if na(q.reviewTime)
            q.reason := blocker == "" ? "Delivery checks met; POI / bias manual" : blocker
            q.lifecycle := s.done or s.cisdFailed or s.dualSweep or (q.measured and (na(q.bodyAtr) or not (q.vShape or q.displacement))) ? "Excluded" : "Assessing"
            if blocker == ""
                q.reviewTime := b.closedAt
                q.reviewPrice := b.c
                q.lifecycle := "Review"
                state.reviews += 1
                f_event(reviewEvents, s, "DELIVERY_REVIEW", b.closedAt, b.c, q.reviewModel + "; " + q.evidence + " Chop check clear when reviewed. This is not full model validation or an entry.")
        else if na(q.endedAt) and blocker != ""
            q.endedAt := b.closedAt
            q.endPrice := b.c
            q.reason := blocker
            q.lifecycle := s.done and s.status == "C4 window complete" ? "Complete" : "Withdrawn"
            state.withdrawals += 1
            f_event(reviewEvents, s, "REVIEW_END", b.closedAt, b.c, blocker + "; original review retained")
    // Retention follows the raw ledger only; a noisy or failed record is not erased.
    int i = array.size(records) - 1
    while i >= 0
        if not map.contains(retainedKeys, array.get(records, i).key)
            array.remove(records, i)
        i -= 1
    float tr = na(state.previousClose) ? b.h - b.l : math.max(b.h - b.l, math.max(math.abs(b.h - state.previousClose), math.abs(b.l - state.previousClose)))
    state.samples += 1
    state.atr := na(state.atr) ? tr : state.samples <= 14 ? (state.atr * (state.samples - 1) + tr) / state.samples : (state.atr * 13 + tr) / 14
    state.previousClose := b.c
    array.push(state.tape, b)
    if array.size(state.tape) > 3
        array.shift(state.tape)

// Independent IC continuation observations. No orders and no parent-state mutation.
// One attempt per reviewed parent per C3/C4 frame. Parent review must precede the
// opposing leg. Anatomy and the stricter FVG/delivery review are separate facts.
// The HTF-open wick, parent-FVG and ATR rules are disclosed product heuristics.
type IcRecord
    string key = ""
    string parentKey = ""
    int dir = 0
    int frame = na
    int stage = 0
    int parentReviewTime = na
    int legTime = na
    int seenTime = na
    float level = na
    float frameOpen = na
    float legExtreme = na
    bool openSwept = false
    float leftHigh = na
    float leftLow = na
    float middleHigh = na
    float middleLow = na
    int middleTime = na
    float swingLevel = na
    int swingTime = na
    int swingKnownTime = na
    int formedTime = na
    float formedPrice = na
    float protectedLevel = na
    int protectedTime = na
    int protectedKnownTime = na
    int poiTime = na
    int poiKnownTime = na
    float poiTop = na
    float poiBot = na
    int reviewTime = na
    float bodyAtr = na
    float bodyFraction = na
    float breakAtr = na
    int takenTime = na
    int endedAt = na
    string formationReason = ""
    string endReason = ""
    string reason = "Opposing leg; waiting for swing and close-through"

f_icFind(array<IcRecord> records, string key) =>
    IcRecord found = na
    for item in records
        if item.key == key
            found := item
            break
    found

f_icParent(array<Setup> setups, string key) =>
    Setup found = na
    for item in setups
        if item.key == key
            found := item
            break
    found

f_icActive(IcRecord item) =>
    not na(item) and not na(item.reviewTime) and na(item.takenTime) and na(item.endedAt)

f_icEmit(array<FmEvent> events, IcRecord item, string kind, int stamp, float price, string detail) =>
    // Copy scalar values into a new event; later lifecycle changes cannot rewrite it.
    array.push(events, FmEvent.new(item.key, kind, stamp, price, item.dir, "ic_reviewed=" + str.tostring(not na(item.reviewTime)) + "; parent=" + item.parentKey + "; " + detail))

f_icEnd(IcRecord item, array<FmEvent> events, FmBar b, string reason) =>
    if na(item.endedAt)
        item.endedAt := b.closedAt
        item.endReason := reason
        item.reason := reason
        f_icEmit(events, item, "IC_END", b.closedAt, b.c, reason + "; original observations retained")

f_icObservePoi(IcRecord item, Setup parent, FmBar b) =>
    // A gap first created by this bar is not available at its open. Equality
    // permits a gap known at the preceding close, before the current bar begins.
    if na(item.poiTime) and not na(parent.fvgTime) and parent.fvgTime <= b.stamp and parent.fvgTop > parent.fvgBot and b.h >= parent.fvgBot and b.l <= parent.fvgTop
        item.poiTime := b.closedAt
        item.poiKnownTime := parent.fvgTime
        item.poiTop := parent.fvgTop
        item.poiBot := parent.fvgBot

f_icProgress(IcRecord item, Setup parent, array<FmEvent> events, ContextState state, ContextRules rules, FmBar b) =>
    f_icObservePoi(item, parent, b)
    item.legExtreme := item.dir == 1 ? math.min(item.legExtreme, b.l) : math.max(item.legExtreme, b.h)
    item.openSwept := item.openSwept or (item.dir == 1 ? b.l < item.frameOpen : b.h > item.frameOpen)
    // Current bar is the right neighbor. No swing is known at its middle bar.
    bool strictSwing = item.dir == 1 ? item.middleLow < item.leftLow and item.middleLow < b.l : item.middleHigh > item.leftHigh and item.middleHigh > b.h
    float candidate = item.dir == 1 ? item.middleLow : item.middleHigh
    if item.middleTime >= item.legTime and strictSwing
        if na(item.swingLevel) or (item.dir == 1 ? candidate < item.swingLevel : candidate > item.swingLevel)
            item.swingLevel := candidate
            item.swingTime := item.middleTime
            item.swingKnownTime := b.closedAt
    bool crossed = (b.c - item.level) * item.dir > 0
    // The stored swing must still be the actual leg extreme; a lower/higher
    // unconfirmed current wick cannot leave an already-broken protected swing.
    bool holds = not na(item.swingLevel) and item.swingLevel == item.legExtreme
    if b.stamp > item.legTime and item.openSwept and crossed and holds
        item.formedTime := b.closedAt
        item.formedPrice := b.c
        item.protectedLevel := item.swingLevel
        item.protectedTime := item.swingTime
        item.protectedKnownTime := item.swingKnownTime
        bool warm = state.samples > rules.minSamples and not na(state.atrBefore) and state.atrBefore > 0
        item.bodyAtr := warm ? math.abs(b.c - b.o) / state.atrBefore : na
        item.bodyFraction := b.h > b.l ? math.abs(b.c - b.o) / (b.h - b.l) : 0
        item.breakAtr := warm ? (b.c - item.level) * item.dir / state.atrBefore : na
        bool decisive = warm and (b.c - b.o) * item.dir > 0 and item.bodyAtr >= rules.minBodyAtr and item.bodyFraction >= rules.minBodyFraction and item.breakAtr >= rules.minBreakAtr
        item.formationReason := na(item.poiTime) ? "IC anatomy; parent FVG POI not observed" : not warm ? "IC anatomy; insufficient prior volatility history" : not decisive ? "IC anatomy; decisive delivery check not met" : "IC FVG and delivery checks met; higher bias / full POI context manual"
        item.reason := item.formationReason
        f_icEmit(events, item, "IC_ANATOMY", b.closedAt, b.c, "Fixed opposing open crossed after a strict local swing; protected price=" + str.tostring(item.protectedLevel, "0.################") + "; swing time=" + str.tostring(item.protectedTime) + "; " + item.formationReason)
        if not na(item.poiTime) and decisive
            item.reviewTime := b.closedAt
            f_icEmit(events, item, "IC_REVIEW", b.closedAt, b.c, "Previously known parent FVG overlapped; decisive close met configurable ATR/body checks; nested continuation observation, not an entry")
    item.leftHigh := item.middleHigh
    item.leftLow := item.middleLow
    item.middleHigh := b.h
    item.middleLow := b.l
    item.middleTime := b.stamp

// Call after f_step and f_contextStep, once per confirmed chart bar. Keep the IC
// event buffer separate from raw/context events; callers may concatenate copies.
f_icStep(array<IcRecord> icBook, array<FmEvent> icEvents, array<Setup> setups, array<ContextRecord> contexts, Engine engine, ContextState state, ContextRules rules, FmBar b, int keep) =>
    array.clear(icEvents)
    for item in icBook
        // Continue marking taken swings even after their frame/parent has ended,
        // while the completed record remains inside the disclosed retention cap.
        if not na(item.formedTime) and na(item.takenTime) and b.stamp >= item.formedTime
            bool taken = item.dir == 1 ? b.l < item.protectedLevel : b.h > item.protectedLevel
            if taken
                item.takenTime := b.closedAt
                item.reason := "Protected IC swing taken; parent record unchanged"
                f_icEmit(icEvents, item, "IC_TAKEN", b.closedAt, item.protectedLevel, item.reason)
                if na(item.endedAt)
                    item.endedAt := b.closedAt
                    item.endReason := "Protected IC swing taken"
        if na(item.endedAt)
            Setup parent = f_icParent(setups, item.parentKey)
            ContextRecord context = f_contextFind(contexts, item.parentKey)
            if b.frame != item.frame
                f_icEnd(item, icEvents, b, "IC frame ended")
            else if na(parent)
                f_icEnd(item, icEvents, b, "Parent left retained history")
            else if not f_contextActive(context) or parent.done or parent.stage < 3 or parent.stage > 4
                f_icEnd(item, icEvents, b, "Parent review ended or withdrawn")
            else if na(item.formedTime)
                f_icProgress(item, parent, icEvents, state, rules, b)

    for parent in setups
        ContextRecord context = f_contextFind(contexts, parent.key)
        bool eligible = f_contextActive(context) and not parent.done and (parent.stage == 3 or parent.stage == 4)
        if eligible
            // The raw engine has just consumed this bar. A run that started before
            // parent review cannot acquire a parent retroactively partway through.
            bool firstOppositeBody = engine.runDir == -parent.dir and engine.runTime == b.stamp
            bool parentKnown = context.reviewTime <= b.stamp
            string key = parent.key + ":IC:" + str.tostring(b.frame) + ":1"
            if firstOppositeBody and parentKnown and na(f_icFind(icBook, key))
                IcRecord item = IcRecord.new()
                item.key := key
                item.parentKey := parent.key
                item.dir := parent.dir
                item.frame := b.frame
                item.stage := parent.stage
                item.parentReviewTime := context.reviewTime
                item.legTime := b.stamp
                item.seenTime := b.closedAt
                item.level := b.o
                item.frameOpen := engine.frameOpen
                item.legExtreme := parent.dir == 1 ? b.l : b.h
                item.openSwept := parent.dir == 1 ? b.l < engine.frameOpen : b.h > engine.frameOpen
                // f_step updates prev2 to the bar immediately preceding b.
                item.leftHigh := engine.prev2High
                item.leftLow := engine.prev2Low
                item.middleHigh := b.h
                item.middleLow := b.l
                item.middleTime := b.stamp
                f_icObservePoi(item, parent, b)
                array.push(icBook, item)

    // Keep current-frame completed records as deduplication tombstones. The cap
    // may temporarily exceed keep when all records are active/current-frame.
    while array.size(icBook) > keep
        int removeAt = na
        for i = 0 to array.size(icBook) - 1
            IcRecord item = array.get(icBook, i)
            if na(removeAt) and not na(item.endedAt) and item.frame != b.frame
                removeAt := i
        if na(removeAt)
            break
        array.remove(icBook, removeAt)
    array.size(icBook)

gModel = "Structure"
inAuto = input.bool(true, "Automatic HTF pairing", group = gModel)
inTf = input.timeframe("60", "Manual higher timeframe", group = gModel)
inBody = input.bool(false, "Projection anchor: body (default wick)", group = gModel, tooltip = "Origin and leg use the same anchor. 1x equals frozen CISD. These are leg multiples, not statistical standard deviations.")
inWickInvalid = input.bool(true, "Invalidate on wick through extreme (off = close)", group = gModel, tooltip = "Strictly beyond; equal touches do not invalidate. Failed early CISD is retained separately from HTF closure.")
inHistory = input.int(24, "Setups retained", minval = 8, maxval = 40, group = gModel, tooltip = "Developing, confirmed, failed and completed setups. Only oldest completed records are evicted at capacity. Live setups are preserved.")
inJson = input.bool(true, "JSON event batch alerts", group = "Alerts", tooltip = "One payload per confirmed bar contains all events and original setup IDs. Create an Any alert() function call alert.")
inAlertScope = input.string("Delivery review", "Event stream", options = ["Delivery review", "All observations"], group = "Alerts", tooltip = "Default: automated delivery reviews, IC reviews and their later outcomes. All observations also includes neutral raw sweeps, CISD and stage facts. Neither stream is a buy/sell instruction.")
gContext = "Delivery review · disclosed proxies"
inVMax = input.int(3, "V reversal: maximum bars from extreme", minval = 1, maxval = 12, group = gContext)
inEfficiency = input.float(0.7, "V reversal: minimum path efficiency", minval = 0.1, maxval = 1, step = 0.05, group = gContext, tooltip = "Net directional travel from the wick divided by total close-to-close travel, including the extreme-to-close segment. A configurable approximation of a clean reversal.")
inBodyAtr = input.float(0.8, "Displacement: minimum body / prior ATR14", minval = 0.1, maxval = 3, step = 0.1, group = gContext)
inBodyFraction = input.float(0.6, "Displacement: minimum body / range", minval = 0.1, maxval = 1, step = 0.05, group = gContext)
inBreakAtr = input.float(0.05, "Decisive close: distance past CISD / prior ATR14", minval = 0.01, maxval = 1, step = 0.01, group = gContext)
inChop = input.bool(true, "Pause reviews in repeated overlapping ranges", group = gContext)
inOverlap = input.float(0.7, "Chop: minimum pairwise overlap of 3 closed HTFs", minval = 0.1, maxval = 1, step = 0.05, group = gContext)
inRepeat = input.int(3, "Chop: sweep observations across those 3 HTFs", minval = 2, maxval = 6, group = gContext, tooltip = "Both adjacent overlaps must pass and the sweep count must reach this threshold. This is a declared noise heuristic, not a universal regime detector.")
int chartSeconds = timeframe.in_seconds()
string autoTf = chartSeconds <= 60 ? "15" : chartSeconds <= 300 ? "60" : chartSeconds <= 900 ? "240" : chartSeconds <= 3600 ? "1D" : chartSeconds <= 14400 ? "1W" : "1M"
string htfTf = inAuto ? autoTf : inTf
if barstate.isfirst and (not chart.is_standard or na(chartSeconds) or timeframe.in_seconds(htfTf) <= chartSeconds)
    runtime.error("Use standard time-based bars and an HTF strictly greater than the chart timeframe.")
[pO1, pH1, pL1, pC1, pT1, pO2, pH2, pL2, pC2, pT2, pO3, pH3, pL3, pC3, pT3] = request.security(syminfo.tickerid, htfTf, [open[1], high[1], low[1], close[1], time[1], open[2], high[2], low[2], close[2], time[2], open[3], high[3], low[3], close[3], time[3]], lookahead = barmerge.lookahead_on)
int htfTime = time(htfTf)
int htfEnd = time_close(htfTf)
if not na(htfEnd) and time_close > htfEnd
    runtime.error("Chart bars must fit entirely inside the selected HTF. Choose an aligned pair such as 5m / 1H.")
var array<Setup> setups = array.new<Setup>()
var Engine engine = Engine.new()
var array<FmEvent> events = array.new<FmEvent>()
var array<ContextRecord> contexts = array.new<ContextRecord>()
var ContextState contextState = f_newContextState()
var ContextRules contextRules = ContextRules.new(maxVBars = inVMax, minEfficiency = inEfficiency, minBodyAtr = inBodyAtr, minBodyFraction = inBodyFraction, minBreakAtr = inBreakAtr, chopOverlap = inOverlap, repeatedSweeps = inRepeat, useChop = inChop)
var array<FmEvent> reviewEvents = array.new<FmEvent>()
var array<IcRecord> icBook = array.new<IcRecord>()
var array<FmEvent> icEvents = array.new<FmEvent>()
if barstate.isconfirmed
    FmBar b = FmBar.new(open, high, low, close, time, time_close, htfTime, pO1, pH1, pL1, pC1, pT1)
    f_step(engine, setups, events, b, inHistory, inBody, inWickInvalid)
    f_contextStep(contextState, contexts, reviewEvents, setups, contextRules, b)
    f_icStep(icBook, icEvents, setups, contexts, engine, contextState, contextRules, b, 24)
plot(engine.total, "Audit / candidates observed", display = display.data_window)
plot(engine.confirmed, "Audit / HTF closures", display = display.data_window)
plot(engine.invalidated, "Audit / structural invalidations", display = display.data_window)
plot(engine.evicted, "Audit / capacity evictions", display = display.data_window)
plot(contextState.reviews, "Review / automated delivery checks met", display = display.data_window)
plot(contextState.withdrawals, "Review / ended or withdrawn", display = display.data_window)

// Optional experiment. Broker positions never feed back into f_step or its records.
labMode = input.string("Delivery review", "Entry experiment", options = ["Delivery review", "FVG retest after review"], group = "Strategy Lab", tooltip = "Experimental execution of automated delivery checks; manual higher bias and POI are not verified. Indicator reviews are not trade instructions.")
labBuffer = input.int(1, "Stop buffer in ticks", minval = 0, group = "Strategy Lab")
var float labStop = na
var float labTarget = na
var string labKey = ""
if barstate.isconfirmed
    bool submitted = false
    if strategy.position_size == 0 and nz(strategy.position_size[1]) != 0
        labStop := na
        labTarget := na
        labKey := ""
    array<FmEvent> labEvents = labMode == "Delivery review" ? reviewEvents : events
    if strategy.position_size == 0 and array.size(labEvents) > 0
        for event in labEvents
            bool trigger = labMode == "Delivery review" ? event.kind == "DELIVERY_REVIEW" : event.kind == "RETEST"
            if trigger and not submitted
                for s in setups
                    bool pairedCisd = s.closure == 2 ? s.cisdFrame == s.c2Time : s.cisdFrame == s.c3Frame
                    ContextRecord q = f_contextFind(contexts, s.key)
                    bool reviewPrecedesRetest = labMode == "Delivery review" or (f_contextActive(q) and q.reviewTime <= time and event.stamp > q.reviewTime)
                    if s.key == event.key and f_contextActive(q) and reviewPrecedesRetest and s.closure > 0 and not s.done and not s.dualSweep and pairedCisd and not s.cisdFailed and not na(s.cisdTime) and na(s.liqTime)
                        float stop = s.invalidLevel - s.dir * labBuffer * syminfo.mintick
                        float target = s.dir == 1 ? s.c1High : s.c1Low
                        // Spent/behind targets are skipped; never replaced with arbitrary 2R.
                        if (close - stop) * s.dir > syminfo.mintick and (target - close) * s.dir > syminfo.mintick
                            labStop := stop
                            labTarget := target
                            labKey := s.key
                            strategy.entry("FM", s.dir == 1 ? strategy.long : strategy.short, comment = s.key)
                            // Bracket on ENTRY calculation, before position_size updates.
                            strategy.exit("FM-X", "FM", stop = labStop, limit = labTarget)
                            submitted := true
    if strategy.position_size != 0 and not na(labStop)
        strategy.exit("FM-X", "FM", stop = labStop, limit = labTarget)

// Display owns its handles; the engine owns setup facts. A finished setup is never
// removed by the renderer. Handles disappear only after its key leaves retention.
string fmVisualGroup = "Display · setup history"
string fmView = input.string("Focus", "View", options=["Focus", "Audit"], group=fmVisualGroup, tooltip="Focus shows the two most recently observed delivery reviews, including later withdrawn or completed reviews. Audit reveals retained raw observations. Display filtering never deletes engine history.")
string fmPalette = input.string("Colorblind", "Direction palette", options=["Colorblind", "Classic"], group=fmVisualGroup)
string fmProjectionScope = input.string("Latest review", "Projection visibility", options=["Latest review", "Selected reviews", "All retained", "Off"], group=fmVisualGroup, tooltip="Latest review uses observation time, never later success. Focus always limits projections to its two selected reviews; All retained is available in Audit. Prices remain frozen CISD-leg multiples, not statistical standard deviations.")
bool fmShowProjections = fmProjectionScope != "Off"
bool fmShowFvg = input.bool(true, "Show first FVG after CISD", group=fmVisualGroup, tooltip="Context only. Audit starts the box at gap observation; Focus starts no earlier than delivery review. A touch requires a later bar.")
bool fmShowStages = input.bool(false, "Audit: show C3 / C4 stage markers", group=fmVisualGroup)
bool fmShowDeveloping = input.bool(false, "Audit: preview developing CISD level", group=fmVisualGroup, tooltip="A neutral dashed rail for a pending observation. This level may move before confirmation; it is not a delivery review.")
bool fmShowHtf = input.bool(true, "Show higher-timeframe candles", group=fmVisualGroup)
bool fmShowDesk = input.bool(true, "Show recent setup ledger", group=fmVisualGroup)
bool fmShowIc = input.bool(true, "Show latest two IC observations", group=fmVisualGroup, tooltip="Focus shows the latest two IC delivery reviews, including later failures. Audit also shows neutral IC anatomy without known FVG or decisive delivery. IC history is independent of parent structure; 24 records retained with active/current-frame overflow protected.")
string fmDeskPosition = input.string("Bottom right", "Ledger position", options=["Bottom right", "Bottom left", "Top right", "Top left"], group=fmVisualGroup)
string fmDeskText = input.string("Small", "Ledger text size", options=["Small", "Normal", "Tiny"], group=fmVisualGroup)
string fmTablePosition = fmDeskPosition == "Bottom left" ? position.bottom_left : fmDeskPosition == "Top right" ? position.top_right : fmDeskPosition == "Top left" ? position.top_left : position.bottom_right
string fmTableSize = fmDeskText == "Normal" ? size.normal : fmDeskText == "Tiny" ? size.tiny : size.small
color fmBull = fmPalette == "Colorblind" ? color.rgb(0, 158, 173) : color.rgb(34, 171, 148)
color fmBear = fmPalette == "Colorblind" ? color.rgb(218, 139, 36) : color.rgb(239, 83, 80)
color fmInk = chart.fg_color
color fmPaper = chart.bg_color
color fmMuted = color.new(fmInk, 48)
color fmReview = color.rgb(56, 189, 248)
bool fmAudit = fmView == "Audit"
int fmDeskRows = fmAudit ? 9 : 6

type SetupInk
    string key = ""
    line reference = na
    line delivery = na
    line level1 = na
    line level2 = na
    line level25 = na
    line level4 = na
    line invalidation = na
    box gap = na
    label seed = na
    label cisd = na
    label c2 = na
    label c3 = na
    label c4 = na
    label earlyFailure = na
    label finish = na
    label gapSeen = na
    label gapTouch = na
    label liquidity = na
    label review = na
    label reviewOutcome = na

type CandleInk
    box body = na
    line wick = na
    label caption = na

var array<SetupInk> fmInks = array.new<SetupInk>()
var map<string, SetupInk> fmInkByKey = map.new<string, SetupInk>()
var array<CandleInk> fmCandles = array.new<CandleInk>()
var line fmPrevHigh = na
var line fmPrevLow = na
var line fmPrevEq = na
var line fmDeveloping = na
var label fmDevelopingCaption = na
var table fmDesk = table.new(fmTablePosition, 5, fmDeskRows, bgcolor=color.new(fmPaper, 8), border_color=color.new(fmInk, 88), border_width=1, frame_color=color.new(fmInk, 75), frame_width=1)

f_fmLine(line handle, int left, int right, float price, color ink, string style, int width) =>
    line result = handle
    if na(result)
        result := line.new(left, price, right, price, xloc=xloc.bar_time, extend=extend.none, color=ink, style=style, width=width)
    else
        line.set_xy1(result, left, price)
        line.set_xy2(result, right, price)
        line.set_color(result, ink)
    result

f_fmLabel(int stamp, float price, string captionText, color ink, string labelStyle, string tip) =>
    label.new(stamp, price, captionText, xloc=xloc.bar_time, yloc=yloc.price, color=color.new(fmPaper, 12), style=labelStyle, textcolor=ink, size=size.tiny, tooltip=tip)

f_fmTime(int stamp) =>
    na(stamp) ? "—" : str.format_time(stamp, "MM-dd HH:mm", syminfo.timezone)

f_fmPrice(float price) =>
    str.tostring(price, format.mintick)

f_fmLabelVisibility(label handle, bool visible, color ink) =>
    if not na(handle)
        label.set_textcolor(handle, visible ? ink : color.new(ink, 100))
        label.set_color(handle, color.new(fmPaper, visible ? 12 : 100))

f_fmShort(string value) =>
    str.length(value) > 38 ? str.substring(value, 0, 35) + "…" : value

f_fmErase(SetupInk ink) =>
    line.delete(ink.reference)
    line.delete(ink.delivery)
    line.delete(ink.level1)
    line.delete(ink.level2)
    line.delete(ink.level25)
    line.delete(ink.level4)
    line.delete(ink.invalidation)
    box.delete(ink.gap)
    label.delete(ink.seed)
    label.delete(ink.cisd)
    label.delete(ink.c2)
    label.delete(ink.c3)
    label.delete(ink.c4)
    label.delete(ink.earlyFailure)
    label.delete(ink.finish)
    label.delete(ink.gapSeen)
    label.delete(ink.gapTouch)
    label.delete(ink.liquidity)
    label.delete(ink.review)
    label.delete(ink.reviewOutcome)

f_fmPaint(Setup s, ContextRecord q, SetupInk ink, bool selected, string projectionKey) =>
    bool reviewed = not na(q) and not na(q.reviewTime)
    bool reviewVisible = reviewed and (fmAudit or selected)
    bool railsVisible = fmAudit or reviewVisible
    bool ended = reviewed and not na(q.endedAt)
    int observedEnd = na(s.endTime) ? time_close : s.endTime
    int right = not fmAudit and ended ? q.endedAt : observedEnd
    int reviewStart = reviewed ? q.reviewTime : s.seenTime
    color railInk = fmAudit ? fmMuted : color.new(fmReview, ended ? 78 : 35)
    string identity = "Observation " + s.key + "\nFirst seen " + f_fmTime(s.seenTime) + " (" + syminfo.timezone + ")"
    string seedStyle = s.dir == 1 ? label.style_label_up : label.style_label_down
    float reference = s.dir == 1 ? s.c1Low : s.c1High
    int referenceStart = fmAudit ? s.c1Time : math.max(s.c1Time, reviewStart)
    ink.reference := f_fmLine(ink.reference, referenceStart, right, reference, color.new(fmInk, railsVisible ? 78 : 100), line.style_dotted, 1)
    // Raw observations are permanently neutral. A later review gets a NEW marker.
    if na(ink.seed)
        ink.seed := f_fmLabel(s.seenTime, s.seedExt, s.dir == 1 ? "C2 · low swept" : "C2 · high swept", fmMuted, seedStyle, identity + "\nRaw C1 " + (s.dir == 1 ? "low " : "high ") + f_fmPrice(reference) + " sweep.\nThis is not a directional recommendation or a context-qualified model.\nAudit references the original candle; Focus begins its rails only when delivery review is observed.")
    if not na(s.cisdTime)
        int cisdStart = fmAudit ? s.cisdTime : math.max(s.cisdTime, reviewStart)
        bool deliveryVisible = railsVisible and (fmAudit or s.cisdTime <= right)
        ink.delivery := f_fmLine(ink.delivery, cisdStart, right, s.cisd, deliveryVisible ? railInk : color.new(fmInk, 100), line.style_solid, 1)
        if na(ink.cisd)
            string levels = "\nFrozen leg multiples, not statistical σ:\n1 = " + f_fmPrice(f_level(s, 1)) + " · 2 = " + f_fmPrice(f_level(s, 2)) + "\n2.5 = " + f_fmPrice(f_level(s, 2.5)) + " · 4 = " + f_fmPrice(f_level(s, 4))
            ink.cisd := f_fmLabel(s.cisdTime, s.cisd, "CISD observed", fmMuted, seedStyle, identity + "\nCandle-series open crossed at " + f_fmTime(s.cisdTime) + ".\nThis price observation alone does not pass delivery or POI checks." + levels)
        if fmShowProjections and not na(s.unit)
            bool projectionVisible = deliveryVisible and (fmProjectionScope == "All retained" or (fmProjectionScope == "Selected reviews" and selected) or s.key == projectionKey)
            color projectionInk = fmAudit ? fmInk : fmReview
            ink.level1 := f_fmLine(ink.level1, cisdStart, right, f_level(s, 1), color.new(projectionInk, projectionVisible ? (ended ? 85 : 72) : 100), line.style_dotted, 1)
            ink.level2 := f_fmLine(ink.level2, cisdStart, right, f_level(s, 2), color.new(projectionInk, projectionVisible ? (ended ? 82 : 54) : 100), line.style_dashed, 1)
            ink.level25 := f_fmLine(ink.level25, cisdStart, right, f_level(s, 2.5), color.new(projectionInk, projectionVisible ? (ended ? 85 : 66) : 100), line.style_dotted, 1)
            ink.level4 := f_fmLine(ink.level4, cisdStart, right, f_level(s, 4), color.new(projectionInk, projectionVisible ? (ended ? 85 : 72) : 100), line.style_dashed, 1)
    if not na(s.c2KnownTime)
        if na(ink.c2)
            string fact = s.c2Valid ? "C2 · inside C1" : "C2 · outside C1"
            ink.c2 := f_fmLabel(s.c2KnownTime, s.c2Close, fact, fmMuted, label.style_label_left, identity + "\nC2 closed " + (s.c2Valid ? "strictly inside" : "outside or on the boundary of") + " the entire C1 range.\nKnown " + f_fmTime(s.c2KnownTime) + ".\nThis is a closure fact, not delivery-context approval.")
        if not na(s.invalidLevel) and not na(s.closureTime)
            int invalidStart = fmAudit ? s.closureTime : math.max(s.closureTime, reviewStart)
            bool invalidVisible = railsVisible and (fmAudit or s.closureTime <= right)
            ink.invalidation := f_fmLine(ink.invalidation, invalidStart, right, s.invalidLevel, color.new(fmInk, invalidVisible ? 80 : 100), line.style_dashed, 1)
    if fmShowStages and not na(s.c3Time) and na(ink.c3)
        ink.c3 := f_fmLabel(s.c3Time, reference, "C3 stage", fmMuted, label.style_label_left, identity + "\nC3 stage observed " + f_fmTime(s.c3Time) + ". No context approval implied.")
    if (fmShowStages or s.closure == 3) and not na(s.c4Time) and na(ink.c4)
        ink.c4 := f_fmLabel(s.c4Time, reference, s.closure == 3 ? "C3 closure observed" : "C4 stage", fmMuted, label.style_label_left, identity + "\nObserved " + f_fmTime(s.c4Time) + ".\nC3 directional close beyond the C2 range: " + (s.c3Strong ? "yes" : "no") + ". Delivery review remains separate.")
    if s.cisdFailed and not na(s.cisdFailTime) and na(ink.earlyFailure)
        ink.earlyFailure := f_fmLabel(s.cisdFailTime, s.ext, "· CISD failed", fmMuted, label.style_label_left, identity + "\nFrozen sweep extreme violated " + f_fmTime(s.cisdFailTime) + ".\nOriginal observations stay recorded; structural invalidation is separate.")
    if fmShowFvg and not na(s.fvgTime)
        int gapStart = fmAudit ? s.fvgTime : math.max(s.fvgTime, reviewStart)
        bool gapVisible = railsVisible and (fmAudit or s.fvgTime <= right)
        if na(ink.gap)
            ink.gap := box.new(gapStart, s.fvgTop, right, s.fvgBot, xloc=xloc.bar_time, border_color=color.new(fmInk, 100), bgcolor=color.new(fmInk, 100))
            ink.gapSeen := f_fmLabel(s.fvgTime, s.dir == 1 ? s.fvgBot : s.fvgTop, "FVG observed", fmMuted, seedStyle, identity + "\nGap observed " + f_fmTime(s.fvgTime) + ".\n" + f_fmPrice(s.fvgBot) + " – " + f_fmPrice(s.fvgTop) + ".\nA gap alone does not pass delivery checks.")
        box.set_left(ink.gap, gapStart)
        box.set_right(ink.gap, right)
        box.set_border_color(ink.gap, color.new(fmAudit ? fmInk : fmReview, gapVisible ? 80 : 100))
        box.set_bgcolor(ink.gap, color.new(fmAudit ? fmInk : fmReview, gapVisible ? 96 : 100))
        if not na(s.touchTime) and na(ink.gapTouch)
            ink.gapTouch := f_fmLabel(s.touchTime, (s.fvgTop + s.fvgBot) / 2, "· FVG touch", fmMuted, label.style_label_left, identity + "\nLater bar overlap observed " + f_fmTime(s.touchTime) + ". Context only.")
    if not na(s.liqTime) and na(ink.liquidity)
        ink.liquidity := f_fmLabel(s.liqTime, s.dir == 1 ? s.c1High : s.c1Low, "C1 opposite level reached", fmMuted, label.style_label_left, identity + "\nOpposite C1 extreme reached " + f_fmTime(s.liqTime) + ".\nThis is not a trade result or setup-quality verdict.")
    if s.done and not na(s.endTime) and na(ink.finish)
        ink.finish := f_fmLabel(s.endTime, s.endPrice, "· " + s.status, fmMuted, label.style_label_left, identity + "\n" + s.status + " at " + f_fmTime(s.endTime) + ".\nRaw observation history remains available in Audit.")
    if reviewed and na(ink.review)
        string levels = "\nFrozen CISD " + f_fmPrice(s.cisd) + "\nLeg multiples: 1 = " + f_fmPrice(f_level(s, 1)) + " · 2 = " + f_fmPrice(f_level(s, 2)) + "\n2.5 = " + f_fmPrice(f_level(s, 2.5)) + " · 4 = " + f_fmPrice(f_level(s, 4))
        ink.review := f_fmLabel(q.reviewTime, q.reviewPrice, "Delivery review\nPOI / bias manual", fmReview, label.style_label_left, "Delivery checks observed " + f_fmTime(q.reviewTime) + " (" + syminfo.timezone + ")\nObservation " + s.key + "\nModel: " + q.reviewModel + "\nFrozen evidence: " + q.evidence + levels + "\nAutomated evidence for review; POI, bias and a trading decision remain manual.\nThis marker is never backdated to the original sweep.")
    if ended and na(ink.reviewOutcome)
        ink.reviewOutcome := f_fmLabel(q.endedAt, q.endPrice, q.lifecycle == "Withdrawn" ? "· Review withdrawn" : "· Review complete", fmMuted, label.style_label_left, "Delivery review " + s.key + "\n" + q.lifecycle + " at " + f_fmTime(q.endedAt) + " (" + syminfo.timezone + ")\n" + q.reason + "\nThe original review and its evidence remain unchanged.")
    // Opacity is a view choice. No event label is removed, moved, or recast as success.
    f_fmLabelVisibility(ink.seed, fmAudit, fmMuted)
    f_fmLabelVisibility(ink.cisd, fmAudit, fmMuted)
    f_fmLabelVisibility(ink.c2, fmAudit, fmMuted)
    f_fmLabelVisibility(ink.c3, fmAudit, fmMuted)
    f_fmLabelVisibility(ink.c4, fmAudit, fmMuted)
    f_fmLabelVisibility(ink.earlyFailure, fmAudit, color.new(fmInk, 65))
    f_fmLabelVisibility(ink.finish, fmAudit, color.new(fmInk, 65))
    f_fmLabelVisibility(ink.gapSeen, fmAudit, fmMuted)
    f_fmLabelVisibility(ink.gapTouch, fmAudit, fmMuted)
    f_fmLabelVisibility(ink.liquidity, fmAudit, fmMuted)
    f_fmLabelVisibility(ink.review, reviewVisible, fmReview)
    f_fmLabelVisibility(ink.reviewOutcome, reviewVisible, fmMuted)
    ink

// Reconcile by key, not array position; concurrent directions and adjacent models
// retain independent histories. Updating on EVERY close freezes completed rails
// identically in historical calculation, replay and subsequent real-time bars.
// Selection depends ONLY on immutable reviewTime. A later withdrawal/completion
// cannot remove an otherwise selected review or turn Focus into a winners filter.
int fmFirst = -1
int fmSecond = -1
int fmFirstTime = na
int fmSecondTime = na
int fmReviewCount = 0
int fmExcludedCount = 0
int fmAssessingCount = 0
int fmPendingIndex = -1
string fmProjectionKey = ""
string fmLatestReason = "Waiting for a raw observation"
if array.size(setups) > 0
    for i = 0 to array.size(setups) - 1
        Setup s = array.get(setups, i)
        ContextRecord q = f_contextFind(contexts, s.key)
        if not na(q)
            fmLatestReason := q.reason
            fmExcludedCount += q.lifecycle == "Excluded" ? 1 : 0
            fmAssessingCount += q.lifecycle == "Assessing" ? 1 : 0
            if not na(q.reviewTime)
                fmReviewCount += 1
                if na(fmFirstTime) or q.reviewTime >= fmFirstTime
                    fmSecond := fmFirst
                    fmSecondTime := fmFirstTime
                    fmFirst := i
                    fmFirstTime := q.reviewTime
                    fmProjectionKey := s.key
                else if na(fmSecondTime) or q.reviewTime >= fmSecondTime
                    fmSecond := i
                    fmSecondTime := q.reviewTime
        if not s.done and s.stage <= 3 and na(s.cisdTime) and not na(s.anchor)
            fmPendingIndex := i
if barstate.isconfirmed
    map<string, bool> retainedKeys = map.new<string, bool>()
    if array.size(setups) > 0
        for i = 0 to array.size(setups) - 1
            Setup s = array.get(setups, i)
            map.put(retainedKeys, s.key, true)
    int fmOld = array.size(fmInks) - 1
    while fmOld >= 0
        SetupInk stale = array.get(fmInks, fmOld)
        if not map.contains(retainedKeys, stale.key)
            f_fmErase(stale)
            map.remove(fmInkByKey, stale.key)
            array.remove(fmInks, fmOld)
        fmOld -= 1
    if array.size(setups) > 0
        for i = 0 to array.size(setups) - 1
            Setup s = array.get(setups, i)
            if not map.contains(fmInkByKey, s.key)
                SetupInk fresh = SetupInk.new(key=s.key)
                array.push(fmInks, fresh)
                map.put(fmInkByKey, s.key, fresh)
            SetupInk ink = map.get(fmInkByKey, s.key)
            ContextRecord q = f_contextFind(contexts, s.key)
            f_fmPaint(s, q, ink, i == fmFirst or i == fmSecond, fmProjectionKey)
    if fmAudit and fmShowDeveloping and fmPendingIndex >= 0
        Setup pending = array.get(setups, fmPendingIndex)
        fmDeveloping := f_fmLine(fmDeveloping, pending.seenTime, time_close, pending.anchor, color.new(fmInk, 70), line.style_dashed, 1)
        string tip = "Developing level for observation " + pending.key + ".\nCurrent candle-series open: " + f_fmPrice(pending.anchor) + ".\nThis level may move before confirmation. No delivery review or directional recommendation is implied."
        if na(fmDevelopingCaption)
            fmDevelopingCaption := f_fmLabel(time_close, pending.anchor, "Developing CISD · unconfirmed", fmMuted, label.style_label_left, tip)
        else
            label.set_xy(fmDevelopingCaption, time_close, pending.anchor)
            label.set_text(fmDevelopingCaption, "Developing CISD · unconfirmed")
            label.set_textcolor(fmDevelopingCaption, fmMuted)
            label.set_color(fmDevelopingCaption, color.new(fmPaper, 12))
            label.set_tooltip(fmDevelopingCaption, tip)
    else
        if not na(fmDeveloping)
            line.set_color(fmDeveloping, color.new(fmInk, 100))
            label.set_text(fmDevelopingCaption, "")
            label.set_color(fmDevelopingCaption, color.new(fmPaper, 100))

f_fmCandle(CandleInk ink, int center, int halfWidth, float o, float h, float l, float c, string caption, string tip, bool forming) =>
    color direction = c >= o ? fmBull : fmBear
    float top = math.max(o, c)
    float bottom = math.min(o, c)
    if not na(o)
        if na(ink.body)
            ink.wick := line.new(center, l, center, h, xloc=xloc.bar_time, color=direction, width=1)
            ink.body := box.new(center - halfWidth, top, center + halfWidth, bottom, xloc=xloc.bar_time, border_color=direction, bgcolor=color.new(direction, forming ? 87 : 64))
            ink.caption := f_fmLabel(center, l, caption, forming ? fmInk : fmMuted, label.style_label_up, tip)
        else
            line.set_xy1(ink.wick, center, l)
            line.set_xy2(ink.wick, center, h)
            line.set_color(ink.wick, direction)
            box.set_lefttop(ink.body, center - halfWidth, top)
            box.set_rightbottom(ink.body, center + halfWidth, bottom)
            box.set_border_color(ink.body, direction)
            box.set_bgcolor(ink.body, color.new(direction, forming ? 87 : 64))
            label.set_xy(ink.caption, center, l)
            label.set_text(ink.caption, caption)
            label.set_tooltip(ink.caption, tip)
    ink

if barstate.isfirst
    for i = 0 to 3
        array.push(fmCandles, CandleInk.new())
    table.merge_cells(fmDesk, 0, 0, 4, 0)
    table.merge_cells(fmDesk, 0, 1, 4, 1)
    table.merge_cells(fmDesk, 0, fmDeskRows - 1, 4, fmDeskRows - 1)

if barstate.islastconfirmedhistory or barstate.isrealtime
    // Preview is display-only: the engine never consumes this forming OHLC.
    int fmStep = int(timeframe.in_seconds() * 1000)
    if fmShowHtf and fmStep > 0
        bool frameIsCurrent = engine.frameTime == htfTime
        float previewOpen = frameIsCurrent ? engine.frameOpen : open
        float previewHigh = frameIsCurrent ? math.max(engine.frameHigh, high) : high
        float previewLow = frameIsCurrent ? math.min(engine.frameLow, low) : low
        float previewClose = close
        int secondsLeft = int(math.max(0, (htfEnd - (barstate.isrealtime ? timenow : time_close)) / 1000))
        string clockText = str.tostring(int(secondsLeft / 60)) + ":" + str.tostring(secondsLeft % 60, "00")
        array<float> os = array.from(pO3, pO2, pO1, previewOpen)
        array<float> hs = array.from(pH3, pH2, pH1, previewHigh)
        array<float> ls = array.from(pL3, pL2, pL1, previewLow)
        array<float> cs = array.from(pC3, pC2, pC1, previewClose)
        array<int> ts = array.from(pT3, pT2, pT1, htfTime)
        for i = 0 to 3
            int center = time + fmStep * (8 + i * 5)
            bool forming = i == 3
            string caption = forming ? htfTf + " · FORMING /\nbar-close snapshot" : str.format_time(array.get(ts, i), "HH:mm", syminfo.timezone)
            string tip = (forming ? "FORMING / bar-close snapshot — refreshed on confirmed chart closes; not setup confirmation" : "Closed HTF candle") + "\n" + htfTf + " · " + f_fmTime(array.get(ts, i)) + " (" + syminfo.timezone + ")\nO " + f_fmPrice(array.get(os, i)) + "   H " + f_fmPrice(array.get(hs, i)) + "\nL " + f_fmPrice(array.get(ls, i)) + "   C " + f_fmPrice(array.get(cs, i)) + "\nEQ " + f_fmPrice((array.get(hs, i) + array.get(ls, i)) / 2)
            f_fmCandle(array.get(fmCandles, i), center, fmStep, array.get(os, i), array.get(hs, i), array.get(ls, i), array.get(cs, i), caption, tip, forming)
        if not na(pH1)
            fmPrevHigh := f_fmLine(fmPrevHigh, time + fmStep * 16, time + fmStep * 25, pH1, color.new(fmInk, 65), line.style_dotted, 1)
            fmPrevLow := f_fmLine(fmPrevLow, time + fmStep * 16, time + fmStep * 25, pL1, color.new(fmInk, 65), line.style_dotted, 1)
            fmPrevEq := f_fmLine(fmPrevEq, time + fmStep * 16, time + fmStep * 25, (pH1 + pL1) / 2, color.new(fmInk, 80), line.style_dashed, 1)
    if fmShowDesk
        table.cell(fmDesk, 0, 0, "FRACTAL MODEL DESK · " + str.upper(fmView) + " / " + htfTf, text_color=fmInk, text_size=fmTableSize, text_halign=text.align_left, bgcolor=color.new(fmInk, 91))
        table.cell(fmDesk, 0, 1, "Observed " + str.tostring(engine.total) + " · Retained " + str.tostring(array.size(setups)) + "/" + str.tostring(inHistory) + "\nIn retained: reviews " + str.tostring(fmReviewCount) + " · excluded " + str.tostring(fmExcludedCount) + " · assessing " + str.tostring(fmAssessingCount), text_color=fmMuted, text_size=fmTableSize, text_halign=text.align_left, tooltip="Raw observation count is separate from delivery reviews. Retention evictions: " + str.tostring(engine.evicted) + ". Exclusion means current automated delivery checks were not met; it does not delete the observation.")
        array<string> headers = fmAudit ? array.from("C2 OPEN", "SWEEP", "OBSERVATIONS", "CONTEXT", "REASON") : array.from("REVIEWED", "SWEEP", "EVIDENCE", "STATE", "CURRENT REASON")
        for col = 0 to 4
            table.cell(fmDesk, col, 2, array.get(headers, col), text_color=fmMuted, text_size=fmTableSize, text_halign=text.align_left, tooltip="Times: " + syminfo.timezone + ". Review time is when automated delivery evidence became observable. A review still needs manual POI and bias assessment.")
        for row = 0 to (fmAudit ? 4 : 1)
            int idx = fmAudit ? array.size(setups) - 1 - row : row == 0 ? fmFirst : fmSecond
            if idx >= 0
                Setup s = array.get(setups, idx)
                ContextRecord q = f_contextFind(contexts, s.key)
                string closureText = s.closure > 0 ? "C" + str.tostring(s.closure) + " close seen" : not na(s.c2KnownTime) ? "C2 outside" : "C2 pending"
                string cisdText = s.cisdFailed ? "CISD failed" : not na(s.cisdTime) ? "CISD observed" : "CISD pending"
                string reason = na(q) ? "Awaiting context assessment" : q.reason
                string lifecycle = na(q) ? "Assessing" : q.lifecycle
                string identity = "Observation " + s.key + "\nC2 open: " + f_fmTime(s.c2Time) + "\nSweep observed: " + f_fmTime(s.seenTime) + "\nCISD: " + f_fmTime(s.cisdTime) + "\nClosure known: " + f_fmTime(s.closureTime) + "\nTimes: " + syminfo.timezone
                identity += not na(q) and not na(q.internalSweepTime) ? "\nEarlier local sweep/reclaim " + f_fmTime(q.internalSweepTime) + " at " + f_fmPrice(q.internalLevel) + "; possible inducement context, intent unknown." : "\nNo separately known prior local swing sweep; inducement intent unknown."
                string evidence = fmAudit ? closureText + "\n" + cisdText : q.reviewModel
                string evidenceTip = fmAudit ? identity + "\n" + s.status : "Review observed " + f_fmTime(q.reviewTime) + ".\nFrozen evidence: " + q.evidence + "\nManual POI and bias assessment required."
                table.cell(fmDesk, 0, row + 3, f_fmTime(fmAudit ? s.c2Time : q.reviewTime), text_color=fmInk, text_size=fmTableSize, text_halign=text.align_left, tooltip=identity)
                table.cell(fmDesk, 1, row + 3, (s.dir == 1 ? "Low swept" : "High swept") + (s.dualSweep ? "\nBoth extremes" : ""), text_color=fmMuted, text_size=fmTableSize, text_halign=text.align_left)
                table.cell(fmDesk, 2, row + 3, evidence, text_color=fmAudit ? fmMuted : fmReview, text_size=fmTableSize, text_halign=text.align_left, tooltip=evidenceTip)
                table.cell(fmDesk, 3, row + 3, lifecycle, text_color=fmMuted, text_size=fmTableSize)
                table.cell(fmDesk, 4, row + 3, f_fmShort(reason), text_color=fmMuted, text_size=fmTableSize, text_halign=text.align_left, tooltip=reason)
            else
                for col = 0 to 4
                    string emptyText = row == 0 and col == 0 ? (fmAudit ? "No observations" : "No delivery review") : row == 0 and col == 4 ? f_fmShort(fmLatestReason) : ""
                    table.cell(fmDesk, col, row + 3, emptyText, text_color=fmMuted, text_size=fmTableSize, text_halign=text.align_left, tooltip=row == 0 ? "Latest observation: " + fmLatestReason : "")
        table.cell(fmDesk, 0, fmDeskRows - 1, "Automated delivery checks · POI / bias manual\nTimes: " + syminfo.timezone + " · " + (fmAudit ? "Raw audit history" : "Latest 2 reviews · outcomes preserved"), text_color=fmMuted, text_size=fmTableSize, text_halign=text.align_left, tooltip="Focus selects two records by immutable review observation time, including later withdrawn and completed reviews. It never selects by trade outcome. Audit exposes retained raw facts. Hidden drawings remain recorded. Ledger times use the exchange timezone, which can differ from chart display time. Automated delivery evidence is not manual POI or directional-bias approval.")

// Two reusable display slots bound IC drawings independently of retained history.
// Rails start when anatomy is observed, never at the historical swing location.
var array<line> fmIcRails = array.new<line>()
var array<label> fmIcLabels = array.new<label>()
if barstate.isconfirmed and fmShowIc
    for rail in fmIcRails
        line.delete(rail)
    for caption in fmIcLabels
        label.delete(caption)
    array.clear(fmIcRails)
    array.clear(fmIcLabels)
    array<IcRecord> selectedIc = array.new<IcRecord>()
    if array.size(icBook) > 0
        for item in icBook
            if not na(item.formedTime) and (fmAudit or not na(item.reviewTime))
                int slot = array.size(selectedIc)
                if array.size(selectedIc) > 0
                    for n = 0 to array.size(selectedIc) - 1
                        if item.formedTime >= array.get(selectedIc, n).formedTime
                            slot := n
                            break
                array.insert(selectedIc, slot, item)
                if array.size(selectedIc) > 2
                    array.pop(selectedIc)
        for item in selectedIc
            bool reviewed = not na(item.reviewTime)
            int endTime = na(item.endedAt) ? time_close : item.endedAt
            string tip = "IC " + item.key + "\nParent " + item.parentKey + "\nAnatomy observed " + f_fmTime(item.formedTime) + "\nProtected swing " + f_fmPrice(item.protectedLevel) + " at " + f_fmTime(item.protectedTime) + "\nSwing known " + f_fmTime(item.protectedKnownTime) + "\n" + item.formationReason + "\nCurrent: " + item.reason + "\nChild swing taken does not itself invalidate the parent."
            array.push(fmIcRails, line.new(item.formedTime, item.protectedLevel, endTime, item.protectedLevel, xloc=xloc.bar_time, color=reviewed ? color.new(fmReview, 45) : fmMuted, style=line.style_dotted))
            array.push(fmIcLabels, f_fmLabel(item.formedTime, item.formedPrice, reviewed ? "IC delivery review\nPOI / bias assessment" : "IC anatomy\nContext incomplete", reviewed ? fmReview : fmMuted, label.style_label_left, tip))
            if not na(item.endedAt)
                array.push(fmIcLabels, f_fmLabel(item.endedAt, item.protectedLevel, "IC ended", fmMuted, label.style_label_left, "Observed " + f_fmTime(item.endedAt) + "\n" + item.endReason + (not na(item.takenTime) ? "\nProtected swing taken " + f_fmTime(item.takenTime) : "") + "\nOriginal IC anatomy retained; parent assessed independently."))

f_jsonNumber(float value) => na(value) ? "null" : str.tostring(value, "0.################")
f_escape(string value) => str.replace_all(str.replace_all(value, "\\", "\\\\"), "\"", "\\\"")
f_eventClass(string kind) => kind == "DELIVERY_REVIEW" ? "delivery_review" : kind == "REVIEW_END" ? "review_outcome" : kind == "IC_REVIEW" ? "ic_review" : kind == "IC_ANATOMY" ? "ic_anatomy" : kind == "IC_TAKEN" or kind == "IC_END" ? "ic_outcome" : "raw_observation"
bool alertSweep = false
bool alertCisd = false
bool alertClosure = false
bool alertFailure = false
bool alertRetest = false
bool alertReview = false
bool alertReviewEnd = false
bool alertIc = false
bool alertIcEnd = false
array<FmEvent> outboundEvents = array.new<FmEvent>()
if barstate.isconfirmed
    for event in reviewEvents
        array.push(outboundEvents, event)
    for event in icEvents
        if inAlertScope == "All observations" or event.kind == "IC_REVIEW" or ((event.kind == "IC_TAKEN" or event.kind == "IC_END") and str.contains(event.detail, "ic_reviewed=true;"))
            array.push(outboundEvents, event)
    if inAlertScope == "All observations"
        for event in events
            array.push(outboundEvents, event)
if barstate.isconfirmed and array.size(outboundEvents) > 0
    string payload = ""
    for event in outboundEvents
        alertSweep := alertSweep or event.kind == "SWEEP"
        alertCisd := alertCisd or event.kind == "CISD"
        alertClosure := alertClosure or event.kind == "C2_CLOSED" or event.kind == "C3_CLOSED"
        alertFailure := alertFailure or event.kind == "C2_FAILED" or event.kind == "CISD_FAILED" or (event.kind == "END" and event.detail != "C4 window complete")
        alertRetest := alertRetest or event.kind == "RETEST"
        alertReview := alertReview or event.kind == "DELIVERY_REVIEW"
        alertReviewEnd := alertReviewEnd or event.kind == "REVIEW_END"
        alertIc := alertIc or event.kind == "IC_REVIEW"
        alertIcEnd := alertIcEnd or event.kind == "IC_TAKEN" or event.kind == "IC_END"
        payload += (payload == "" ? "" : ",") + "{\"id\":\"" + event.key + "\",\"event\":\"" + event.kind + "\",\"classification\":\"" + f_eventClass(event.kind) + "\",\"observed_at\":" + str.tostring(event.stamp) + ",\"direction\":" + str.tostring(event.dir) + ",\"price\":" + f_jsonNumber(event.price) + ",\"detail\":\"" + f_escape(event.detail) + "\"}"
    if inJson
        alert("{\"schema\":\"fm-desk-v2.1\",\"rules_version\":\"2.1.0\",\"scope\":\"" + inAlertScope + "\",\"full_model_validation\":false,\"symbol\":\"" + f_escape(syminfo.tickerid) + "\",\"chart_tf\":\"" + timeframe.period + "\",\"htf\":\"" + htfTf + "\",\"events\":[" + payload + "]}", alert.freq_once_per_bar_close)
